Data Sheet
FUJITSU Component Wireless Modules
FWM8BLZ02A-109047
FUJITSU Component Wireless Modules
¬
Bluetooth
Version 4.1 Sensor Embedded Beacon
FWM8BLZ02A-109047
Overview
A
Bluetooth
Version 4.1 sensor embedded beacon with accelerometer and temperature sensors
Features
■
Selection of 3 types of sensor data reporting
• Via Fujitsu Components Data Communication (FDC)*
Beacon outputs sensor data in preset intervals
• Using Sensor Value Characteristic**
Data is stored in sensor module and central equipment accesses the module to read data
■
OTA configuration mode
In
Over-The-Air
(OTA) config mode the beacon unit settings and data can be re-configured by
connecting to the central device wirelessly
■
LED status
The Beacon status can be checked by the LED indicator
■
Long operation life with coin cell battery
The Beacon is able to operate for more than 2 years with a CR2450 coin cell battery at 1 second
advertise interval
Applications
• State monitors (logistics, nursing services, etc.)
• Front-end device of IoT platforms
Notes: *: Fujitsu Component unique data transmission profile, equipped in the beacon as standard
**:Sensor Value Characteristic is a function set in ‘Characteristic’, GATT specification of Bluetooth Smart, to have central equipment read.
Sensor Value Characteristic is Fujitsu Component unique name
RoHS compliant
FWM8BLZ02A-109047
Item
Part number
Antenna
Bluetooth
technology
Transmit power
Power supply
Operating temperature / humidity
Sense interval
Sensor
Dimensions / Weight
Certifications
Acceleration sensor
Temperature sensor
Specifications
FWM8BLZ02A-109047
Pattern antenna
Conforms to
Bluetooth
Version 4.1 technology
-16, -12, -8, -4, 0, +4 dBm (changeable by command)
CR family coin type lithium battery CR2450 (not included)
-300C to +600C, 20 to 80% RH
Typical 990ms (range 99 to 60,000ms)
Range of detection: ±16G, accuracy: ±3%
Range of detection: -30°C to +60°C, accuracy : ±0.3°C
40 x 31 x 12mm / Approx. 10g (without battery)
Bluetooth
qualification (QDID), Radio Act (Japan), FCC, IC, CE
Page 1 of 2
ASIA PACIFIC: www.fujitsu.com/sg/products/devices/components
EMEA: www.fujitsu.com/uk/components
AMERICAS: http://us.fujitsu.com/components
Data Sheet
FUJITSU Component Wireless Modules
FWM8BLZ02A-109047
■
Battery specifications
Note: Use of coin type lithium battery CR2450
Please use the battery meets Figure 1 (minus electrode height min.
0.9mm, diameter max. 23 mm) to keep enough clearance between
beacon holder and battery.
Max.
φ23
Figure 1
Min. 0.9
Unit: mm
■
Dimensions
FWM8BLZ02A-109047
40.0
(5.3)
12.0
Hole for strap or fixing screw
Status indication LED (Red)
31.0
φ
0
3.
(5.3)
Power supply switch
Unit: mm
Mode switching button
Note: The
Bluetooth
¬
word mark and logos are registered trademarks owened by Bluetooth SIG, Inc. and any use of such marks by Fujitsu Component is under license. Other
trademarks and trade names are those of their respective oweners.
