ESM
Series
ESM020
ESM030
ESM040
ESM050
ESM060
10-20
21-30
31-40
41-50
51-60
W
W
W
W
W
Tri-Mode Dimming™ (0-10 V & TRIAC/ELV)
Constant Current LED Drivers with Fast Startup Time
Input
Voltage
120 to 277
Vac
nominal
TRIAC/ELV Dimmer
Max.
Output
Power
60 W
Output
Voltage
19 to 56
Vdc
Output
Max. Case
Efficiency
Current
Temperature
280 mA
90°C
up to 87%
to 1.4 A
(measured at
typical
CC
the hot spot)
CC: Constant Current
THD
< 20%
Power
Factor
> 0.9
Dimming
Method
Dimming
Range
Startup
Time
300 ms
typical
Max
Output
Power
(W)
11.8
14.7
14.7
16.8
11.0
11.0
15.0
15.0
14.0
21.0
23.1
22.4
29.4
29.4
23.4
24.4
24.5
39.2
33.6
35.7
37.8
31.0
40.4
44.1
44.1
50.4
47.6
58.8
Forward-Phase,
1 - 100%
Reverse-Phase
(% of Iout)
& 0 - 10V
ERP Part Number
+ Dim
- Dim
Nominal
Iout
Input Voltage
(mA)
(Vac)
ESM020W: 12 to 20 W
Output Voltage
Range (Vdc)
Min
24
24
24
24
19
19
27
19
8
24
24
21
24
24
19
20.5
8
40
24
24
24
28
32
24
24
24
23
24
Max
42
42
42
42
25
25
34
34
14
42
42
32
42
42
26
26
14
56
42
42
42
33
43
42
42
42
34
42
ESM
series
0-10 V
Dimmer
+ LEDs
- LEDs
ESM020W-0280-42
ESM020W-0350-42
ESM020W-0350-42-Z1
(5)
ESM020W-0400-42
ESM020W-0440-25
ESM020W-0440-25-SS-F1B
[1]
ESM020W-0440-34-SS-F1B
[2]
ESM020W-0440-34
ESM020W-1000-14
ESM030W-0500-42
ESM030W-0550-42
ESM030W-0700-32
ESM030W-0700-42
ESM030W-0700-42-Z1
(5)
ESM030W-0900-26
ESM030W-0940-26-SS-F1B
[3]
ESM030W-1750-14
ESM040W-0700-56
ESM040W-0800-42
ESM040W-0850-42
ESM040W-0900-42
ESM040W-0940-33-SS-F1B
[4]
ESM040W-0940-43
ESM050W-1050-42
ESM050W-1050-42-Z1
(5)
ESM050W-1200-42
ESM050W-1400-34
ESM060W-1400-42
120 to 277
120 to 277
120 to 277
120 to 277
120 to 277
120 to 277
120 to 277
280
350
350
400
440
440
440
CA Title 24
120 to 277
440
120 to 277
1000
ESM030W: 21 to 30 W
120 to 277
500
120 to 277
550
120 to 277
700
120 to 277
700
120 to 277
120 to 277
120 to 277
700
900
940
Metal Case
L 106.5 x W 60.3 x H 25.2 mm
(L 4.19 x W 2.37 x H 0.99 in)
5
FEATURES
•
Compatible with TRIAC (forward-phase or leading-edge),
ELV (reverse-phase or trailing-edge) and 0-10 V dimmers
•
TRIAC and ELV dimming only at 120 Vac
•
Linear 0-10V dimming transfer function (10V=100%, 1V=10%,
0.1V=1%).
Models with the “Z1” suffix exhibit a non-linear 0-10V dimming
profile (10V to 9.1V=100%, 1V to 0.8V=1%, <0.8V dim-to-off).
•
Lifetime: 50,000 hours min at 70°C case temperature
•
Conducted and radiated EMI: Compliant with FCC CFR Title 47
Part 15 Class B (120 Vac)/Class A (277 Vac) and EN55015
(CISPR 15) at 220/230/240 Vac
•
Complies with ENERGY STAR®, DLC (DesignLight Consortium®)
and CA Title 24 technical requirements
•
IP20-rated Bottom Leads with Studs metal case with silicone-
based potting.
•
90°C maximum case hot spot temperature
•
Class 2 power supply
120 to 277
1750
ESM040W: 31 to 40 W
120 to 277
700
120 to 277
800
120 to 277
850
120 to 277
900
120 to 277
940
120 to 277
940
ESM050W: 41 to 50 W
120 to 277
1050
120 to 277
1050
120 to 277
1200
120 to 277
1400
ESM060W: 51 to 60 W
120 to 277
1400
APPLICATIONS
•
Recessed downlights
!
Residential lighting
•
Commercial lighting
!
Architecture Lighting
CHINA Operations
tel: +86-756-6266298
No. 8 Pingdong Road 2
Zhuhai, Guangdong, China 519060
Notes:
1) The ESM020W-0440-25-SS-F1B is specifically intended to drive the Cree LMH2 850
sunset module and exhibits a customized 0-10V dimming transfer function. It will not
work with any other LED or LED string.
2) The ESM020W-0440-34-SS-F1B is specifically intended to drive the Cree LMH2 1250
sunset module and exhibits a customized 0-10V dimming transfer function. It will not
work with any other LED or LED string.
3) The ESM030W-0940-26-SS-F1B is specifically intended to drive the Cree LMH2 2000
sunset module and exhibits a customized 0-10V dimming transfer function. It will not
work with any other LED or LED string.
4) The ESM040W-0940-33-SS-F1B is specifically intended to drive the Cree LMH2 3000
sunset module and exhibits a customized 0-10V dimming transfer function. It will not
work with any other LED or LED string.
5) Models with the “Z1” suffix exhibit a non-linear 0-10V dimming profile:
(10V to 9.1V=100%, 1V to 0.8V=1%, <0.8V dim-to-off).
6) For additional options of output current and output voltage, contact your sales
representative or send an email to:
SaveEnergy@erp-power.com
www.erp-power.com
SaveEnergy@erp-power.com
