F-219
T2M–110–01–L–D–TH–WT–DS
T2M–105–01–L–D–TH–WT
(2.00 mm) .0787"
T2M–105–01–L–D–RA–WT
T2M–105–01–L–D–SM–WT
T2M SERIES
HIGH-RELIABILITY CABLE HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?T2M
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating (T2M/S2SD):
3.8 A per pin
(2 pins powered)
Voltage Rating:
250 VAC/350 VDC
mated with S2SD
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
Board Mates:
S2M
Cable Mates:
S2SD, S2SDT
Mates with Tiger Eye
™
discrete wire cable
assemblies
Up to 30
positions per row
• Weld tabs
MATED HEIGHT
S2M
SM= (7.06 mm) .278"
THT= (6.17 mm) .243"
T2M
Optional
weld tab
Choice of surface mount,
through-hole or right-angle
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
T2M
1
NO. OF
POSITIONS
01
PLATING
OPTION
D
OPTION
OTHER
OPTION
05, 07, 10,
15, 20, 25, 30
(Per Row)
No. of positions x (2.00) .0787 + (14.38) .566
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Through-hole
–TH
OTHER
SOLUTIONS
= Right-angle
–RA
= Weld Tab
(S2SD & S2SDT,
–SR/–DR required
mate)
–WT
(6.00)
.236
(3.98)
.157
= Surface Mount
–SM
= Screw Down
(N/A with –RA)
(mates with
–S2M–DS,
S2SD/S2SDT
–SS/–DS option)
–DS
See S2SD in the
discrete wire section
(0.64)
.025
SQ
(3.81)
.150
No. of positions x (2.00) .0787 + (5.67) .223
(1.98)
.078
–DS
02
(2.29)
.090
(7.44)
.293
(1.77)
(2.26) .070
.089
= (7.50 mm) .295" DIA
Polyimide film
Pick & Place Pad
(–SM only)
–K
ALSO AVAILABLE
(MOQ Required)
• Other platings
(2.00)
.0787
01
–RA–WT
(2.00)
.0787 (1.52)
.060
= Tape & Reel
(–SM only)
–TR
(8.76)
.345
(2.41)
.095
(0.50)
.020
SQ
(6.55)
.258
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(2.00)
.0787
(0.64)
.025
(8.63)
.340
–TH–WT
Due to technical progress, all designs, specifications and components are subject to change without notice.
–SM–WT
(1.64)
.065
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
