1N5333B Series
Preferred Device
5 Watt Surmetict 40
Zener Voltage Regulators
This is a complete series of 5 Watt Zener diodes with tight limits and
better operating characteristics that reflect the superior capabilities of
silicon−oxide passivated junctions. All this in an axial lead,
transfer−molded plastic package that offers protection in all common
environmental conditions.
Features
http://onsemi.com
Cathode
Anode
•
•
•
•
•
Zener Voltage Range − 3.3 V to 200 V
ESD Rating of Class 3 (>16 kV) per Human Body Model
Surge Rating of up to 180 W @ 8.3 ms
Maximum Limits Guaranteed on up to Six Electrical Parameters
These devices are manufactured with a Pb−Free external lead
finish only*
AXIAL LEAD
CASE 17
PLASTIC
Mechanical Characteristics
CASE:
Void free, transfer−molded, thermosetting plastic
FINISH:
All external surfaces are corrosion resistant and leads are
readily solderable
MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:
230°C, 1/16 in. from the case for 10 seconds
POLARITY:
Cathode indicated by polarity band
MOUNTING POSITION:
Any
MAXIMUM RATINGS
Rating
Max. Steady State Power Dissipation
@ T
L
= 75°C, Lead Length = 3/8 in
Derate above 75°C
Operating and Storage
Temperature Range
Symbol
P
D
Value
5
40
T
J
, T
stg
−65 to
+200
Unit
W
mW/°C
°C
MARKING DIAGRAM
L
1N
53xxB
YWW
L
1N53xxB
Y
WW
= Assembly Location
= Device Code
=
(See Table Next Page)
= Year
= Work Week
Maximum ratings are those values beyond which device damage can occur.
Maximum ratings applied to the device are individual stress limit values (not
normal operating conditions) and are not valid simultaneously. If these limits
are exceeded, device functional operation is not implied, damage may occur
and reliability may be affected.
ORDERING INFORMATION
Device
1N53xxB
1N53xxBRL
1N53xxBTA*
Package
Axial Lead
Axial Lead
Axial Lead
Shipping
†
1000 Units/Box
4000/Tape & Reel
2000/Ammo Pack
*1N5361B Not Available in 2000/Ammo Pack
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
Preferred
devices are recommended choices for future use
and best overall value.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
©
Semiconductor Components Industries, LLC, 2004
1
December, 2004 − Rev. 4
Publication Order Number:
1N5333B/D
1N5333B Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless
otherwise noted, V
F
= 1.2 V Max @ I
F
= 1.0 A for all types)
Symbol
V
Z
I
ZT
Z
ZT
I
ZK
Z
ZK
I
R
V
R
I
F
V
F
I
R
DV
Z
I
ZM
Parameter
Reverse Zener Voltage @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZK
Reverse Leakage Current @ V
R
Breakdown Voltage
Forward Current
Forward Voltage @ I
F
Maximum Surge Current @ T
A
= 25°C
Reverse Zener Voltage Change
Maximum DC Zener Current
V
Z
V
R
I
R
V
F
I
ZT
V
I
F
I
Zener Voltage Regulator
http://onsemi.com
2
1N5333B Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted, V
F
= 1.2 V Max @ I
F
= 1.0 A for all types)
Zener Voltage
(Note 2)
Device
(Note 1)
Device
Marking
V
Z
(Volts)
Min
Nom
Max
@ I
ZT
mA
Zener Impedance
(Note 2)
Z
ZT
@ I
ZT
W
Z
ZK
@ I
ZK
W
I
ZK
mA
Leakage
Current
I
R
@ V
R
mA
Max
Volts
I
R
(Note 3)
A
DV
Z
(Note 4)
Volts
I
ZM
(Note 5)
mA
1N5333B
1N5334B
1N5335B
1N5336B
1N5337B
1N5338B
1N5339B
1N5340B
1N5341B
1N5342B
1N5343B
1N5344B
1N5345B
1N5346B
1N5347B
1N5348B
1N5349B
1N5350B
1N5351B
1N5352B
1N5333B
1N5334B
1N5335B
1N5336B
1N5337B
1N5338B
1N5339B
1N5340B
1N5341B
1N5342B
1N5343B
1N5344B
1N5345B
1N5346B
