METRI-PACK SERIES
U
N
SE
Metri-Pack Series
S
SE
AL
Available in device and in-line
connections for vehicle applications,
Metri-Pack 630 Series connectors can
meet or exceed the requirements for
most marine, appliance, and industrial
control applications.
Ideally suited for high current
applications that do not require
environmental protection, Metri-Pack 630
Series products are extremely rugged
and versatile.
E
N
AL
S
S
E
L
E
A
ED
Available in device and in-line
connections for underhood vehicle
AL
E
D
applications, Metri-Pack 630 Series sealed
connectors can meet or exceed the
630
E
U
D
D
U
requirements for most marine, appliance,
and industrial control applications.
Utilizing triple-rib peripheral silicone
rubber seals, Metri-Pack 630 Series sealed
systems are ideally suited for high current
applications that require protection from
environmental hazards.
630 Metri-Pack Features
•
Connector Position Assurance
(CPA)
•
Terminal Position Assurance
(TPA)
•
46 Amps continuous maximum
current rating
•
Low energy, low voltage capability
•
Excellent resistance to temperature,
chemicals and abrasion
•
-40ºC to 125ºC temperature range
105
630
Metri-Pack Series
U
N
SE
AL
SE
AL
E
U
Unsealed System Application Information
630 SERIES TERMINALS–Tin Plated
TEMPERATURE RISE ABOVE
o
AMBIENT (25 C ) VS CURRENT*
TEMPERATURE DERATING CURVES*
T
EMPERATURE
R
ISE
( C )
CABLE RANGE
(
mm
2
):
........ 0.35-5.0
......... 0-46
100
80
60
40
20
0
0
M
AXIMUM
C
URRENT
(AMPS)
0.50
0.80
1.0
2.0
3.0
5.0
50
40
30
20
10
0
25
50
5.0
3.0
2.0
1.0
0.80
0.50
CURRENT RANGE
(
AMPS
):
TEMP RANGE
O
C
:
RESISTANCE
:
........... -40 to 125
....... <3.0mV/amp
8.5
6.3
....... <10m
Ω
@20mV
VOLTAGE DROP
:
CENTERLINE SPACING
(
mm
): ........
BLADE WIDTH
(
mm
): ..................
O
10
20
30
40
50
75
100
125
C
URRENT
(AMPS)
A
MBIENT
T
EMPERATURE
(
O
C )
*The test data are based on single circuits in free space and were generated using a “Lumped
Resistance” model. This model does not account for all of the variables that would be present
in an actual application. For actual product performance, contact your regional support
representative at the number listed below.
Male Terminal
TPA
(Terminal Position
Assurance)
Male Connector
630 MALE TERMINALS UNSEALED
Part #
12066493
12052826
Cable Range (mm
2
)
5.0
3.0
3.0 (2 Req’d.)
2.0-1.0
1.0-0.80
0.80-0.50 (2 Req’d.)
0.50-0.35
Material
Tin Brass
Tin Brass
Tin Brass
Tin Brass
Tin Brass
Tin Brass
Tin Brass
Plating
Tin over Copper
Tin over Copper
Tin over Copper
Tin over Copper
Tin over Copper
Tin over Copper
Tin over Copper
630 MALE CONNECTORS UNSEALED
# Cavities
2
4
Connector
12129938
12052623
Color
Black
Black
Material
PA66 HS IM
PA6
TPA
12129940
–
12020365
12020126
12020125
12033972
12066454
SECTION NOTES:
Contact your regional support representative at the number listed below.
• Due to rigid tolerances of connector cavities, it is
critical to meet all crimp dimensions as specified.
http://delphi.com/products/connect
North American Region
1-800-PACKARD
European Region
49-202-291-2000
Asia Pacific Region
65-730-9900
South American Region
55-12-378-2002
