3075 (SPECIAL Q-00021555) datasheet, PDF

Datasheet> All Categories > Wire/cable> cable> 3075 (SPECIAL Q-00021555)

3075 (SPECIAL Q-00021555): DescriptionConnecting wire 18AWG 16/30 PVC 1000FT SPOOL SPECIAL; CategoryWire/cable cable; File Size1MB，20 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric View All

3075 (SPECIAL Q-00021555) Overview

Connecting wire 18AWG 16/30 PVC 1000FT SPOOL SPECIAL

3075 (SPECIAL Q-00021555) Parametric

Parameter Name	Attribute value
Maker	Alpha Wire
Product Category	Connecting line
Shipping restrictions	Mouser does not currently sell this product.
Wire Gauge – American Wire Gauge (AWG)	18 AWG
Insulation Materials	Polyvinyl Chloride (PVC)
Voltage rating	600 V
maximum temperature	+ 105 C
type	High Temperature, High Voltage
series	3075
Wire type	Hook-Up/Lead Wire
Factory packaging quantity	1000
unit weight	4.536 kg

Preview

Download Datasheet

View All

Hook-Up Wire

Everything You Need

to Hook Up Anything

he broad range of hook-up

wire from Alpha Wire means

you will find the wire exactly

suited to your application—

whether it’s as straightforward

as a control cabinet in a

protected environment or as

specialized as a machine tool

on the factory floor, a high-

temperature oven, or off-road

construction equipment. Our

hook-up wire is available in a

variety of insulation to meet

your needs for temperature,

ability to withstand wear and

abrasion, electrical properties,

and resistance to oil, solvents,

and chemicals.

•

Stranded and solid copper

conductors, bare or tinned,

with other platings available

for special application needs

•

Broad range of insulations

•

Color-coded insulation for

easy circuit identification

•

UL, CSA, and mil-spec

compliance

•

Convenient put-ups as

short as 100 feet

•

Excellent uniformity for

easy handling, stripping,

and termination

Choice of Insulations to Meet Temperature Range and Mechanical and Environmental Requirements

Insulation

PVC

Material

Polyvinyl chloride

Temperature Range

-55°C to +105°C

Features

General-purpose insulation

Good abrasion resistance

Excellent flame resistance

Better abrasion and cut-through resistance than standard PVC

Improved temperature and solder iron resistance over standard PVC

Used in high-density wiring

High temperature

Chemically inert: excellent chemical and solvent resistance

Excellent electrical properties

Higher temperature rating than PVC

High-voltage material

Excellent flexibility

Excellent dielectric strength and resistance to radiation, corona, and ozone

Widely used in wire wrap applications

High-temperature applications, such as heat-treating furnaces,

kilns, and food service equipment

Excellent thermal stability

Modified polyphenylene ether insulation (mPPE)

Lighter, tougher, and more durable than PVC

Meets RoHS and WEEE requirements, 100% recyclable

45% smaller diameter, 40% lighter

All the environmental benefits and abrasion resistance

characteristics of EcoWire; 100% recyclable

Excellent resistance to oils, chemicals, solvents, and fuels

Meets ISO 6722 for thin-wall and ultra-thin wall wire

Page No.

XL-PVC

Cross-linked PVC

-55°C to +105°C

7, 8

PTFE

XLPE

Silicone

PDVF

ETFE

Polytetrafluoroethylene

Cross-linked polyethylene

Silicone

Polyvinylidene fluoride

Ethylene tetrafluoroethylene

Mica glass

-55°C to +200°C

-55°C to +125°C

-40°C to +150°C

-40°C to +125°C

-70°C to +150°C

+450°C

mPPE

Modified

polyphenylene ether

-40°C to +105°C

mPPE*

*EcoWire® Plus

Modified

polyphenylene ether

-40°C to +110°C

Choice of Features and Approvals by Application

Voltage

UL/CSA

150

XL-PVC

XLPE

PVC

300

SR-PVC

XL-PVC

XLPE

PTFE

PVC

600

XLPE

Silicone

10,000+

Military

250

600

PTFE

XL-PVC

PVC

PTFE

XL-PVC

1000

PVC

XLPE

PTFE

3000

Wire Wrap

PVDF

ETFE

Ribbon Cable: 5 to 30 Conductors

150/600

300/1000

Bus Bar Wire

—

30 – 12

A-A59551

PVC

26 – 22

—

UL 2713, 2555

MIL-W-16878/1 (Types B & C)

