8
CATALOG NO.
RM25030-1SR
TERMINAL TYPE
SCREW
SCREW
SCREW
PRESSURE PLATE
PRESSURE PLATE
PRESSURE PLATE
BOX LUG
BOX LUG
BOX LUG
7
W/O INDICATION
6
IP20 FINGER SAFE C
INDICATION
NO. OF
POLES
5
4
3
2
1
F
RM25030-2SR
RM25030-3SR
RM25030-1PR
RM25030-2PR
RM25030-3PR
RM25030-1CR*
RM25030-2CR*
RM25030-3CR*
RM25030-1QR
RM25030-2QR
CVR-RH-25030
CVRI-RH-25030
SCREW AND .187 QUICK CONNECTS
SCREW AND .187 QUICK CONNECTS
E
RM25030-3QR
SCREW AND .187 QUICK CONNECTS
* -CHR ALSO AVAILABLE; SEE NOTE 10
1
2
3
1
2
3
1
2
3
1
2
3
F
80.4
3.17
24.6
.97
49.1
1.93
24.4
.96
LOCKOUT-TAGOUT
RING
SEE NOTE 6
73.5
2.89
E
PROVISION FOR
MARKING LABEL
SEE NOTE 8
R2.4
.10
R2.9
.11
7.7
.30
24.4
.96
99.1
3.90
D
REJECTION RIB
TYPICAL FOR
CLASS R BLOCKS
25.7
1.01
.187 QC
50.2
1.97
74.6
2.94
14.5
.57
PROVISION FOR
MARKING LABEL
SEE NOTE 8
D
50.2
1.97
C
35.9
1.41
C
RM25030-1SR
NOTES:
RM25030-1PR
RM25030-1QR
1-POLE
RM25030-1CR SHOWN
2-POLE
RM25030-2CR SHOWN
3- POLE
RM25030-3CR SHOWN
RM25030-1CR
SHOWN WITH COVER
B
A
SLA3_BUSS_NAE_GENRL_REV_A
1) VOLTAGE RATING: 250V
2) AMPERAGE: 30A
3) WITHSTAND RATING: CLASS R = 200kA; CLASS H = 10kA
4) WIRE: CU75C/90C
5) -CR WIRE RANGE:
(1) 2 - 14 AWG CU
2-3: 50 lb-in (5.6 Nm)
4-6, 45 lb-in (5.1 Nm)
8, 40 lb-in (4.5 Nm)
10-14, 35 lb-in (4.0 Nm)
(2) 12-14, 50 lb-in (5.6 Nm)
(1) 2 - 8 AWG AL
3D VIEW FOR
2-3: 50 lb-in (5.6 Nm)
RM25030-1QR
4-6, 45 lb-in (5.1 Nm)
SCALE NONE
8, 40 lb-in (4.5 Nm)
-SR/PR WIRE RANGE: (1) 10-18 AWG CU ONLY
10-18 AWG = 20 LB-IN (2.3NM)
6) USE 4MM DIA. CABLE LOCK OR 1/4 INCH DIA. HASP PADLOCK.
7) RECOMMEND USING DIN-RAIL END STOPS FOR DIN RAIL MOUNTED APPLICATIONS
BUSSMANN PART NUMBERS BRKT-ND OR BRKT-NDSCREW2
8) USE BUSMANN MAKER LABEL TM26CB
9) ALL DIMENSIONS ARE TYPICAL UNLESS OTHERWISE INDICATED
10) -CHR IS IDENTICAL TO THE -CR EXCEPT WITH A 1/8 INCH HEX WIRE CONNECTOR SCREW
8
7
6
5
B
3D VIEW FOR
RM25030-1CR
SCALE NONE
3D VIEW FOR
RM25030-1PR
SCALE NONE
EATON CORPORATION - CONFIDENTIAL
AND PROPRIETARY
3D VIEW FOR
RM25030-1SR
SCALE NONE
THIS DRAWING IS AN UNCONTROLLED COPY IF PRINTED OR
SENT ELECTRONICALLY,DO NOT SCALE DRAWING
3D VIEW FOR RM25030-1xR
WITH COVER
SCALE NONE
NOTICE TO PERSONS RECEIVING THIS DOCUMENT AND/OR TECHNICAL
INFORMATION
GENERAL DRAWING PRACTICES IN
ACCORDANCE WITH
ASME - Y14.100-2004
DIMENSIONS AND TOLERANCES IN
ACCORDANCE WITH
ASME - Y14.5M-1994
UNLESS OTHERWISE SPECIFIED
TITLE
THIS DOCUMENT, INCLUDING THE DRAWING AND INFORMATION CONTIANED THEREON,
DIMENSIONS ARE IN MILLIMETERS
IS CONFIDENTIAL AND IS THE EXCLUSIVE PROPERTY OF EATON CORPORATION AND
IS MERELY ON LOAN AND SUBJECT TO RECALL BY EATON AT ANY TIME. BY TAKING
POSSESSION OF THE DOCUMENT, THE RECIPIENT ACKNOWLEDGES AND AGREES THAT
UNLESS OTHERWISE SPECIFIED TOLERANCES TO BE
THIS DOCUMENT CANNOT BE USED IN ANY MANNER ADVERSE TO THE INTERESTS OF
MILLIMETERS ±
.13
mm
EATON AND THAT NO PORTION OF THIS DOCUMENT MAY BE COPIED OR OTHERWISE
REPRODUCED WITHOUT THE PRIOR WRITTEN CONSENT OF EATON. IN THE CASE OF
ANGULAR
±
1
°
CONFLICTING CONTRACTUAL PROVISIONS, THIS NOTICE SHALL GOVERN THE
STATUS OF THIS DOCUMENT.
