45053 BK005 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> Multi-core cable with multiple pairs cable> Multi-core cable> 45053 BK005

45053 BK005: DescriptionMulti-core cable 20AWG 3C UNSHIELD 100FT SPOOL BLACK; CategoryWire/cable Multi-core cable with multiple pairs cable Multi-core cable; File Size223KB，5 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

45053 BK005 Overview

Multi-core cable 20AWG 3C UNSHIELD 100FT SPOOL BLACK

45053 BK005 Parametric

Parameter Name	Attribute value
Maker	Alpha Wire
Product Category	multi-core cable
type	Xtra-Guard 4
Number of conductors	3 Conductor
Shell color	Black
outer diameter	-
Shell material	Thermoplastic Elastomer (TPE)
shield	Unshielded
conductor material	Tinned Copper
Insulation Materials	Thermoplastic Elastomers (TPE)
stranded	7 x 28
Voltage rating	300 V
Factory packaging quantity	1

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 45053

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Cond

2) Cable Assembly

a) Twists:

b) Orientation:

c) Core Wrap

3) Jacket

a) Color(s)

b) Ripcord

Color

BLACK

3 X 1 COND

20 (7/28) AWG Tinned Copper

0.016" Wall, Nom. TPE

Alpha Wire Color Code D

Cond

3 Components Cabled

6.9 Twists/foot (min)

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

Nonwoven Polyester Tape, 25% Overlap, Min.

0.045" Wall, Nom.,TPE

0.245 (0.256 Max.)

Color

RED

Cond

Color

WHITE

0.038

0.070

Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White

1 End 810 Denier Nylon

ALPHA WIRE-* P/N 45053 3C 20 AWG

XTRAGUARD(R) 4 (UL) TYPE PLTC 105C SUN RES OR AWM

21916 125C 300 V OR CRU AWM I/II A/B 125C 300V

FT1 P-07-KA140023-MSHA

CE ROHS (SEQ FOOTAGE)

* = Factory Code

c) Print

Applicable Specifications

1) UL

AWM/STYLE 21916

PLTC

SUN RES

2) CSA International

C(RU) AWM I/II A/B FT1

SUN RES (Black only)

3) Other

4) CE:

PENNSYLVANIA BUREAU OF MINE SAFETY

APPROVED

EU Low Voltage Directive 2014/35/EC

125°C / 300 VRMS

105°C

Environmental

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 45053

45053 , RoHS-Compliant Commencing With 10/1/2014 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

12/3/2018

45053 BK005 Related Products

	45053 BK005	45053 BK199
Description	Multi-core cable 20AWG 3C UNSHIELD 100FT SPOOL BLACK	Multi-core cable 20AWG 3C UNSHLD 1000FT SPOOL BLACK
Maker	Alpha Wire	Alpha Wire
Product Category	multi-core cable	multi-core cable
Shell color	Black	Black
Factory packaging quantity	1	1000