-55°C to +80°C

-55°C to +105°C

—

30 – 24

UL 1422, 1423

UL 1516, 1523

-40°C to +125°C

-70°C to +150°C

XLPE

32 – 22

26 – 16

32 – 14

14 – 8

30 – 10

26 – 16

24 – 12

22 – 18

24 – 8

18 – 10

30 – 26

—

26 – 18

—

24 – 18

—

MIL-DTL-16787/6 (Type ET)

MIL-DTL-16878/1 (Type B)

MIL-W-76B Type HW

MIL-DTL-16878/4 (Type E)

MIL-DTL-16878/1 (Type C)

MIL-DTL-16878/5 (Type EE)

MIL-DTL-16878/1 (Type D)

-60°C to +200°C

-55°C to +105°C

-20°C to +80°C

-60°C to +200°C

-55°C to +105°C

-40°C to +80°C

-55°C to +105°C

-60°C to +200°C

-55°C to +105°C

Silicone

26 – 16

22 – 18

30 – 16

26 – 16

22 – 18

24 – 8

24 – 10

8 – 4/0

18 – 10

20 – 2/0

22 – 4/0

22 – 2

—

24 – 16

—

26 – 10

—

CSA AWM I A/B FT1

UL AWM 1429

UL AWM 3265

UL AWM 1569

UL AWM 1007

CSA TR-64

UL AWM 1061

UL AWM 1430

UL AWM 3266

UL AWM 1180

UL AWM 1015, 1230

UL MTW, THW, TW

UL AWM 1242, 1284

UL AWM 3271

UL AWM 3173, 3195, 3196,

3300 SIS Rated

UL AWM 3212, 3213, 3214

UL AWM 3239

CSA AWM I A/B FT2

CSA CL 1251 XLPE

CSA TEW-105

CSA AWM I A/B FT1

CSA REW XL-PVC

CSA CL 1252 XLPE

CSA AWM I A/B FT1

-55°C to +105°C

-55°C to +80°C

-55°C to +125°C

-40°C to +105°C

-40°C to +80°C

-40°C to +90°C

-10°C to +80°C

-55°C to +105°C

-55°C to +125°C

-60°C to +200°C

-20°C to +105°C

-55°C to +125°C

-40°C to +150°C

Insulation

Wire Range (AWG)

Stranded

Solid

Approvals

CSA

Temperature

Range

Page No.

Bulk Hook-Up Wire

We support your high-volume

needs with large put-ups for a

wide range of both military and

UL style PVC hook-up wire.

Bulk PVC wire options include:

• Stranded and solid conductors

• Bare or tinned copper

• Standard and semirigid PVC

• Variety of temperature ranges

For additional information,

visit

www.alphawire.com

600 V, mPPE Wire

EcoWire®

Innovative EcoWire combines

increased performance with

a minimized environmental

impact. Compared to

PVC wire, EcoWire’s modified

polyphenylene ether

(mPPE) insulation allows

wire that are:

Up to 45% smaller in

diameter

Up to 40% lighter

Non-halogenated, with

no heavy metal pigments

100% recyclable

UL AWM 11028 VW-1

CSA AWM I A/B FT1

IEC 60332-2 Flame Behavior

RoHS/RoHS2 Compliant

REACH Compliant

Halogen-Free

CE compliant

-40°C to +105°C

Stranded or solid tinned

copper conductors

Modified polyphenylene

ether insulation

Part No.

6710

6711

6712

6713

6714

6715

6715S

6716

6717

6717S

6718

6719

Conductor Size

AWG

0.08

0.13

0.20

0.32

0.52

0.82

1.30

2.08

3.30

5.26

Stranding

AWG

7/36

7 x 0.12

7/34

7 x 0.16

7/32

7 x 0.20

7/30

7 x 0.25

10/30

10 x 0.25

16/30

16 x 0.25

Solid

26/30

26 x 0.25

41/30

41 x 0.25

Solid

65/30

65 x 0.25

105/30

105 x 0.25

Insulation Thickness

Inch

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.011

0.28

0.011

0.28

0.011

0.28

0.012

0.30

0.012

0.30

Wire Diameter

Inch

0.034

0.86

0.038

0.97

0.043

1.09

0.049

1.24

0.055

1.40

0.067

1.70

0.059

1.50

0.081

2.06

0.096

2.44

0.086

2.18

0.117

2.97

0.142

3.66

White, Black, Red, Green, Yellow, Blue, Brown, Orange, Slate, Violet, Yellow/Green, Dark Blue

Availability

100 ft (30.5 m)

1000 ft (305 m)

5000 ft (1524 m)

25,000 ft (7620 m) drum

EcoWire and EcoWire Plus

are part of the EcoGen family

of weight- and space-saving,

environmentally friendly wires

and cables.