C
2012 Eaton Corporation, All Rights Reserved.
A
DWG NO.
REV
250V / 30AMP CLASS R & H FUSE BLOCK
2:3
CUSTOMER PRINT
A3
THIRD ANGLE PROJECTION
SCALE:
SIZE
RM25030-HM25030-SERIES-CP
SHEET
4
3
2
1
1 OF 3
Tue Oct 01, 2013 4:0X PM GPK
B
8
CATALOG NO.
HM25030-1SR
TERMINAL TYPE
SCREW
SCREW
SCREW
PRESSURE PLATE
PRESSURE PLATE
PRESSURE PLATE
BOX LUG
BOX LUG
BOX LUG
7
W/O INDICATION
6
IP20 FINGER SAFE C
INDICATION
NO. OF
POLES
5
4
3
2
1
F
HM25030-2SR
HM25030-3SR
HM25030-1PR
HM25030-2PR
HM25030-3PR
HM25030-1CR*
HM25030-2CR*
HM60030-3CR*
HM25030-1QR
HM25030-2QR
HM25030-3QR
CVR-RH-25030
CVRI-RH-25030
SCREW AND .187 QUICK CONNECTS
SCREW AND .187 QUICK CONNECTS
SCREW AND .187 QUICK CONNECTS
1
2
3
1
2
3
1
2
3
1
2
3
F
E
* -CHR ALSO AVAILABLE; SEE NOTE 10
E
D
D
.187 QC
C
HM25030-1SR
HM25030-1PR
HM25030-1QR
1-POLE
HM25030-1CR SHOWN
2-POLE
HM25030-2CR SHOWN
3- POLE
HM25030-3CR SHOWN
C
B
B
3D VIEW FOR
HM25030-1QR
SCALE NONE
3D VIEW FOR
HM25030-1CR
SCALE NONE
3D VIEW FOR
HM25030-1PR
SCALE NONE
3D VIEW FOR
HM25030-1SR
SCALE NONE
3D VIEW FOR HM25030-1xR
WITH COVER
SCALE NONE
A
SLA3_BUSS_NAE_GENRL_REV_A
TITLE
A
DWG NO.
REV
1
250V / 30AMP CLASS R & H FUSE BLOCK
2:3
A3
SCALE:
SIZE
RM25030-HM25030-SERIES-CP
SHEET
8
7
6
5
4
3
2
1
2 OF 3
Tue Oct 01, 2013 4:0X PM GPK
B
8
7
6
5
4
3
2
1
F
F
CUT COVER TAB
AT NOTCH FOR
WIRES LARGER
THAN 8 AWG
E
E
D
DETAIL A
SCALE 4 : 3
D
C
C
A
B
CLOSING
PUSH STRAIGHT DOWN UNTIL SNAPS CLICK
INTO PLACE
OPENING
PULL STRAIGHT UP AT BOTH OUTSIDE
HANDLES
INSTALLATION ON DIN RAIL
END STOPS MAY BE NECESSARY FOR SOME
ASSEMBLY CONDITIONS - SEE NOTE 7
B
A
SLA3_BUSS_NAE_GENRL_REV_A
TITLE
A
DWG NO.
REV
250V / 30AMP CLASS R & H FUSE BLOCK
2:3
A3
SCALE:
SIZE
RM25030-HM25030-SERIES-CP
SHEET
8
7
6
5
4
3
2
1
3 OF 3
Tue Oct 01, 2013 4:0X PM GPK
B
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Eaton
:
RM25030-1QR RM25030-2PR RM25030-1CR RM25030-3SR RM25030-1SR RM25030-3CHR RM25030-2CHR
RM25030-1CHR RM25030-2CR RM25030-3QR RM25030-3PR RM25030-2SR RM25030-1PR RM25030-3CR
RM25030-2QR HM25030-2SR HM25030-1CR HM25030-2PR HM25030-2QR HM25030-3PR HM25030-3SR
HM25030-3CR HM25030-2CR HM25030-1PR HM25030-1QR HM25030-3QR HM25030-1SR CVRI-RH-25030
CVR-RH-25030
