F-219
SS5–20–3.00–L–D–K–TR
SS5–10–3.00–L–D–K–TR
ST5–20–1.50–L–D–P–TR
ST5–10–1.00–L–D–P–TR
SS5–20–3.50–L–D–K–TR
ST5–20–1.00–L–D–P–TR
(0.50 mm) .0197"
SS5, ST5 SERIES
ULTRA-FINE PITCH SOCKET
SS5 Mates with:
ST5
ST5 Mates with:
SS5
SS5
NO. OF
POSITIONS
LEAD
STYLE
PLATING
OPTION
D
K
TR
(Required
in callout)
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?SS5 or
www.samtec.com?ST5
Insulator Material:
Black LCP
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C
Current Rating:
1.6 A per pin
(2 pins powered)
RoHS Compliant:
Yes
–10, –15, –20,
–30, –40, –50,
–60, –70, –80
(Per Row)
(4.35)
.171
= 3.00 mm
–3.00
–3.50
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
(Required in callout)
= 3.50 mm
01
= (3.50 mm) .138" DIA
Polyimide Film
Pick & Place Pad
–K
= Tape &
Reel
–TR
(0.50)
.0197
02
LEAD
STYLE
A
(2.85)
.112
(3.35)
.132
B
(3.50)
.138
(4.00)
.157
–3.00
–3.50
POWER/SIGNAL
APPLICATION
No. of
positions
per row x
(0.50) .0197
+ (3.54) .139
(3.50)
.138
(0.15)
.006
A
(5.00)
.197
B
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
HIGH-SPEED CHANNEL PERFORMANCE
SS5/ST5 @ 4 mm Mated Stack Height
Rating based on Samtec reference channel.
For full SI performance data visit Samtec.com
or contact SIG@samtec.com
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
Compatible with
UMPT/UMPS for flexible
two-piece power/signal solutions
ST5
NO. OF
POSITIONS
LEAD
STYLE
PLATING
OPTION
D
P
TR
(Required
in callout)
MATED HEIGHT*
ST5
LEAD
STYLE
SS5 LEAD STYLE
–3.00
–3.50
–1.00
(4.00) .157 (4.50) .177
–1.50
(4.50) .177 (5.00) .197
*Processing conditions will affect
mated height.
–10, –15, –20,
–30, –40, –50,
–60, –70, –80
(Per Row)
No. of
positions
per row x
(0.50) .0197
+ (1.40) .055
(3.70)
.146
02
= 1.00 mm
–1.00
–1.50
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
–L
(Required in callout)
= 1.50 mm
= Pick & Place Pad
–P
= Tape &
Reel
–TR
ALSO AVAILABLE
(MOQ Required)
• Other lead styles
01
LEAD
STYLE
A
(1.00)
.039
(1.50)
.059
B
(3.08)
.121
(3.58)
.141
–1.00
–1.50
(1.46)
.057
A
(4.00)
.157
(0.50)
.0197
B
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(0.20)
.008
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
