F-219
SLM–112–01–L–D
SMS–106–02–L–S
SMS–122–01–G–S
(1.27 mm) .050"
SLM–134–01–G–D
SLM, SMS SERIES
THROUGH-HOLE MICRO SOCKETS
SPECIFICATIONS
For complete specifications
see www.samtec.com?SLM
or www.samtec.com?SMS
Insulator Material:
SLM: Black Glass
Filled Polyester
SMS: Black LCP
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating
(SLM/TMS):
5.2 A per pin
(2 pins powered)
Current Rating (SMS/TMS):
5.0 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
Insertion Depth:
SLM: (2.03 mm) .080"
to (3.05 mm) .120"
SMS: (3.43 mm) .135" to
(6.35 mm) .250" with
(0.38 mm) .015" wipe
RoHS Compliant:
Yes
SLM
1
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
Mates with:
HTMS, TMS, MTMS, DWM,
HDWM, FTR, HMTMS
01 thru 50
(1.27) .050 X No. of Positions
01
50
= 10 µ" (0.25 µm) Gold on contact,
Matte Tin on tail
–L
= Single
Row
–S
(2.54)
.100
(1.27)
.050
TYP
= 20 µ" (0.51 µm) Gold on contact,
Gold flash on balance
–G
= Double
Row
–D
100
02
ALSO AVAILABLE
(2.54) (5.08)
.100 .200
(MOQ Required)
• Other platings
99
01
(0.25)
.010
(4.57)
.180
PROCESSING
Lead-Free Solderable:
SLM: Wave Only
SMS: Yes
(0.51)
.020
x
(0.41)
.016
TYP
(2.92)
.115
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
SMS
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
FILE NO. E111594
Mates with:
HTMS, TMS, MTMS,
DWM, HDWM, FTR, TML,
ZML, HMTMS
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
= Single
Row
–S
01 thru 50
01
= 10 µ" (0.25 µm)
Gold
50
–G
= Double
Row
–D
(1.27) .050 X No. of Positions
(3.05)
.120
(1.27) .050 TYP
100
02
(2.54) (5.59)
.100 .220
99
01
LEAD STYLE
–01
–02
A
(2.54) .100
(4.83) .190
ALSO AVAILABLE
(MOQ Required)
(8.51)
.335
(8.51)
.335
• Other platings
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(0.51)
.020
A
(0.41) .016
(0.51) .020
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
