UGA8120
Taiwan Semiconductor
CREAT BY ART
8A, 1200V Super Fast Power Rectifier
FEATURES
- Super Fast, Soft Recovery characteristics
- High junction temperature up to 175°C
- Negligible leakage sustain the high operation temperature
- Very low stored charge and its soft recovery minimize ringing and
electrical noise to reduce power loss in associated MOSFET or IGBT
- High capability for high dI/dt operation.
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
C
1
2
TO-220AC
TYPICAL APPLICATIONS
The UGA8120 is an ideal solution for being used as freewheeling diodes, featuring extremely low peak recovery current to
significantly reduce snubbing, and lowering switching losses in IGBT / MOSFET.
It is especially suited for heavy duty applications with demanding long term reliability such as inverters,
uninterrupted power supplies, motor drives and other mission-critical systems,
where high frequency and high efficiency is being needed.
Another competitive advantage of this device is the negligible leakage for use in high temperature environment.
MECHANICAL DATA
Case:
TO-220AC
Molding compound, UL flammability classification rating 94V-0
Part no. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
As marked
Mounting torque:
0.56 Nm maximum
Weight:
1.85g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum average forward rectified current
Non-repetitive peak forward surge current
8.3ms single sine-wave
Maximum instantaneous forward voltage (Note 1)
I
F
= 8 A
Maximum reverse current @ Rated VR
T
J
=25 °C
T
J
=125 °C
Reverse Recovery Time
T
J
=25°C, I
F
=0.5A, I
R
=1A, I
RR
=0.25A
T
J
=25°C, I
F
=1A, dI
F
/dt= -100A/µs, V
R
=30V
Reverse Recovery Charges
T
J
=25°C, I
F
=8A, dI
F
/dt= -200A/µs, V
R
=400V
T
J
=125°C, I
F
=8A, dI
F
/dt= -200A/µs, V
R
=400V
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Document Number: DS_D1405001
Version: C15
Q
rr
I
RM
R
θJC
T
J
T
STG
t
rr
I
R
SYMBOL
V
RRM
I
F(AV)
I
FSM
V
F
TYP
1
5
TYP
35
50
TYP
165
11
2.3
- 55 to +175
- 55 to +175
UGA8120
1200
8
80
2.8
MAX
5
100
MAX
50
70
MAX
-
16
nC
A
°C/W
°C
°C
ns
μA
UNIT
V
A
A
V
UGA8120
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
UGA8120
*: Optional available
PART NO.
SUFFIX
H
PACKING
CODE
C0
PACKING CODE
SUFFIX
G
(*)
PACKAGE
TO-220AC
PACKING
50 / Tube
EXAMPLE
EXAMPLE P/N
UGA8120HC0G
PART NO.
UGA8120
PART NO.
SUFFIX
H
PACKING CODE
C0
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CURVE
PEAK FORWARD SURGE CURRENT (A)
10
8
6
4
2
0
0
25
50
75
100
125
150
175
Resistive or
inductive load
with heat sink
100
8.3ms single half sine wave
75
FIG. 2 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
AVERAGE FORWARD
A
CURRENT (A)
50
25
1
10
NUMBER OF CYCLES AT 60 Hz
100
CASE TEMPERATURE (
°
C)
FIG. 3 TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
100
Pulse width=300μs
1% duty cycle
10
FIG. 4 TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT (μA)
INSTANTANEOUS FORWARD CURRENT (A)
T
J
=125
°
C
1
10
T
J
=125
°
C
T
J
=25
°
C
1
0.1
T
J
=25
°
C
0.01
0.1
0
0.5
1
1.5
2
2.5
3
FORWARD VOLTAGE (V)
0
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Document Number: DS_D1405001
Version: C15
UGA8120
Taiwan Semiconductor
CREAT BY ART
