8-216035-1 Product Details
Live Product Chat
Product View
Standard Board Mount Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (9)
Product Feature Selector
C ontact Us About This Product
8-216035-1
T E I nternal N umber: 8 - 2 1 6 0 3 5 - 1
Product Highlights:
l
Number of Positions = 25
l
Receptacle
l
PC B Mount Angle = Vertical
l
Product Series = HDP-20
l
With Mating C onnector Lock
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (9)
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions
= 25
l
Gender
= Receptacle
l
PC B Mount Angle
= Vertical
l
Product Series
= HDP-20
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type
= Bushing with 4-40 UNC Thread
l
PC B Retention Feature
= No
l
Shell Type
= Front Metal Shell
l
Shell Size
= 3
l
PC B Thickness (in [mm])
= 0.062 [1.57]
l
Grounding Indents
= Without
l
Grounding Straps
= Without
l
PC B Mount Style
= Through Hole
l
C olor C ode
= None
l
Sealed = No
l
Profile = Standard
l
Post Size (mm [in]) = 0.66 [.026]
l
Mounting Hole Diameter (mm [in]) = 3.00 [.118]
l
C olor = Black
l
Shell Material = Steel
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Grounding C lips
= Without
l
Termination Post Length (mm [in])
= 3.20 [0.126]
l
Solder Tail C ontact Plating
= Bright Tin-Lead
Body Related Features:
l
Shell Plating = Bright Tin
l
Bushing Material = Aluminum
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Shape = Round
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Flammability Rating = UL 94V-0
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