300 V, mPPE Wire

EcoWire® Plus

All the benefits of EcoWire,

plus higher temperature

range and additional fluid

resistance for demanding

factory applications.

ISO 6722 Ultra Thin Wall

ISO 6722 Thin Wall

RoHS Compliant

REACH Compliant

Halogen-Free

CE compliant

-40°C to +110°C

Stranded bare

copper conductors

Modified polyphenylene

ether insulation

Part

No.

6820

6821

6822

6823

6824

6825

6826

6827

6828

6829

6830

6831

AWG

Conductor Size

ISO mm Equiv.

0.09

—

0.14

0.13

0.23

0.22

0.35

0.56

0.5

0.81

0.75

0.96

1.23

—

1.53

1.5

1.94

3.08

4.92

Stranding

AWG

7/36

7 x 0.12

7/34

7 x 0.16

7/32

7 x 0.20

7/30

7 x 0.25

7/28

7 x 0.32

19/0.0092 19 x 0.23

19/30

19 x 0.25

19/29

19 x 0.29

19/28

19 x 0.32

19/27

19 x 0.36

19/25

19 x 0.46

19/23

19 x 0.57

Insulation Thickness

Inch

0.008

0.20

0.008

0.20

0.008

0.20

0.008

0.20

0.008

0.20

0.008

0.20

0.008

0.20

0.010

0.24

0.010

0.24

0.012

0.30

0.015

0.38

0.017

0.43

Wire Diameter

Inch

0.031

0.79

0.035

0.89

0.040

1.02

0.046

1.17

0.054

1.37

0.062

1.57

0.066

1.68

0.077

1.96

0.083

2.11

0.095

2.41

0.120

3.05

0.147

3.73

White, Black, Red, Green, Yellow, Blue, Brown, Orange, Green/Yellow

Availability

100 ft (30.5 m)

1000 ft (305 m)

300 V, PVC Wire

UL AWM 1007, 1581, 1569 VW-1

CSA AWM I A/B FT1

CSA TR-64 FT1

-40°C to +105°C

(AWM 1569, CSA AWM)

-40°C to +90°C (CSA TR-64)

-40°C to +80°C

(AWM 1007, 1581)

Stranded or solid tinned

copper conductor

PVC insulation

Part No.

3047

3048

3049

3050/1

3050

892419†

3051/1

3051

892219†

3053

3053/1

892007†

892019†

3055

3055/1

891819†

3057/1

3057

891441†

891265*†

891000*†

Wire Size

AWG

0.06

0.09

0.14

0.20

0.23

0.24

0.32

0.35

0.38

0.51

0.52

0.56

0.62

0.81

0.82

0.96

1.31

1.32

2.08

3.30

5.32

Stranding

AWG

7/38

7/36

7/34

Solid

7/32

19/36

Solid

7/30

19/34

10/30

Solid

7/28

19/32

16/30

Solid

19/30

Solid

26/30

41/30

65/30

105/30

7 x 0.10

7 x 0.13

7 x 0.16

1 x 0.51

7 x 0.20

19 x 0.13

1 x 0.64

7 x 0.25

19 x 0.16

10 x 0.25

1 x 0.81

7 x 0.32

19 x 0.20

16 x 0.25

1 x 1.02

19 x 0.25

1 x 1.29

26 x 0.25

41 x 0.25

65 x 0.25

105 x 0.25

Availability

100 ft (30.5 m)

1000 ft (305 m)

