SHEET 1 OF 1
R1 (RED)
G1 (GREEN)
B1 (BLUE)
C1
17.40
[.685 in]
1
2
R2 (RED)
G2 (GREEN)
B2 (BLUE)
C2
LED COLOR:
RED / GREEN / BLUE
CIRCUIT: SPST
LED SCHEMATIC
12.70
[.500 in]
4.50
[.177 in]
7.62
[.300 in]
4.00
[.157 in]
.80 (10x)
[.031 in]
G1
R1
C2
B2
4.50
[.177 in]
7.00
[.276 in]
12.70
[.500 in]
2
B1
C1
R2
G2
1
23.0
[.906 in]
11.50
[.453 in]
15.00
[.591 in]
1.60
4.60
[.063 in] [.181 in]
1.30 (4x)
[.051 in]
3.81
[.150 in]
PCB LAYOUT
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X = 0.4
X.XX = 0.25
3. TERM. NOS. FOR REFERENCE ONLY.
4. RATING: 12VDC, 100mA
5. CONTACT MATERIAL: GOLD PLATED
6. CONTACT RESISTANCE: 200 m MAX.
7. INSULATION RESISTANCE: 500VDC, 100 M MIN.
8. OPERATING FORCE: 200 80gf
9. MECHANCIAL LIFE: 2,000,000 CYCLES
10. OPERATING TEMP: -40 C TO +85 C
11. LED COLORS: RED / GREEN / BLUE
12. TRAVEL: 4.50mm 0.20
13. 2002/95/EC (ROHS) COMPLIANT
14.
DENOTES CRITICAL PARAMETER.
15. SWITCH HAS TACTILE FEEDBACK WHEN ACTUATED
A
REV
22360
PCR NO
INITIAL RELEASE
DESCRIPTION
6/21/16
DATE
2.60
[.102 in]
12.70
[.500 in]
3.00
[.118 in]
12.70
[.500 in]
3.60
[.142 in]
1
G2
R2
C1
B1
B2
C2
R1
G1
LED SPECS
FORWARD CURRENT
FORWARD VOLTAGE @20mA
LUMINOUS INTENSITY @20mA
UNITS
mA
V
MCD
RED
20
2.1-2.5
1000
GREEN
20
3.2-4.0
1600
BLUE
20
3.1-3.8
400
2
MW
BY
TITLE
SCALE
LP11OA1TCSRGB
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
2:1
6/20/2016
MW
B231021
A
