ChiP and VIA Packages
DCM™ Family
Isolated, Regulated DC-DC Converter Modules
For use in: Industrial and Process Control, Distributed Power, ATE, Communications,
Defense/Aerospace, Semiconductor Manufacturing Equipment (SME), Transportation.
®
S
C
US
C
NRTL
US
Description
The DCM is an isolated, highly efficient, regulated DC-DC converter
utilizing high frequency zero-voltage switching (ZVS) topology,
operating from an unregulated, wide range input to generate an
isolated output. Modular DCM converters and downstream DC-DC
products support efficient power distribution, providing superior
power system performance and connectivity from a variety of
unregulated power sources to the point of load. Leveraging the
thermal and density benefits of Vicor’s ChiP packaging technology,
the DCM ChiP module offers flexible thermal management options
with very low top and bottom side thermal impedances while the
DCM VIA module additionally provides integrated EMI filtering,
tight output voltage regulation, and a secondary-referenced
control interface while retaining the fundamental design benefits
of the conventional brick architecture.
Features & Benefits
•
Up to 600W, 43.5A continuous
•
93% peak efficiency
•
Up to 1244W/in
3
power density
•
Up to 4,242V
DC
isolation
•
ZVS high frequency switching
•
Fully operational current limit
•
OV, OC, UV, short circuit and thermal protection
•
Integrated filtering, remote or local sense, enhanced
thermal management, and tight output voltage regulation
over all lines and load conditions for DCM VIA applications
3414 VIA
3.38 x 1.40 x 0.37in
[85.9 x 35.5 x 9.4mm]
4623 ChiP
1.886 x 0.898 x 0.284in
[47.91 x 22.80 x 7.21mm]
3714 VIA
3.75 x 1.40 x 0.37in
[95.1 x 35.5 x 9.4mm]
3623 ChiP
1.524 x 0.898 x 0.284in
[38.72 x 22.80 x 7.21mm]
Family of DCM Products
Nominal
Input (V)
300
(180 – 420)
290
(160 – 420)
275
(120 – 420)
270
(160 – 420)
100
(43 – 154)
48
(36 – 75)
42
(9 – 75)
30
(9 – 50)
28
(16 – 50)
24
(18 – 36)
Package
Size
4623 ChiP or 3714 VIA
4623 ChiP
4623 ChiP
4623 ChiP or 3714 VIA
3623 ChiP
3623 ChiP or 3414 VIA
3623 ChiP
3623 ChiP
3623 ChiP or 3414 VIA
3623 ChiP
80
120
80
180
180
160
320
320
110
150
80
190
250
120
160
375
500
240
320
3.3
5
12
400
13.8
500
600
375
500
240
320
80
160
320
320
160
320
320
375
500
240
320
15
24
600
= Also Available in VIA package
Power (W) by Nominal Output Voltage (V)
28
500
36
48
500
375
500
240
320
320
375
500
240
320
160
320
320
320
160
320
320
vicorpower.com
Rev 3.5
03/2018
DCM Part Numbering
Product
Function
D
C
M
Package
Length
37
Package
Width
14
Package
Type
x
T
= Through Hole ChiP
Internal Reference
VIA: Inches x 10
B
= Board VIA
V
= Chassis VIA
C
= -20 to 100°C
[a]
T
= -40 to 100°C
[a]
M
= -55 to 100°C
[a,b]
Internal Reference
D2
H
26
D7
Product Grade
(Case Temperature)
y
T
= -40 to 125°C
M
= -55 to 125°C
Option Field
z
z
ChiP: mm x 10
DCM
=
DC-DC Converter
ChiP
00
= Analog
70
= Enhanced V
OUT
Regulation
[c]
VIA
01
= Chassis/Analog
05
= Short Pin/Analog
09
= Long Pin/Analog
[a]
High temperature power derating may apply.
M-Grade available on selected models. Consult vicorpower.com for details.
[c]
±1% output voltage regulation accuracy on selected models. Consult
vicorpower.com
for details.
[b]
Typical Application
Single DCM3714xD2H26D7yzz in Local Sense Operation, to a non-isolated regulator, and direct to load
Load 1
F
V
IN
DCM
+IN
TM
in a VIA package
+OUT
VDDE
EN
TR
-SENSE
+SENSE
C
-IN
C
OUT-EXT
-OUT
Non-isolated
Point-of-Load
Regulator
Load 2
Block Diagram
Typical 24V input to point of load.
(2)
24V
DC
DCM
48V
Cool-Power
ZVS Bucks
16V
DCM
12V
Cool-Power
ZVS Bucks
5V
vicorpower.com
Rev 3.5
03/2018
