PL
IA
NT
Features
■
RoHS compliant*
■
Convex termination style
■
2 isolated elements in an 02 package width
■
Resistance tolerance: ±5 %
■
Resistance range: 10 ohms to 1 megohm
*R
oH
S
CO
M
& zero-ohm jumper
■
Sulfur-resistant design
CAY06-AS Series
-
Sulfur-Resistant Thick Film Chip Arrays
General Characteristics
Characteristic
Number of Elements (Isolated)
Power Rating @ 70 °C per Resistor
Resistor Tolerance
Resistance Range (E24) plus Zero-ohm Jumper
Temperature Coefficient of Resistance (TCR)
Maximum Overload Voltage
Maximum Working Voltage
Operating Temperature Range
Storage Conditions
Derating Temperature
Packaging (Paper Tape)
Zero-ohm Jumper:
Current Rating
Maximum Resistance
CAY06-AS
2
31 mW
±5 %
10 ohms to 1 megohm
±200 ppm
25 V
12.5 V
-55 to +125 °C
+5 ~ +40 °C, 25~75 % RH, 1 year
How To Order
CA Y 06 - 103 J 2 AS
Chip Array
Type
• Y = Convex
Model
• 06 = 02 Package Width
Resistance Code
• First two digits are significant,
third digit represents number of
zeros to follow
(example: 103 = 10K ohms)
• 000 = Zero-ohm jumper
Resistance Tolerance
• J = ±5 %
Resistors
• 2 = 2 Resistors
Special Characteristics
• AS = Sulfur-resistant, Tin-plated terminations
(RoHS compliant)
+70 °C
10,000 pcs. per reel
1 A per element
100 milliohms
For Standard Values Used in Capacitors,
Inductors, and Resistors,
click here.
Environmental Characteristics
Specification
Test Method
(JIS C 5201-1)
Construction
Characteristics
±(2 % +0.1 ohm)
±(1 % +0.05 ohm)
±(1 % +0.05 ohm)
±(3 % +0.1 ohm)
±(3 % +0.1 ohm)
±(5 % +0.1 ohm)
PROTECTIVE
GLASS
OVERCOAT
HIGH PURITY
ALUMINA
SUBSTRATE
TERMINATION
THICK FILM
RESISTIVE
ELEMENT
Short Time
Overload
Soldering Heat
Temperature
Cycling
Moisture Load
Life
Load Life
Sulfur Test
Rated voltage x 2.5, 5 seconds
+260 °C ±5 °C, 10 ±1 seconds
-55 °C (30 minutes) - normal (2~3 minutes)
+125 °C (30 minutes) - normal (2~3 minutes), 5 cycles
+40 °C, 90~95 % RH, 1000 hours,
1.5 hours ON, 0.5 hours OFF
+70 °C, 1000 hours,
1.5 hours ON, 0.5 hours OFF
3 ppm H2S, +50 °C, 90~95 % RH, 100 hours
NOTE: Zero-ohm jumper <100 milliohms.
Soldering Profile
275
<1>
Maximum of 20 seconds between
260 °C peak
<1>
255 °C
+255 °C and +260 °C
225
220 °C
Temperature (°C)
190 °C
175
150 °C
60 - 90
seconds
Ramp Down
6 °C/second
125
60 - 120 seconds
10 seconds minimum
* RoHS Directive 2002/95/EC Jan. 27, 2003 including
annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data
sheet can and do vary in different applications and
actual device performance may vary over time.
250
300
75
Ramp Up
3 °C/second maximum
25
0
50
100
150
Time (seconds)
200
Users should verify actual device performance in their
specific applications.
CAY06-AS Series
-
Sulfur-Resistant Thick Film Chip Arrays
Derating Curve
100
80
60
40
20
0
-55
40 60
mbien Tem .
80
100 120 140 160
70
125
Isolated Circuit
4
3
Typical Part Marking
Marking.........Refer to Product Dimensions
Marking Color ...................................Yellow
R
oa
R
ae
1
2
Product Dimensions
Dim.
L
W
T
P
A
B
G
CAY06-AS
0.85 ± 0.05
(0.033 ± 0.002)
0.60 ± 0.05
(0.024 ± 0.002)
0.35 ± 0.05
(0.014 ± 0.002)
0.50 ± 0.05
(0.020 ± 0.002)
0.37 ± 0.05
(0.015 ± 0.002)
0.11 ± 0.05
(0.004 ± 0.002)
0.17 ± 0.05
(0.007 ± 0.002)
B
P
L
T
G
W
B
A
G
Recommended Land Pattern
0.50
(.020)
0.30
(.012)
0.30
(.012)
0.30
(.012)
0.30
(.012)
DIMENSIONS:
MM
(INCHES)
Packaging Specifications
4.00 ± 0.10
(.157 ± .004)
2.00 ± 0.05
(.079 ± .002)
DIA.
1.50 +0.10/-0
(.059 +.004/-0)
2.0 ± 0.5
(.079 ± .020)
9.0 ± 0.3
(.354 ± .012)
1.75 ± 0.10
(.069 ± .004)
13.0 ± 0.2
(.511 ± .008)
3.50 ± 0.05
(.138 ± .002)
8.00 ± 0.30
(.315 ± .012)
1.00 ± 0.04
(.039 ± .001)
3
4
2
1
2.00 ± 0.05
(.079 ± .002)
4.00 ± 0.10
(.157 ± .004)
2.75 ± 0.10
(.108 ± .004)
0.70 ± 0.04
(.028 ± .001)
0.48 ± 0.05
(.019 ± .002)
180
(7.087)
21.0 ± 0.8
(.827 ± .031)
60
(2.362)
11.4 ± 1.0
(.449 ± .040)
DIMENSIONS:
MM
(INCHES)
ORIENTATION OF
PART IN TAPE
Asia-Pacific:
Tel: +886-2 2562-4117 • Email: asiacus@bourns.com
EMEA:
Tel: +36 88 520 390 • Email: eurocus@bourns.com
The Americas:
Tel: +1-951 781-5500 • Email: americus@bourns.com
www.bourns.com
10/16
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