Insulation

Thickness

Inch

0.016 0.41

Nominal

Diameter

Inch

0.044

1.12

0.047

1.19

0.051

1.30

0.052

1.32

0.056

1.42

0.057

1.45

0.057

1.45

0.062

1.57

0.064

1.63

0.069

1.75

0.064

1.63

0.070

1.78

0.072

1.83

0.079

2.01

0.072

1.83

0.082

2.08

0.083

2.11

0.092

2.34

0.106

2.69

0.125

3.18

0.150

3.81

Colors

Z1, 1 - 10

Z1, 1 – 19, 28, 30

Z2, 0 - 9

Z1, 1 - 10

Z1, 1 – 19, 28, 30

Z2, 0 - 9

Z1, 1 – 19, 28, 30

Z1, 1 - 10

Z2, 0 - 9

Z1, 1 – 19, 28, 30

Z1, 1 - 10

Z2, 0 - 9

Z1, 1 - 10

Z1, 1 – 19, 28, 30

Z2, 0 - 9

Z1 Insulation Colors:

1 White • 2 Black • 3 Red • 4 Green • 5 Yellow • 6 Blue • 7 Brown • 8 Orange • 9 Slate

• 10 Violet • 11 White/Black • 12 White/Red • 13 White/Green • 14 White/Yellow • 15 White/Blue • 16 White/

Brown • 17 White/Orange • 18 White/Slate • 19 White/Violet • 28 Green/Yellow • 29 Yellow/Green • 30 Pink

Z2 Insulation Colors:

0 Black • 1 Brown • 2 Red • 3 Orange • 4 Yellow • 5 Green • 6 Blue • 7 Violet • 8 Slate •

9 White

†These wires also available in 500 ft (152 m) put-ups.

300 V, Semirigid PVC Wire

UL AWM 1061 VW-1

CSA AWM I A/B FT1

-10°C to +80°C

Stranded or solid tinned

copper conductor

Semirigid PVC insulation

Part No.

422807

422801

422607

422601

3250

3251

422010

3252

422001

421816

3253

421626

3254

Wire Size

AWG

0.09

0.08

0.14

0.13

0.23

0.35

0.51

0.56

0.52

0.81

0.90

1.32

1.43

Stranding

AWG

7/36

Solid

7/34

Solid

7/32

7/30

10/30

7/28

Solid

16/30

7/26

26/30

7/24

7 x 0.13

1 x 0.32

7 x 0.16

1 x 0.40

7 x 0.20

7 x 0.25

10 x 0.25

7 x 0.32

1 x 0.81

16 x 0.25

7 x 0.40

26 x 0.25

7 x 0.51

Insulation

Thickness

Inch

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

0.010

0.25

Nominal

Diameter

Inch

0.035

0.89

0.033

0.84

0.039

0.99

0.036

0.91

0.044

1.12

0.050

1.27

0.057

1.45

0.058

1.47

0.052

1.32

0.067

1.70

0.068

1.73

0.080

2.03

0.080

2.03

Colors

Availability

100 ft (30.5 m)

1000 ft (305 m)

Z1 Insulation Colors:

1 White • 2 Black • 3 Red • 4 Green • 5 Yellow • 6 Blue • 7 Brown • 8 Orange • 9 Slate •

10 Violet

Z2 Insulation Colors:

0 Black • 1 Brown • 2 Red • 3 Orange • 4 Yellow • 5 Green • 6 Blue • 7 Violet • 8 Slate •

9 White

Recommended Resources

Transistor time relay circuit three

High voltage mercury lamp wiring method

Low-power three-terminal voltage regulator application circuit diagram

Split phase amplifier circuit diagram

Digital speed measuring circuit

Transistor AC voltage regulator circuit

Shortcut: A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 AA AB AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR AS AT AU AV AW AX AY AZ B0 B1 B2 B3 B4 B5 B6 B7 B8 B9 BA BB BC BD BE BF BG BH BI BJ BK BL BM BN BO BP BQ BR BS BT BU BV BW BX BY BZ C0 C1 C2 C3 C4 C5 C6 C7 C8 C9 CA CB CC CD CE CF CG CH CI CJ CK CL CM CN CO CP CQ CR CS CT CU CV CW CX CY CZ D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 DA DB DC DD DE DF DG DH DI DJ DK DL DM DN DO DP DQ DR DS DT DU DV DW DX DZ

Popular Components

M85049/10-54S
0505Y200P600BQT
H10A-FREQ-15-3OT-100100-TR
890-001-51SS-0B1-18T
72255-9445TRALF
405-0018-02M-P30-N10
TNPW080521R0BEEC
C1608X7R1E104K
BAV170W_R1_00001
UF150_R2_10001
1N751AT/B
07D680K
