Uninterruptible Power Supplies
S4K4U-C 6 kVA and S4K6U-C 10 kVA Industrial On-Line UPS
The new SolaHD S4K4U6000C and the S4K6U10KC
Industrial UPS Series are the first true On-Line industrial UPS
that provide higher output power factor, higher efficiency,
flexible output voltage, an integrated maintenance bypass
switch and internal batteries all in slim 4U (7.0”) and 6U
(10.5") enclosures respectively.
The S4K4UC and S4K6UC features true On-Line (double
conversion) topology providing the ultimate in protection
against a wide range of potential power problems. The
S4K4UC design of two 3 kVA, 120V inverters allow flexible
output voltage to meet mixed load voltage requirements. The
UPS automatically configures the output voltage to match
the input configuration without requiring tap selections. Self
diagnostics simplify maintenance and troubleshooting. The
standard maintenance bypass switch provides an additional
level of protection.
The S4K4UC and S4K6UC also feature a wide input voltage
window to support the critical load without having to transfer
to the battery. This extends system availability when back-up
is truly needed.
Applications
• Industrial Computers
• Robotics and Process Controls
• Industrial Automation Systems
• Network Servers
• Enterprise Telecommunication Systems
• Printing and Publishing Machinery
• Pharmaceutical and Medical Diagnosis Equipment
• Industrial and Commercial Machinery
• Micro-processor Controlled Equipment
• Mission Critical Devices
Features
• True double conversion topology
• Higher power factor of 0.80 (6kVA) and 0.90 (10kVA)
• Both models offer 208/120V or 240/120V
• Configurable as a tower or rack mounting
•
Highest density, 6 kVA in only 4U and 10 kVA in
only 6U of rack space
•
Easily installed in 18” to 32” deep rack using rack
mount kit # SRS1832
• User replaceable, hot-swappable internal battery module
• Extended battery cabinets
• Includes both automatic and manual maintenance
bypass switch
86
ENPC
E179213
•
Automatic frequency detection (60 or 50 Hz)
•
Power factor correction
•
Self-diagnostics simplify maintenance and
troubleshooting
•
Remote emergency Power Off (REPO)
•
Intellislot
TM
USB and terminal block communication ports
• Compatible with most standby generators
• Uses an average of 35% less energy than their standard
counterparts
• Provides continuous uptime for the connected equip-
ment, with capacity and battery back-up delivered in
cabinets that use 4U to 6U of rack space
• Two year limited
warranty
Certifications and Compliances
Listed, UPS Equipment
- UL 1778
- CSA C22.2 No. 107.3
• IEEE/ANSI C62.41 Category A & B
• ISTA Procedure 1A
• ABS Type Approved
• RoHS Compliant
•
ENERGY STAR
®
certified
•
Related Products
• Portable MCR Power Conditioners
• Surge Protective Devices
• Active Tracking
®
Filters
Visit our website at www.emerson.com or contact Technical Services at (800) 377-4384 with any questions.
© January 2017
Uninterruptible Power Supplies
S4K 6 and 10 kVA Specifications
Table 1:
UPS Specifications
Parameters
Rating
Model Number
S4K4U6000C
4800 W/6000 VA
Dimensions, W x D x H, in. (mm)
Unit
Shipping
6.80 x 26.10 x 16.90 (173.0 x 662.0 x 430.0)
13.20 x 33.10 x 26.10 (336.0 x 842.0 x 662.0)
Weight, lbs. (kg)
Unit
Shipping
56.2 (25.50)
70.5 (32.00)
Input AC Parameters
Nominal Operating Frequency
Factory Default Vac
L1–L2 Factory Default Input Phase Angle
Allowable Input Phase Angle
Factory Default L1–N, L2–N Vac
User Configurable L1–N, L2–N Vac
Input Frequency w/o Battery Operation
Input Power Connection
L1–N, L2–N Maximum Allowable Vac
Output AC Parameters
Factory Default Vac
L1–L2 Factory Default Output Phase Angle
Allowable Output Phase Angle
Factory Default L1–N, L2–N Vac
User Configurable L1–N, L2–N Vac
L1-N, L2-N Overload Rating
105% to 130%
131% to 150%
151% to 200%
>200% (impact load)
1 minute
10 seconds
1 second
At least 5 cycles
120/208 Vac @ 120°C
120°C
120, 180, 240 degrees; auto-sensing on initial application of input alternating current
120 Vac nominal
100/110/115/120/127 Vac, ± 2%
50 or 60 Hz (Factory default is 60 Hz)
120/208 Vac @ 120°C
120°C
120, 180, 240 degrees; auto-sensing on application of alternating current
(Restrictions for L–N voltage other than 120 Vac)
120 Vac nominal
100/110/115/120/127 Vac (Can be modified with configuration program)
40–70 Hz
Hardwire terminal block 3W + G (L–L–N–G)
150 Vac
78.3 (35.50)
92.6 (42.00)
10.30 x 26.50 x 16.90
(261.0 x 672.0 x 430.0)
16.70 x 32.80 x 24.10
(424.0 x 832.0 x 612.0)
S4K6U10KC
9000 W/10000 VA
Visit our website at www.emerson.com or contact Technical Services at (800) 377-4384 with any questions.
