Western Digital
®
PC SN520 NVMe
™
SSD
Fueling Innovation
Design Flexibility
With future-ready, scalable NVMe architecture, the Western Digital
PC SN520 NVMe SSD offers a robust solution to fuel generations of innovative
IoT applications. Scalable NVMe offers a significant performance increase over
SATA SSDs while further optimizing low power consumption to the low level
of 2.5mW.
This NVMe SSD enables greater design flexibility for IoT and embedded
customers, who seek a cost effective, small form factor, reliable and rugged
storage device with low capacity points from 128GB to 512GB.
Robust Construction Suited for IoT
The Western Digital PC SN520 NVMe SSD, supporting PCIe Gen3 x2,
is designed for applications that have a limited number of PCIe lanes available
for storage, however, require both high performance and low power. Partners
that could benefit from NVMe technology include:
•
Commercial:
Interactive kiosks, ATMs and Point-of-Sales (POS), Multi-Functional
Printers (MFP) and industries that require high-volume transaction processing
•
Edge Equipment and IoT Gateway:
Such as network equipment, industrial
machinery, medical equipment, or embedded PC that need the high
capacities to capture the floor’s and sensors’ data and the high IOPS
to support the system’s data analytics
•
Media Content Delivery and Streaming:
In-flight entertainment systems,
train control and monitoring systems, data recorder and video surveillance
that require high capacity and reliability
WESTERN DIGITAL PC SN520 NVMe SSD
KEY BENEFITS & FEATURES
READ SPEEDS UP TO 1,700MB/S AND LOW
POWER CONSUMPTION LEVERAGES BOTH
THE PCIe GEN3 x2 INTERFACE, AS WELL AS
SOPHISTICATED NVMe POWER MANAGEMENT
128GB-512GB CAPACITIES AVAILABLE IN THREE
SMALL FORM FACTORS: M.2 2230, M.2 2242,
M.2 2280
ENDURANCE OF UP TO 300 TBW
5 YEAR LIMITED WARRANTY
Versatile Options for IoT
Equipped with a fully integrated solution which includes in-house controller, 64-layer 3D NAND, firmware, and testing,
Western Digital provides longevity, supply and a robust and reliable design.
Designed with Western Digital’s in-house tiered-caching NVMe architecture, the Western Digital PC SN520 NVMe SSD delivers
high performance with sequential read and write speeds up to 1,700MB/s and 1,400MB/s respectively and high endurance up
to 300 TBW, all of which are available in a variety of small form factors: M.2 2230, M.2 2242, M.2 2280.
Summary
Western Digital PC SN520 NVMe SSD, in variety of small, single-sided form factors such as M.2 2230, M.2 2242 and M.2 2280,
enables customers to build ultra-thin, ultra-small boards and systems that address multiple IoT segments, without sacrificing
performance and power consumption.
Western Digital PC SN520 NVMe SSD
Specifications are subject to change
Form Factors
Interface
Formatted Capacities
1
Performance
2
Sequential Read up to (MB/s)
Sequential Write up to (MB/s)
Random Read up to (IOPS)
Random Write up to (IOPS)
Endurance
3
(TBW)
Power
Peak Power (10µs) (A)
Avg. Active Power
4,5
(mW)
Low Power (PS3)
5
(mW)
Sleep (PS4)
5
(mW)
Supply Voltage (V / ±5%)
Reliability
MTTF
6
Environmental
Operating Temperature
7
Non-operating Temperature
8
Operating Vibration
Non-operating Vibration
Shock
Certifications
Limited Warranty
9
Physical Dimensions
Width
Length
Thickness (max)
Weight
SKU
SDAPTUW-128G
SDAPTUW-256G
SDAPTUW-512G
SDAPMUW-128G
SDAPMUW-256G
SDAPMUW-512G
SDAPNUW-128G
SDAPNUW-256G
SDAPNUW-512G
Form Factor
M.2 2230 S3-B-M
M.2 2230 S3-B-M
M.2 2230 S3-B-M
M.2 2242 S3-B-M
M.2 2242 S3-B-M
M.2 2242 S3-B-M
M.2 2280 S3-B-M
M.2 2280 S3-B-M
M.2 2280 S3-B-M
1
M.2 2230, M.2 2242, M.2 2280
PCIe Gen3 x2 NVMe v1.3
128GB, 256GB, 512GB
128GB
1,500
800
95K
90K
100
128GB
1.2
75
25
2.5
3.3
256GB
1,700
1,300
220K
175K
200
256GB
1.4
75
25
2.5
3.3
512GB
1,700
1,400
270K
280K
300
512GB
1.8
75
25
2.5
3.3
Up to 1.752M hours
32ºF to 158ºF (0ºC to 70ºC)
-67ºF to 185ºF (-55ºC to 85ºC)
5 gRMS, 10-2000 Hz, 3 axes
4.9 gRMS, 7-800 Hz, 3 axes
1,500G @0.5 ms half sine
FCC, UL, TUV, KCC, BSMI, VCCI, C-Tick
5 years
22mm ±0.15mm
2230: 30mm ±0.15mm; 2242: 42mm ±0.15mm; 2280: 80mm ±0.15mm
2.38mm
2230: 3.5g ±1g; 2242: 4.0g ±1g; 2280: 6.5g ±1g
Capacity
128GB
256GB
512GB
128GB
256GB
512GB
128GB
256GB
512GB
As used for storage capacity, one gigabyte (GB) = one billion bytes and one terabyte (TB) = one trillion bytes.
Total accessible capacity varies depending on operating environment.
Test Conditions: Performance is based on the CrystalDiskMark 5.2.2 benchmark using a 1000MB LBA range ASUS
Z170A desktop with Intel® i7-6700K 4.0GHz, 8GB 2133MHz DDR4. Windows 10 Pro 64-bit using Microsoft StorNVMe
driver, secondary drive. Performance may vary based on host device. 1 MB = 1,000,000 bytes. IOPS = input/output
operations per second.
TBW (terabytes written) values calculated using JEDEC client workload (JESD219) and vary by product capacity.
Measured using MobileMark™ 2014 on HP EliteBook X360 1030 G2 with i7-7600U, 8GB RAM. Windows 10 Pro,
64-bit RS3 using Microsoft StorNVMe driver, primary drive.
Power measurements at 25°C.
MTTF = Mean Time To Failure based on internal testing using Telcordia stress part testing. MTTF is based on a sample
population and is estimated by statistical measurements and acceleration algorithms. MTTF does not predict an
individual drive’s reliability and does not constitute a warranty. (Telecordia SR-332, GB, 40°C)
Operational temperature as reported by device (composite temperature.)
Non-operational storage temperature does not guarantee data retention.
5 years or Max Endurance (TBW) limit, whichever occurs first. 5 year warranty in regions not recognizing “limited.”
See http:/
/support.wdc.com for more details.
2
3
Western Digital
5601 Great Oaks Parkway
San Jose, CA 95119, USA
www.wdc.com
Western Digital and the Western Digital logo are the registered trademarks of
Western Digital Corporation or it’s affiliates in the U.S. and/or other countries.
All marks are the property of their respective owners. Pictures shown may vary
from actual products. The NVMe
™
word mark is a trademark of NVM Express, Inc.
4
5
6
7
8
9
Product specifications subject to change without notice. Not all products are available in all regions of the world.
©2018 Western Digital Corporation or its affiliates.
