BT137B-600E
4Q Triac
26 September 2013
Product data sheet
1. General description
Planar passivated sensitive gate four quadrant triac in a SOT404 (D2PAK) surface-
mountable plastic package intended for use in general purpose bidirectional switching
and phase control applications. This sensitive gate "series E" triac is intended to be
interfaced directly to microcontrollers, logic integrated circuits and other low power gate
trigger circuits.
2. Features and benefits
•
•
•
•
•
•
•
Direct triggering from low power drivers and logic ICs
High blocking voltage capability
Low holding current for low current loads and lowest EMI at commutation
Planar passivated for voltage ruggedness and reliability
Sensitive gate
Surface-mountable package
Triggering in all four quadrants
3. Applications
•
•
General purpose motor control
General purpose switching
4. Quick reference data
Table 1.
Symbol
V
DRM
I
TSM
I
T(RMS)
Quick reference data
Parameter
repetitive peak off-
state voltage
non-repetitive peak on- full sine wave; T
j(init)
= 25 °C;
state current
t
p
= 20 ms;
Fig. 4; Fig. 5
RMS on-state current
full sine wave; T
mb
≤ 102 °C;
Fig. 1;
Fig. 2; Fig. 3
Static characteristics
I
GT
gate trigger current
V
D
= 12 V; I
T
= 0.1 A; T2+ G+;
T
j
= 25 °C;
Fig. 7
V
D
= 12 V; I
T
= 0.1 A; T2+ G-;
T
j
= 25 °C;
Fig. 7
-
4
10
mA
-
2.5
10
mA
Conditions
Min
-
-
-
Typ
-
-
-
Max
600
65
8
Unit
V
A
A
Scan or click this QR code to view the latest information for this product
D2
PA
K
NXP Semiconductors
BT137B-600E
4Q Triac
Symbol
Parameter
Conditions
V
D
= 12 V; I
T
= 0.1 A; T2- G-;
T
j
= 25 °C;
Fig. 7
V
D
= 12 V; I
T
= 0.1 A; T2- G+;
T
j
= 25 °C;
Fig. 7
Min
-
-
-
Typ
5
11
2.5
Max
10
25
20
Unit
mA
mA
mA
I
H
holding current
V
D
= 12 V; T
j
= 25 °C;
Fig. 9
5. Pinning information
Table 2.
Pin
1
2
3
mb
Pinning information
Symbol Description
T1
T2
G
T2
main terminal 1
main terminal 2
gate
mounting base; main
terminal 2
2
1
3
Simplified outline
mb
Graphic symbol
T2
sym051
T1
G
D2PAK (SOT404)
6. Ordering information
Table 3.
Ordering information
Package
Name
BT137B-600E
D2PAK
Description
Version
plastic single-ended surface-mounted package (D2PAK); 3 leads SOT404
(one lead cropped)
Type number
BT137B-600E
All information provided in this document is subject to legal disclaimers.
© NXP N.V. 2013. All rights reserved
Product data sheet
26 September 2013
2 / 14
NXP Semiconductors
BT137B-600E
4Q Triac
7. Limiting values
Table 4.
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol
V
DRM
I
T(RMS)
I
TSM
Parameter
repetitive peak off-state voltage
RMS on-state current
non-repetitive peak on-state
current
full sine wave; T
mb
≤ 102 °C;
Fig. 1;
Fig. 2; Fig. 3
full sine wave; T
j(init)
= 25 °C;
t
p
= 20 ms;
Fig. 4; Fig. 5
full sine wave; T
j(init)
= 25 °C;
t
p
= 16.7 ms
I t
dI
T
/dt
2
Conditions
Min
-
-
-
-
-
-
-
-
-
-
-
Max
600
8
65
71
21
50
50
50
10
2
5
0.5
150
125
Unit
V
A
A
A
2
I t for fusing
rate of rise of on-state current
2
t
p
= 10 ms; SIN
I
T
= 12 A; I
G
= 0.2 A; dI
G
/dt = 0.2 A/µs;
T2+ G+
I
T
= 12 A; I
G
= 0.2 A; dI
G
/dt = 0.2 A/µs;
T2+ G-
I
T
= 12 A; I
G
= 0.2 A; dI
G
/dt = 0.2 A/µs;
T2- G-
I
T
= 12 A; I
G
= 0.2 A; dI
G
/dt = 0.2 A/µs;
T2- G+
A s
A/µs
A/µs
A/µs
A/µs
A
W
W
°C
°C
I
GM
P
GM
P
G(AV)
T
stg
T
j
peak gate current
peak gate power
average gate power
storage temperature
junction temperature
over any 20 ms period
-
-40
-
BT137B-600E
All information provided in this document is subject to legal disclaimers.
© NXP N.V. 2013. All rights reserved
Product data sheet
26 September 2013
3 / 14
NXP Semiconductors
BT137B-600E
4Q Triac
10
I
T(RMS)
(A)
8
003aae689
25
I
T(RMS)
(A)
20
003aae692
6
15
4
10
2
5
0
- 50
0
50
100
T
mb
(°C)
150
0
10- 2
10- 1
1
10
surge duration (s)
Fig. 1.
RMS on-state current as a function of mounting
base temperature; maximum values
Fig. 2.
12
f = 50 Hz
T
mb
≤ 102 °C
RMS on-state current as a function of surge
duration; maximum values
003aae690
P
tot
(W)
8
conduction
form
angle
factor
(degrees)
a
30
4
60
2.8
90
2.2
120
1.9
180
1.57
α = 180°
120°
α
90°
60°
30°
4
0
0
2
4
6
8
I
T(RMS)
(A)
10
α = conduction angle
a = form factor = I
T(RMS)
/I
T(AV)
Fig. 3.
Total power dissipation as a function of RMS on-state current; maximum values
BT137B-600E
All information provided in this document is subject to legal disclaimers.
© NXP N.V. 2013. All rights reserved
Product data sheet
26 September 2013
4 / 14
NXP Semiconductors
BT137B-600E
4Q Triac
10
3
I
TSM
(A)
003aae691
I
T
I
TSM
t
t
p
T
j(init)
= 25 °C max
10
2
(1)
(2)
10
10
- 5
10
- 4
10
- 3
10
- 2
t
p
(s)
10
- 1
t
p
≤ 20 ms
(1) dI
T
/dt limit
(2) T2- G+ quadrant limit
Fig. 4.
Non-repetitive peak on-state current as a function of pulse width; maximum values
80
I
TSM
(A)
60
003aae693
40
I
T
20
I
TSM
t
1/f
T
j(init)
= 25 °C max
0
1
10
10
2
10
3
number of cycles
10
4
f = 50 Hz
Fig. 5.
Non-repetitive peak on-state current as a function of the number of sinusoidal current cycles; maximum
values
BT137B-600E
All information provided in this document is subject to legal disclaimers.
© NXP N.V. 2013. All rights reserved
Product data sheet
26 September 2013
5 / 14
