Terminal Systems
DCS-2
2.8 mm female and male terminals
Features
•
DCS-2 technology
•
Long auxiliary steel spring in CrNi
•
5 mm pitch for unsealed
applications
•
6 mm pitch for sealed applications
with single wire seal
•
Single wire seal versions available
•
Crimp code on terminal
•
Suitable for secondary lock
•
Selective gold-plated versions
available
Performance characteristics*
•
Contact resistance:
•
Contact mating force:
•
Contact unmating force:
< 2 mΩ
<9N
< 5N
Packing
•
No. of terminals per reel: Consult us
•
No. of reels per packing: Consult us
•
Current carrying capacity with
2.5 mm
2
wire:
at 23°C up to approx.:
33 A
at 85°C up to approx.:
22 A
at 100°C up to approx.:
17 A
* Mated with 2.8 x 0.8 mm DCS-2 male
terminal (Sn)
Tooling
•
Manual crimping tool:
•
Mini applicator:
Consult us
Consult us
Part Numbers
Type
Wire size range
(in mm2)
Min.
Max.
Insulation Ø
(in mm)
Max.
Material
Plating
6 001 28 11
6 001 28 31
6 001 28 41
6 001 29 11 (SWS)
6 001 29 31 (SWS)
6 001 29 41 (SWS)
6 001 40 11
6 001 40 31
6 001 40 41
6 011 06 11
6 011 06 31
6 011 06 41
Female
Female
Female
Female
Female
Female
Female
Female
Female
0.20
0.50
> 1.00
0.20
0.50
> 1.00
0.20
0.50
> 1.00
0.35
1.00
2.50
0.35
1.00
2.50
0.35
1.00
2.50
1.30
2.00
3.00
1.30
2.00
3.00
1.30
2.00
3.00
CuSn/CrNi
CuSn/CrNi
CuSn/CrNi
CuSn/CrNi
CuSn/CrNi
CuSn/CrNi
CuFe/CrNi
CuFe/CrNi
CuFe/CrNi
CuFe/CrNi
CuFe/CrNi
CuFe/CrNi
Sn
Sn
Sn
Sn
Sn
Sn
Sn
Sn
Sn
Sn
Sn
Rev 06/04
Male
Male
Male
0.20
0.50
> 1.00
0.35
1.00
2.50
1.30
2.00
3.00
Sn
SWS: Single Wire Seal
1.57