1N5347B
1N5348B
1N5349B
1N5350B
1N5351B
1N5352B
3.14
3.42
3.71
4.09
4.47
4.85
5.32
5.70
5.89
6.46
7.13
7.79
8.27
8.65
9.50
10.45
11.4
12.35
13.3
14.25
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.0
6.2
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
3.47
3.78
4.10
4.52
4.94
5.36
5.88
6.30
6.51
7.14
7.88
8.61
9.14
9.56
10.5
11.55
12.6
13.65
14.7
15.75
380
350
320
290
260
240
220
200
200
175
175
150
150
150
125
125
100
100
100
75
3
2.5
2
2
2
1.5
1
1
1
1
1.5
1.5
2
2
2
2.5
2.5
2.5
2.5
2.5
400
500
500
500
450
400
400
300
200
200
200
200
200
150
125
125
125
100
75
75
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
300
150
50
10
5
1
1
1
1
10
10
10
10
7.5
5
5
2
1
1
1
1
1
1
1
1
1
2
3
3
5.2
5.7
6.2
6.6
6.9
7.6
8.4
9.1
9.9
10.6
11.5
20
18.7
17.6
16.4
15.3
14.4
13.4
12.7
12.4
11.5
10.7
10
9.5
9.2
8.6
8.0
7.5
7.0
6.7
6.3
0.85
0.8
0.54
0.49
0.44
0.39
0.25
0.19
0.1
0.15
0.15
0.2
0.2
0.22
0.22
0.25
0.25
0.25
0.25
0.25
1440
1320
1220
1100
1010
930
865
790
765
700
630
580
545
520
475
430
395
365
340
315
1N5353B
1N5354B
1N5355B
1N5356B
1N5357B
1N5358B
1N5359B
1N5360B
1N5361B*
1N5362B
1N5353B
1N5354B
1N5355B
1N5356B
1N5357B
1N5358B
1N5359B
1N5360B
1N5361B
1N5362B
15.2
16.15
17.1
18.05
19
20.9
22.8
23.75
25.65
26.6
16
17
18
19
20
22
24
25
27
28
16.8
17.85
18.9
19.95
21
23.1
25.2
26.25
28.35
29.4
75
70
65
65
65
50
50
50
50
50
2.5
2.5
2.5
3
3
3.5
3.5
4
5
6
75
75
75
75
75
75
100
110
120
130
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
12.2
12.9
13.7
14.4
15.2
16.7
18.2
19
20.6
21.2
6.0
5.8
5.5
5.3
5.1
4.7
4.4
4.3
4.1
3.9
0.3
0.35
0.4
0.4
0.4
0.45
0.55
0.55
0.6
0.6
295
280
264
250
237
216
198
190
176
170
Devices listed in
bold, italic
are ON Semiconductor
Preferred
devices.
Preferred
devices are recommended choices for future use and best overall value.
1.
TOLERANCE AND TYPE NUMBER DESIGNATION
The JEDEC type numbers shown indicate a tolerance of
±5%.
2.
ZENER VOLTAGE (V
Z
) and IMPEDANCE (I
ZT
and I
ZK
)
Test conditions for zener voltage and impedance are as follows: I
Z
is applied 40
±10
ms prior to reading. Mounting contacts are located 3/8″
to 1/2″ from the inside edge of mounting clips to the body of the diode (T
A
= 25°C +8°C, −2°C).
3.
SURGE CURRENT (I
R
)
Surge current is specified as the maximum allowable peak, non−recurrent square−wave current with a pulse width, PW, of 8.3 ms. The data
given in Figure 5 may be used to find the maximum surge current for a square wave of any pulse width between 1 ms and 1000 ms by plotting
the applicable points on logarithmic paper. Examples of this, using the 3.3 V and 200 V zener are shown in Figure 6. Mounting contact located
as specified in Note 2 (T
A
= 25°C +8°C, −2°C).
4.
VOLTAGE REGULATION (DV
Z
)
The conditions for voltage regulation are as follows: V
Z
measurements are made at 10% and then at 50% of the I
Z
max value listed in the
electrical characteristics table. The test current time duration for each V
Z
measurement is 40
±10
ms. Mounting contact located as specified
in Note 2 (T
A
= 25°C +8°C, −2°C).
5.
MAXIMUM REGULATOR CURRENT (I
ZM
)
The maximum current shown is based on the maximum voltage of a 5% type unit, therefore, it applies only to the B−suffix device. The actual
I
ZM
for any device may not exceed the value of 5 watts divided by the actual V
Z
of the device. T
L
= 75°C at 3/8″ maximum from the device
body.
*Not Available in the 2000/Ammo Pack.
