MBR(F,B)1035 thru MBR(F,B)1060
Vishay General Semiconductor
Schottky Barrier Rectifier
TO-220AC
ITO-220AC
FEATURES
• Low power loss, high efficiency
• Low forward voltage drop
• High forward surge capability
• High frequency operation
2
MBR10xx
PIN 1
PIN 2
2
1
MBRF10xx
PIN 1
1
• Meets MSL level 1, per J-STD-020C, LF maximum
peak of 245 °C (for TO-263AB package)
• Solder dip 260 °C, 40 s (for TO-220AC and
ITO-220AC package)
• Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
CASE
PIN 2
TO-263AB
K
2
1
MBRB10xx
PIN 1
PIN 2
K
HEATSINK
TYPICAL APPLICATIONS
For use in low voltage, high frequency rectifier of
switching mode power supplies, freewheeling diodes,
dc-to-dc converters and polarity protection application.
MECHANICAL DATA
Case:
TO-220AC, ITO-220AC, TO-263AB
Epoxy meets UL 94V-0 flammability rating
Terminals:
Matte tin plated leads, solderable per
J-STD-002B and JESD22-B102D
E3 suffix for commercial grade, meets JESD 201 class
1A whisker test, HE3 suffix for high reliability grade
(AEC Q101 qualified), meets JESD 201 class 2
whisker test
Polarity:
As marked
Mounting Torque:
10 in-lbs maximum
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
T
J
max.
10 A
35 V to 60 V
150 A
0.57 V, 0.70 V
150 °C
MAXIMUM RATINGS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum average forward rectified current (Fig. 1)
Peak forward surge current 8.3 ms single half sine-wave
superimposed on rated load per leg
Peak repetitive reverse current per leg at t
p
= 2.0 µs, 1 kHz
Voltage rate of change (rated V
R
)
Operating junction temperature range
Storage temperature range
Isolation voltage (ITO-220AC only)
from terminal to heatsink t = 1 min
SYMBOL
V
RRM
I
F(AV)
I
FSM
I
RRM
dV/dt
T
J
T
STG
V
AC
1.0
10000
- 65 to + 150
- 65 to + 175
1500
MBR1035
35
MBR1045
45
10
150
0.5
MBR1050
50
MBR1060
60
UNIT
V
A
A
A
V/µs
°C
°C
V
Document Number: 88669
Revision: 08-Nov-07
www.vishay.com
1
MBR(F,B)1035 thru MBR(F,B)1060
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous
forward voltage per leg
(1)
TEST CONDITIONS
I
F
= 10 A
I
F
= 10 A
I
F
= 20 A
I
F
= 20 A
T
J
= 25 °C
T
J
= 125 °C
T
J
= 25 °C
T
J
= 125 °C
T
J
= 25 °C
T
J
= 125 °C
SYMBOL
MBR1035
MBR1045
MBR1050
MBR1060
UNIT
-
0.57
0.84
0.72
0.10
15
0.80
0.70
0.95
0.85
V
F
V
Maximum instantaneous
reverse current at rated DC
blocking voltage
(1)
Note:
(1) Pulse test: 300 µs pulse width, 1 % duty cycle
I
R
mA
THERMAL CHARACTERISTICS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Maximum thermal resistance from junction to case
SYMBOL
R
θJC
MBR
2.0
MBRF
4.0
MBRB
2.0
UNIT
°C/W
ORDERING INFORMATION
(Example)
PACKAGE
TO-220AC
ITO-220AC
TO-263AB
TO-263AB
TO-220AC
ITO-220AC
TO-263AB
TO-263AB
Note:
(1) Automotive grade AEC Q101 qualified
PREFERRED P/N
MBR1045-E3/45
MBRF1045-E3/45
MBRB1045-E3/45
MBRB1045-E3/81
MBR1045HE3/45
(1)
MBRF1045HE3/45
(1)
MBRB1045HE3/45
(1)
MBRB1045HE3/81
(1)
UNIT WEIGHT (g)
1.80
1.94
1.33
1.33
1.80
1.94
1.33
1.33
PACKAGE CODE
45
45
45
81
45
45
45
81
BASE QUANTITY
50/tube
50/tube
50/tube
800/reel
50/tube
50/tube
50/tube
800/reel
DELIVERY MODE
Tube
Tube
Tube
Tape reel
Tube
Tube
Tube
Tape reel
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
12
Resistive or Inductive Load
175
T
J
= T
J
max.
