Data Sheet
ASMT-UWB1-Nxxxx
OneWhite Surface-Mount PLCC-2 LED Indicator
Description
This family of SMT LEDs is packaged in the industry
standard PLCC-2 package. These SMT LEDs have high
reliability performance and are designed to work under a
wide range of environmental conditions. This high reliability
feature makes them ideally suited to be used as interior
signs application conditions.
To facilitate easy pick and place assembly, the LEDs are
packed in EIA-compliant tape and reel. Every reel will be
shipped in single intensity and color bin.
These LEDs are compatible with reflow soldering process.
The wide viewing angle at 120° makes these LEDs ideally
suited for panel, push button, office equipment, industrial
equipment, and home appliances. The flat top emitting
surface makes it easy for these LEDs to mate with light
pipes. With the built-in reflector pushing up the intensity of
the light output, these LEDs are also suitable to be used as
LED pixels in interior electronic signs.
Features
High reliability package with silicone encapsulation
Compatible with reflow soldering process
High optical efficiency with 100 lm/W
Available in 8-mm carrier tape with reel diameter
180 mm
JEDEC MSL 3 product
ESD threshold of 1000V (HBM model) per JEDEC
Applications
Non-automotive use
General signage backlighting
Amusement machine backlighting
Industrial lighting
Light strips
CAUTION!
LEDs are ESD sensitive. Please observe appropriate precautions during handling and processing.
Broadcom
AV02-2936EN
February 16, 2018
ASMT-UWB1-Nxxxx
Data Sheet
OneWhite Surface-Mount PLCC-2 LED Indicator
Package Drawing
2.8 ± 0.2
2.2 ± 0.2
0.1 TYP.
1.9 ± 0.2
0.8 ± 0.1
3.2 ± 0.2
3.5 ± 0.2
0.8 ± 0.3
CATHODE MARKING
0.5 ± 0.1
NOTE:
1. All dimensions in millimeters.
2. Terminal finish = Ag plating.
Device Selection Guide
Luminous Intensity (mcd)
a, b
Color
White
White
White
White
White
White
White
White
White
White
White
White
White
White
Part Number
ASMT-UWB1-NX302
ASMT-UWB1-NX312
ASMT-UWB1-NX3A2
ASMT-UWB1-NX3B2
ASMT-UWB1-NX3C2
ASMT-UWB1-NX3D2
ASMT-UWB1-NX3E2
ASMT-UWB1-NX3F2
ASMT-UWB1-NX3G2
ASMT-UWB1-NX3H2
ASMT-UWB1-NX3J2
ASMT-UWB1-NX7B2
ASMT-UWB1-NX7D2
ASMT-UWB1-NX7C2
CCT (K)
4500 ~ 8000
2700 ~ 4000
8000
6500
5700
5000
4500
4000
3500
3000
2700
6500
5000
5700
Min.
1800
1800
1800
1800
1800
1800
1800
1800
1800
1800
1800
2240
2240
2240
Typ.
2300
2300
2300
2300
2300
2300
2300
2300
2300
2300
2300
-
-
-
Max.
3550
3550
3550
3550
3550
3550
3550
3550
3550
3550
3550
4500
4500
4500
Test Current
(mA)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Chip
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
a. The luminous intensity is measured at the mechanical axis of the lamp package. The actual peak of the spatial radiation pattern may not be
aligned with this axis.
b. Tolerance ±12%
Broadcom
AV02-2936EN
2
ASMT-UWB1-Nxxxx
Data Sheet
OneWhite Surface-Mount PLCC-2 LED Indicator
Part Numbering System
AS M T – U X
1
B1 – N X
2
X
3
X
4
X
5
Packaging Option
Color Bin Selection
Intensity Bin Selection
LED Chip Color
Absolute Maximum Ratings (T
A
= 25°C)
Parameters
DC Forward Current
a
Peak Forward Current
b
Power Dissipation
Junction Temperature
Operating Temperature
Storage Temperature
a. Derate linearly as shown in derating curve.
b. Duty factor = 10%, frequency = 1 kHz.
Rating
30 mA
100 mA
108 mW
110°C
–40°C to +100°C
–40°C to +100°C
Optical Characteristics (T
A
= 25°C)
Typ. Chromaticity
Coordinates
a
x
0.33
y
0.34
Viewing Angle
2
½b
(Degrees)
Typ.
120
Luminous
Efficiency
e
(lm/W)
Typ.
100
Total Flux /
Luminous
Intensity
V
(lm) / I
V
(cd)
Typ.
2.8
Color
White
Part Number
ASMT-UWB1
Dice
Technology
InGaN
CRI
Min.
70
a. The chromaticity coordinates are derived from the CIE 1931Chromaticity diagram and represents the perceived color of the device.
b.
½
is the off-axis angle where the luminous intensity is ½ the peak intensity.
Electrical Characteristics (T
A
= 25°C)
Forward Voltage
V
F
(Volts) @ I
F
= 20 mA
Color
White
Part Number
ASMT-UWB1
Min.
2.4
Max.
3.2
Reverse Voltage V
Ra
@ 10 µA
Min.
5
Thermal Resistance
R
J-P
(°C/W)
150
a. Reverse Voltage indicates product final test condition. Long-term reverse bias is not recommended.
Broadcom
AV02-2936EN
3
ASMT-UWB1-Nxxxx
Data Sheet
OneWhite Surface-Mount PLCC-2 LED Indicator
Figure 1: Forward Current vs. Forward Voltage
Figure 2: Relative Intensity vs. Forward Current
35
1.6
25
20
15
10
5
0
0
1
2
FORWARD VOLTAGE (V)
3
4
RELATIVE LUMINOUS INTENSITY
(NORMALIZED AT 20 mA)
30
1.4
1.2
1
0.8
0.6
0.4
0.2
0
0
5
10
15
20
25
DC FORWARD CURRENT (mA)
30
35
Figure 3: Chromaticity Shift vs. Current
0.003
0.002
30mA
FORWARD CURRENT (mA)
Figure 4: Radiation Pattern
1
NORMALIZED INTENSITY
0.0006
0.001
0
-0.001
Y
-0.002
-0.003
-0.004
-0.005
5mA
-0.001
-0.0006
10mA
20mA
0.75
0.5
0.25
-0.006
-0.0014
-0.0002 0 0.0002
X
0
-90
-60
-30
0
30
ANGULAR DISPLACEMENT ( )
60
90
Figure 5: Maximum Forward Current vs. Ambient
Temperature. Derated based on T
jmax
110°C, R
thja
600°C/W
Figure 6: Recommended Pb-Free Reflow Soldering Profile
35
MAXIMUM FORWARD CURRENT (mA)
30
25
20
15
10
5
0
0
20
40
60
80
AMBIENT TEMPERATURE (°C)
100
120
TEMPERATURE
217° C
200° C
150° C
3°C/SEC. MAX.
60 - 120 SEC.
TIME
(Acc. to J-STD-020C)
100 SEC. MAX.
10 - 30 SEC.
255 - 260° C
3°C/SEC. MAX.
6°C/SEC. MAX.
Broadcom
AV02-2936EN
4