http://onsemi.com
3
1N5333B Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted, V
F
= 1.2 V Max @ I
F
= 1.0 A for all types)
Zener Voltage
(Note 7)
Device
(Note 6)
1N5363B
1N5364B
1N5365B
1N5366B
1N5367B
Device
Marking
1N5363B
1N5364B
1N5365B
1N5366B
1N5367B
V
Z
(Volts)
Min
28.5
31.35
34.2
37.05
40.85
Nom
30
33
36
39
43
Max
31.5
34.65
37.8
40.95
45.15
@ I
ZT
mA
40
40
30
30
30
Zener Impedance
(Note 7)
Z
ZT
@ I
ZT
W
8
10
11
14
20
Z
ZK
@ I
ZK
W
140
150
160
170
190
I
ZK
mA
1
1
1
1
1
Leakage
Current
I
R
@ V
R
mA
Max
0.5
0.5
0.5
0.5
0.5
Volts
22.8
25.1
27.4
29.7
32.7
I
R
(Note 8)
A
3.7
3.5
3.5
3.1
2.8
DV
Z
(Note 9)
Volts
0.6
0.6
0.65
0.65
0.7
I
ZM
(Note 10)
mA
158
144
132
122
110
1N5368B
1N5369B
1N5370B
1N5371B
1N5372B
1N5373B
1N5374B
1N5375B
1N5376B
1N5377B
1N5378B
1N5379B
1N5380B
1N5381B
1N5382B
1N5368B
1N5369B
1N5370B
1N5371B
1N5372B
1N5373B
1N5374B
1N5375B
1N5376B
1N5377B
1N5378B
1N5379B
1N5380B
1N5381B
1N5382B
44.65
48.45
53.2
57
58.9
64.6
71.25
77.9
82.65
86.45
95
104.5
114
123.5
133
47
51
56
60
62
68
75
82
87
91
100
110
120
130
140
49.35
53.55
58.8
63
65.1
71.4
78.75
86.1
91.35
95.55
105
115.5
126
136.5
147
25
25
20
20
20
20
20
15
15
15
12
12
10
10
8
25
27
35
40
42
44
45
65
75
75
90
125
170
190
230
210
230
280
350
400
500
620
720
760
760
800
1000
1150
1250
1500
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
35.8
38.8
42.6
45.5
47.1
51.7
56
62.2
66
69.2
76
83.6
91.2
98.8
106
2.7
2.5
2.3
2.2
2.1
2.0
1.9
1.8
1.7
1.6
1.5
1.4
1.3
1.2
1.2
0.8
0.9
1.0
1.2
1.35
1.52
1.6
1.8
2.0
2.2
2.5
2.5
2.5
2.5
2.5
100
93
86
79
76
70
63
58
54.5
52.5
47.5
43
39.5
36.6
34
1N5383B
1N5384B
1N5385B
1N5386B
1N5387B
1N5388B
1N5383B
1N5384B
1N5385B
1N5386B
1N5387B
1N5388B
142.5
152
161.5
171
180.5
190
150
160
170
180
190
200
157.5
168
178.5
189
199.5
210
8
8
8
5
5
5
330
350
380
430
450
480
1500
1650
1750
1750
1850
1850
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
114
122
129
137
144
152
1.1
1.1
1.0
1.0
0.9
0.9
3.0
3.0
3.0
4.0
5.0
5.0
31.6
29.4
28
26.4
25
23.6
Devices listed in
bold, italic
are ON Semiconductor
Preferred
devices.
Preferred
devices are recommended choices for future use and best overall value.
6.
TOLERANCE AND TYPE NUMBER DESIGNATION
The JEDEC type numbers shown indicate a tolerance of
±5%.
7.
ZENER VOLTAGE (V
Z
) and IMPEDANCE (I
ZT
and I
ZK
)
Test conditions for zener voltage and impedance are as follows: I
Z
is applied 40
±10
ms prior to reading. Mounting contacts are located 3/8″
to 1/2″ from the inside edge of mounting clips to the body of the diode (T
A
= 25°C +8°C, −2°C).
8.
SURGE CURRENT (I
R
)
Surge current is specified as the maximum allowable peak, non−recurrent square−wave current with a pulse width, PW, of 8.3 ms. The data
given in Figure 5 may be used to find the maximum surge current for a square wave of any pulse width between 1 ms and 1000 ms by plotting
the applicable points on logarithmic paper. Examples of this, using the 3.3 V and 200 V zener are shown in Figure 6. Mounting contact located
as specified in Note 7 (T
A
= 25°C +8°C, −2°C).
9.
VOLTAGE REGULATION (DV
Z
)
The conditions for voltage regulation are as follows: V
Z
measurements are made at 10% and then at 50% of the I
Z
max value listed in the
electrical characteristics table. The test current time duration for each V
Z
measurement is 40
±10
ms. Mounting contact located as specified
in Note 7 (T
A
= 25°C +8°C, −2°C).
10.
MAXIMUM REGULATOR CURRENT (I
ZM
)
The maximum current shown is based on the maximum voltage of a 5% type unit, therefore, it applies only to the B−suffix device. The actual
I
ZM
for any device may not exceed the value of 5 watts divided by the actual V
Z
of the device. T
L
= 75°C at 3/8″ maximum from the device
body.
http://onsemi.com
4
1N5333B Series
θ
JL, JUNCTION-TO-LEAD THERMAL RESISTANCE (
°C/W)
40
30
20
L
10
L
0
PRIMARY PATH OF
CONDUCTION IS THROUGH
THE CATHODE LEAD
0
0.2
0.4
0.6
0.8
L, LEAD LENGTH TO HEATSINK (INCH)
1
Figure 1. Typical Thermal Resistance
TEMPERATURE COEFFICIENTS
θV
Z , TEMPERATURE COEFFICIENT
(mV/°C) @ I ZT
θV
Z , TEMPERATURE COEFFICIENT
(mV/°C) @ I ZT
10
8
6
4
2
0
−2
3
4
7
5
6
8
V
Z
, ZENER VOLTAGE @ I
ZT
(VOLTS)
9
10
RANGE
300
200
100
50
30
20
10
5
0
20
40
60 80 100 120 140 160 180
V
Z
, ZENER VOLTAGE @ I
ZT
(VOLTS)
200 220
RANGE
Figure 2. Temperature Coefficient-Range
for Units 3 to 10 Volts
Figure 3. Temperature Coefficient-Range
for Units 10 to 220 Volts
http://onsemi.com
5
京公网安备 11010802033920号
EEWORLD