8.3
ms Single Half Sine-Wave
Average Forward Current (A)
10
Peak Forward Surge Current (A)
100
150
150
8
125
6
100
4
75
2
MBR1035 - MBR1045
MBR1050 - MBR1060
0
50
50
0
25
0.1
1
10
100
Case Temperature (°C)
Number
of Cycles at 60 Hz
Figure 1. Forward Current Derating Curve
Figure 2. Maximum Non-Repetitive Peak Forward Surge Current
www.vishay.com
2
Document Number: 88669
Revision: 08-Nov-07
MBR(F,B)1035 thru MBR(F,B)1060
Vishay General Semiconductor
100
10000
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
Instantaneous Forward Current (A)
10
T
J
= 150 °C
Pulse
Width
= 300
µs
1
%
Duty Cycle
1
T
J
= 25 °C
0.1
MBR1035 - MBR1045
MBR1050 - MBR1060
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
Junction Capacitance (pF)
1000
MBR1035 - MBR1045
MBR1050 - MBR1060
100
0.1
1
10
100
Instantaneous Forward
Voltage
(V)
Reverse
Voltage
(V)
Figure 3. Typical Instantaneous Forward Characteristics
Figure 5. Typical Junction Capacitance
100
100
10
T
J
= 125 °C
Transient Thermal Impedance (°C/W)
100
Instantenous Reverse Current (mA)
10
1
T
J
= 75 °C
0.1
T
J
= 25 °C
0.01
MBR1035 - MBR1045
MBR1050 - MBR1060
1
0.001
0
20
40
60
80
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse
Voltage
(%)
t - Pulse Duration (s)
Figure 4. Typical Reverse Characteristics
Figure 6. Typical Transient Thermal Impedance
Document Number: 88669
Revision: 08-Nov-07
www.vishay.com
3
MBR(F,B)1035 thru MBR(F,B)1060
Vishay General Semiconductor
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
TO-220AC
0.415 (10.54) MAX.
0.370 (9.40)
0.360 (9.14)
0.154 (3.91) DIA.
0.148 (3.74) DIA.
0.113 (2.87)
0.103 (2.62)
0.145 (3.68)
0.135 (3.43)
0.635 (16.13)
0.625 (15.87)
1
0.160 (4.06)
0.140 (3.56)
0.057 (1.45)
0.045 (1.14)
0.105 (2.67)
0.095 (2.41)
PIN 1
PIN 2
CASE
ITO-220AC
0.404 (10.26)
0.384 (9.75)
0.185 (4.70)
0.175 (4.44)
0.055 (1.39)
0.045 (1.14)
45° REF.
0.671 (17.04)
0.651 (16.54)
PIN
0.076 (1.93) REF.
0.076 (1.93) REF.
7° REF.
0.140 (3.56) DIA.
0.125 (3.17) DIA.
0.135 (3.43) DIA.
0.122 (3.08) DIA.
0.190 (4.83)
0.170 (4.32)
0.110 (2.79)
0.100 (2.54)
0.350 (8.89)
0.330 (8.38)
1.148 (29.16)
1.118 (28.40)
0.603 (15.32)
0.573 (14.55)
0.600 (15.24)
0.580 (14.73)
7° REF.
0.350 (8.89)
0.330 (8.38)
PIN
1
2
0.191 (4.85)
0.171 (4.35)
7° REF.
2
0.110 (2.79)
0.100 (2.54)
0.560 (14.22)
0.530 (13.46)
0.560 (14.22)
0.530 (13.46)
0.057 (1.45)
0.045 (1.14)
0.110 (2.79)
0.100 (2.54)
0.037 (0.94)
0.027 (0.68)
0.205 (5.20)
0.195 (4.95)
0.022 (0.56)
0.014 (0.36)
0.025 (0.64)
0.015 (0.38)
0.035 (0.89)
0.025 (0.64)
0.205 (5.21)
0.195 (4.95)
0.028 (0.71)
0.020 (0.51)
TO-263AB
0.411 (10.45)
0.380 (9.65)
0.245 (6.22)
MIN.
K
0.360 (9.14)
0.320 (8.13)
1
K
2
0.055 (1.40)
0.047 (1.19)
0.670 (17.02)
0.591 (15.00)
0.15 (3.81) MIN.
0.08 (2.032) MIN.
0.105 (2.67)
0.095 (2.41)
0.33 (8.38) MIN.
0.190 (4.83)
0.160 (4.06)
0.055 (1.40)
0.045 (1.14)
Mounting Pad Layout
0.42 (10.66) MIN.
0.624 (15.85)
0.591 (15.00)
0.037 (0.940)
0.027 (0.686)
0.105 (2.67)
0.095 (2.41)
0 to 0.01 (0 to 0.254)
0.110 (2.79)
0.090 (2.29)
0.021 (0.53)
0.014 (0.36)
0.205 (5.20)
0.195 (4.95)
0.140 (3.56)
0.110 (2.79)
www.vishay.com
4
Document Number: 88669
Revision: 08-Nov-07
