+output models 1.1 MΩ to ground, - output models 1.1 MΩ to +5 vRef.
10 to 100 K (potentiometer across vRef. and signal ground, wiper to adjust)
Programming and Controls
Input
Impedance
Adjust
Resistance
Adjust Logic
Output
Voltage and
Impedance
Enable/Disable
Environmental
Operating
Coefficient
Thermal
Shock
Storage
Humidity
Altitude
Shock
Vibration
Full Load, Max Eout,
Case Temperature
Over the Specified
Temperature
Mil-Std 810, Method
503-4, Proc. II
Non-Operating,
Case Temperature
All Conditions,
Standard Package
Standard Package,
All Conditions
Nominal Input
Typical
Potentiometer
Values
0 to +5 for +Out,
+5 to 0 for - Out
T = +25°C
MΩ
Ω
+4.64 VDC for +output or +0.36 for -output = nominal Eout
+5.00 VDC ±2%, Zout = 464 Ω ±1%
-
-
0 to +0.5 disable, +2.4 to 32 enable (default = enable)
All Types
-40 to +65
±50 (±25 optional)
-40 to +65
-55 to +105
0 to 95%, non-condensing
Sea level through vacuum
VDC
°C
PPM/°C
°C
°C
-
-
Gs
Gs
Mil-Std-810, Method 20
516.5, Proc. IV
Mil-Std-810, Method 10
514.5, Fig.514.5C-3
advanced-energy.com
3
ULTRAVOLT AA SERIES
MECHANICAL SPECIFICATIONS
Drawing dimensions are in mm (in).
Volumes and Weights
cm3
Volume
54.8
g
Weight
Tolerance
Overall
Pin to Pin
Mounting Hole Location
±1.27 mm (0.050")
±0.38 mm (0.015")
±0.64 mm (0.025")
114
in3
3.34
oz
4.0
Construction
Case
RTV silicone-filled DAP box certified to
ASTM-D-5948
20 and 30 W versions are an additional 1.57 mm (0.062") in height.
-M equipped units are an additional 0.76 mm (0.030") for all dimensions.
Contact AE for drawings of models equipped with -E or -H options.
4
advanced-energy.com
ULTRAVOLT AA SERIES
INTERFACE
Connections
Pin
1
2
3
4
5
6
7
8
9
10 and 11
Function
Input-Power Ground Return
Positive Power Input
Iout Monitor
Enable/Disable
Signal Ground Return
Remote Adjust Input
+5 VDC Reference Output
HV Ground Return
Eout Monitor
HV Output
All grounds joined internally. Power-supply mounting points isolated from internal grounds by > 100 kΩ, 0.01 uF/50 V (max) on all models except -M (20 W and above),