© January 2017
87
Uninterruptible Power Supplies
S4K 6 and 10 kVA Specifications - continued
Table 2:
UPS Specifications
Parameters
Model Number
S4K4U6000C
Bypass Protection Limits
Disable Bypass Operation
Re-enable Bypass Operation
Disable Bypass Operation
If input voltage exceeds ±15% of the nominal voltage
If input voltage returns to within ±10% of nominal output voltage
When the input frequency prevents synchronous operation
Environmental Requirements
Operating Temperature
Storage Temperature
Relative Humidity
Operating Elevation
Audible Noise
0°C to +40°C; see Table 11 for operating temperature parameters
-15°C to +50°C
0% to 95%, non-condensing
Up to 10,000 ft. [3,000 m]
<55 dBA @ 3.2 ft. [1 m] rear; <50 dBA @ 3.2 ft. [1 m] front & sides
Standards
EMC
FCC Part 15, Subpart B, Class A, FCC Class A
S4K6U10KC
Table 3:
Operating Temperature Parameters
Ambient Temperature
pf @ 30°C ±3°C
pf @ 40°C ±3°C
Model Number
S4K4U6000C
0.8 pf
0.8 pf
S4K6U10KC
0.9 pf
0.8 pf
88
Visit our website at www.emerson.com or contact Technical Services at (800) 377-4384 with any questions.
© January 2017
Uninterruptible Power Supplies
Table 4:
Internal Battery Specifications
Parameters
Used with UPS Models
Model Number
S4K144INTBATC
S4K4U6000C
Dimensions, W x D x H, in. (mm)
Unit
Shipping
2.80 x 19.30 x 8.10 (70.0 x 490.0 x 206.0)
12.20 x 23.70 x 10.30 (310.0 x 602.0 x 262.0)
Weight, lbs. (kg)
Unit
Shipping
75.8 (34.40)
81.1 (36.80)
Battery Parameters
Type
Qty x V x Rating
Battery Mfr./Part Number
Back-up Time
Recharge Time
Valve-regulated, non-spillable, flame retardant, lead acid
2 x 6 x 12 V x 9.0 Ah
CSB type UPS12460F2
See Table 8
3 hours to 90% capacity after full discharge into 100% load
Environmental Requirements
Operating Temperature
Storage Temperature
Relative Humidity
Operating Elevation
0°C to +40°C
-15°C to +50°C
0% to 95%, non-condensing
Up to 10,000 ft. [3,000 m] at +40°C without derating
2 x 12 x 12 V x 9.0 Ah
71.1 (32.30)
76.4 (34.70)
5.30 x 19.70 x 8.10 (135.0 x 500.0 x 207.0)
12.20 x 23.90 x 9.50 (310.0 x 607.0 x 242.0)
S4K288INTBATC
S4K6U10KC
Visit our website at www.emerson.com or contact Technical Services at (800) 377-4384 with any questions.
© January 2017
89
Uninterruptible Power Supplies
Table 5:
External Battery Cabinet Specifications
Parameters
Used with UPS Models
Model Number
S4K144BATC
S4K4U6000C
Dimensions, W x D x H, in. (mm)
Unit (with bezel)
Shipping
3.30 x 26.10 x 16.90 (85.0 x 662.0 x 430.0)
25.80 x 34.30 x 12.30 (655.0 x 872.0 x 312.0)
Weight, lbs. (kg)
Unit
Shipping
99.9 (45.30)
110.2 (50.00)
Battery Parameters
Type
Qty x V x Rating
Battery Mfr./Part Number
Back-up Time
Environmental Requirements
Operating Temperature
Storage Temperature
Relative Humidity
Operating Elevation
0°C to +40°C
-15°C to +50°C
0% to 95%, non-condensing
Up to 10,000 ft. [3,000 m] at +40°C without derating
Valve-regulated, non-spillable, flame retardant, lead acid
2 x 6 x 12 V x 9.0 Ah
CSB type UPS12460F2
See Table 8
2 x 12 x 12 V x 9.0 Ah
29.8 (13.50)
44.1 (20.00)
6.80 x 26.50 x 16.90 (173.0 x 672.0 x 430.0)
13.20 x 33.10 x 24.50 (336.0 x 842.0 x 622.0)
S4K288BATC
S4K6U10KC
90
Visit our website at www.emerson.com or contact Technical Services at (800) 377-4384 with any questions.
© January 2017
