TYPE
：
MV002 Series Relay
Revised : 2015-01-24
Issued : 2012-08-22
Type List
Terminal
style
Plug-in terminal
PCB terminal
Ordering Information
1A
(SPDM)
Contact
form
Dust cover
MV002-1AH-F-D
MV002H-1AH-F-D
------
Designation (provided with)
Flux tight
------
MV002P-1AH-F-C
MV002HP-1AH-F-C
Flanged cover
(Dust cover)
MV002-1AH-F-D1
MV002H-1AH-F-D1
------
MV002
1
H P - 1A H - F -
2
3
4
5
6
C
7
-
R1
8
S
D1
C1
S1
D1SW
XXX
9
1. MV002 -- Basic series designation
2. Blank
H
3. Blank
P
4. 1A
5. H
6. Blank
F
7. D
C
-- Standard
-- High power type
-- Socket terminal
-- PCB terminal
-- Single-pole, double-make (SPDM)
-- Contact material Ag alloy
-- Standard type
-- Class F
-- Dust cover
-- Flux tight
-- Sealed type washable
-- Flanged cover (Dust cover)
-- Flanged cover (Flux tight)
-- Flanged cover (Sealed type washable)
-- Steel bracket (dust cover with weather
proof)
D1SF -- Steel bracket (dust cover with shroud)
D1S -- Steel bracket (dust cover)
C1S -- Steel bracket (flux tight)
S1S -- Steel bracket (sealed type washable)
8. Blank -- Standard type
R1
-- Coil parallel with resistor 1/2W for
12V 680Ω
9. XXX
-- Special feature code
Contact Rating
Type
Rated load (Resistive)
20A 72VDC
Max. Switching Capacity
1800W
2400W
Standard
30A 60VDC
High power type
40A 60VDC
P. 1 / 3
ENMV00201
TYPE
：
MV002 Series Relay
Coil Rating (DC)
Rated
(V)
12
24
48
Rated current
(mA)
133.3
66.7
33.3
Coil resistance
±10
% at 23°C
(Ω)
90
360
1440
Pick up
Voltage
(Max)
at 23°C
75% of
rated
voltage
Drop out
Voltage
(Min)
at 23°C
5% of
rated
voltage
Revised : 2015-01-24
Issued : 2012-08-22
Max.
continuous
voltage
at 23°C
(1)
130% of
rated
voltage
Power
consumption
at rated
voltage
voltage
±10
% at 23°C
approx. 1.6W
Notes：(1) Without contact load.
Specification
Contact material
Voltage drop
(1)
Operate time
(1)
Release time
(1)
Insulation resistance
(1)
Dielectric strength
(1)
Ag alloy
Typ.50 mV at 10A
20ms Max.
20ms Max.
20MΩ Min. (DC 500V)
Between open contact
Between contact and coil
Operating extremes
:
AC 750V, 50/60Hz 1 min.
:
AC 750V, 50/60Hz 1 min.
10~500Hz, 5.0G
10~500Hz, 5.0G
10G
100G
1000,000 operations
(frequency 9,000 operations/hr)
10,000 operations
(frequency 600 operations/hr)
-40½+85°C (no freezing)
Approx. 40 g
Vibration resistance
Damage limits
Operating extremes
Shock resistance
Damage limits
Mechanical
Life expectancy
Electrical
Operating ambient temperature
Weight
Note：(1) Initial value. Operate and release time excluding contact bounce.
(2) All tests are conducted under room temperature and room humidity.
(3) Consider the heat of PCB is necessary, please check the actual condition of PCB.
(4) If it includes ripple, the ripple factor should be less than 5%. And do not have a parallel connection
with diode for the purpose of coil surge instead of diode, a varistor (ZNR) is recommend for the
absorber.
(5) Do not use the relay exceeding the coil rating, contact rating and life expectancy, or this may cause
the risk of overheating.
(6) To assure optimum performance, avoid the relay from dropping, hitting, or other unnecessary shocks.
(7) Do not switch the contacts without any load as the contact resistance may become increased
rapidly.
P. 2 / 3
ENMV00201
TYPE
：
MV002 Series Relay
(8) Use suitable harnesses and bus bars according to the current as below︰
30A type︰Min. 6 mm
2
；
40A type︰Min. 10 mm
2
(9) Please contact Song Chuan for the detailed information.
Safety Approval
Certified
File No.
Safety Approval Rating
MV002
Revised : 2015-01-24
Issued : 2012-08-22
UL / CUL
E88991
MV002H
30A 60VDC
55A 60VDC
Confirmed by
Checked by
Prepared by
副董事長
吳頌仁
15’.03.12
技術協理
葉家昇
15’.03.11
文管課長
胡麗珠
15’.01.24
P. 3 / 3
ENMV00201
