Transcend
Wireless Switches and Dimmers
®
Self-powered wireless controls by Molex are simple to install.
The single and double switch pads use energy harvesting technology to communicate with a wireless gateway and
provide convenient local control of lighting, temperature and miscellaneous electric loads. These switch/dimmer
pads are self-powered and never require batteries because the action of pressing the rocker generates sufficient
energy to send a wireless signal to a given gateway device. Used with sensors and controls, these local switches
maximize efficiency to provide a level of comfort and convenience not possible with conventional switches. The
clean contemporary styling is an attractive complement to any décor.
Features and Benefits
Wireless communication with light fixture(s)
Integrated energy harvesting technology
Switching and dimming capable
Clean, contemporary design
Elminates need for wire and conduit; cost-saving. Installation is fast, easy, non-intrusive
No need for line voltage or batteries; self-powered. Reliable and energy-saving solution
Enables local controls in addition to network control. Provides local manual dimming function
Compatible with a wide range of décors and styles
Specifications
Description
Power Supply
Inputs/Outputs
RF Communication
Transmission Range
RF Transmission
EnCcean® Equipment profile (EEP)
Dimensions
Weight
Mounting
Environment
Agency Compliance
Warranty
Mechanical Energy Harvesting (power is generated by the motion of pressing the switch)
1 or 2 button rocker switch options
Radio Frequency (RF) transmitter
EnOcean
®
902 MHz
80ft. (25m)
On press and release of rocker button
F6-02-02
Single: 4.95” H x 3.21” W x 0.74” D(126mm x 82mm x 19mm)
Double: 4.95” H x 4.52” W x 0.72” D(126mm x 115mm x 18mm)
Single: 3.98oz. (112g)
Double: 5.3oz. (150g)
Surface mounted on wall (using included mounting screws)
Can also be flush mounted by optional use of electrical wall box or low-voltage ring
Indoor use only
32° to 131°F (0° to 55°C)
5% to 95% relative humidity (non-condensing)
FCC: SZV-PTM210U IC: 5713A-PTM210U
1 Year
Ordering Information
Product
Description
Transcend Wireless Single Switch
Molex Part Number
180997-0001
Transcend Wireless Double Switch
180997-0002
www.molex.com/cl/transcend
Order No. 987651-4281 Rev. 1
USA/0k/GF/2016.11
©2016 Molex
