Rev.
Ø
Description of revision
Refer from QP-14145A (FAW-1233-TX) and use -01 for
and -02 for 200mm.
Date
25/7/2015
By
Wittaya
A-Side
(10.0)
CONNECTOR
3
7
30
L
(10.0)
B-Side
7
1
CONNECTOR
Description
PIN No.
L (mm)
100.0±5.0
200.0±5.0
300.0±10.0
400.0±15.0
500.0±15.0
FAW-1233-01
FAW-1233-02
FAW-1233-03
FAW-1233-04
FAW-1233-05
6
5
1
2
3
4
5
2
4
Fig. 1 Applying UV resin
A-side
connector
Pin No.
1
2
3
4
5
6
7
WIRING
B-side
connector
Pin No.
30
29
28
27
26
25
24
30
NOTE.
24
25
26
27
Test:
28
Insulation resistance:Min 50M ohms.(DC.300V Megaohm tester,0.1 SEC)
29
Dielectric strength: No break down.(AC100V 0.1 SEC)
Continuity wire collation: To be correct as shown in wiring.
30
GND
1. Apply UV resin at the end of connector to cover cables
both sides of the cable assembly (Fig.1).
PIN No.
(6.0)
(6.0)
1
8
(2.0)
8
7
6
5
4
3
2
1
UV RESIN
TAPE
TAPE
FLAT COPPER WIRE
PULL BAR
SHIELD PLATE
CONNECTOR
CABLE
DESCRIPTION
2
2
1
4
2
2
2
30
Q'TY
LOCTITE P/N : 352 LIGHT CURE
CHUKOH P/N: ASF-116T
CHUKOH P/N: SEF-110
GROUND BAR
I-PEX P/N : 2766-0301
I-PEX P/N : 2764-0301-002
I-PEX P/N : 20634-130T-02
UL10231 AWG40 MCX (Z=50ohm)
REMARK
7
6
5
4
3
2
1
GND
ITEM
Title
FJK P/N: FAW-1233-XX
Drawn by
Drawing No.
Date
Unit:mm
