Contents
Product specifications are as of
February 2018
.
Part Numbering
1
Leaded MLCC for Automotive
RCE Series (DC25V-DC1kV)
o
Marking
Temperature Compensating Type, C0G/U2J Characteristics
High Dielectric Constant Type, X7R/X7S Characteristics
o
Specifications and Test Methods
2
150°C Operation Leaded MLCC for Automotive
RHE Series (DC25V-DC100V)
o
Marking
Temperature Compensating Type, X8G Characteristics
High Dielectric Constant Type, X8L Characteristics
o
Specifications and Test Methods
3
175°C/200°C Operation Leaded MLCC for Automotive
RHS Series (DC100V-DC500V)
o
Marking
Temperature Compensating Type, CCG/UNJ Characteristics
High Dielectric Constant Type, XAL/XAN Characteristics
o
Specifications and Test Methods
4
Leaded MLCC for General Purpose
RDE Series (DC25V-DC1kV)
o
Marking
Temperature Compensating Type, C0G/U2J Characteristics
High Dielectric Constant Type, X7R/X7S Characteristics
o
Specifications and Test Methods
5
Leaded MLCC for General Purpose
RDE Series Large Capacitance and High Allowable Ripple Current
(DC250V-DC630V)
o
Marking
High Dielectric Constant Type, X7T Characteristics
o
Specifications and Test Methods
Characteristics Reference Data (Typical Example)
Packaging
!Caution
Notice
p2
2
p4
p6
p6
p13
p17
3
p25
p26
p27
p28
p31
4
p34
p35
p35
p37
p38
5
p44
p45
p45
p52
p56
p60
p61
p61
p63
p66
p67
p69
p71
Please check the MURATA website (https://www.murata.com/)
if you cannot find a part number in this catalog.
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
C49E.pdf
May 10,2018
o
Part
Numbering
Leaded MLCC
(Part Number)
1Product
ID
2Series
Product ID
RC
RH
RH
RD
Series Code
E
E
S
E
Leaded MLCC for Automotive
150°C Operation Leaded MLCC for Automotive
175°C/200°C Operation Leaded MLCC for Automotive
Leaded MLCC for General Purpose
RC
1
E
R7 1H 104 K
4
5
0 M1 H03 A
9
:
2 3
6 7 8
3Temperature
Characteristics
Temperature Characteristic
Code
5C
5G
Public STD Code
Reference
Temperature
25°C
25°C
Temperature Characteristics
Temperature
Range
25 to 125°C
-55 to 25°C
25 to 150°C
-55 to 25°C
-55 to 25°C
7G
CCG
*1
25°C
25 to 125°C
125 to 200°C
-55 to 25°C
7J
UNJ
*1
25°C
25 to 125°C
125 to 200°C
7U
C7
D7
L1
L8
N1
R7
U2J
X7S
X7T
XAL
X8L
XAN
X7R
EIA
EIA
EIA
*1
*1
*1
EIA
25°C
25°C
25°C
25°C
25°C
25°C
25°C
25 to 125°C*2
-55 to 25°C
-55 to 125°C
-55 to 125°C
-55 to 175°C
-55 to 150°C
-55 to 175°C
-55 to 125°C
Capacitance Change or
Temperature Coefficient
0±30ppm/°C
0+30/-72ppm/°C
0±30ppm/°C
0+30/-72ppm/°C
0+30/-72ppm/°C
0±30ppm/°C
0+72/-30ppm/°C
-750+120/-347ppm/°C
-750±120ppm/°C
-750+347/-120ppm/°C
-750±120ppm/°C
-750+120/-347ppm/°C
±22%
+22%, -33%
+15%, -40%
+15%, -40%
+15%, -60%
±15%
-55 to 125°C
-55 to 125°C
-55 to 125°C
-55 to 175°C
-55 to 150°C
-55 to 175°C
-55 to 125°C
-55 to 200°C
-55 to 200°C
Operating
Temperature Range
C0G
X8G
EIA
*1
-55 to 125°C
-55 to 150°C
*1 Murata Temperature Characteristic Code.
*2 Rated Voltage 100Vdc max: 25 to 85°C
4Rated
Voltage
Code
1E
1H
2A
2D
2E
2W
2H
2J
3A
5Capacitance
Expressed by three figures. The unit is pico-farad (pF). The first
and second figures are significant digits, and the third figure
expresses the number of zeros that follow the two numbers.
If there is a decimal point, it is expressed by the capital letter "R."
In this case, all figures are significant digits.
Rated Voltage
DC25V
DC50V
DC100V
DC200V
DC250V
DC450V
DC500V
DC630V
DC1kV
6Capacitance
Tolerance
Code
C
D
J
K
M
Capacitance Tolerance
±0.25pF
±0.5pF
±5%
±10%
±20%
Continued on the following page.
2
!Note
• Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
