BUK7608-55A
N-channel TrenchMOS standard level FET
Rev. 03 — 14 June 2010
Product data sheet
1. Product profile
1.1 General description
Standard level N-channel enhancement mode Field-Effect Transistor (FET) in a plastic
package using TrenchMOS technology. This product has been designed and qualified to
the appropriate AEC standard for use in automotive critical applications.
1.2 Features and benefits
Low conduction losses due to low
on-state resistance
Q101 compliant
Suitable for standard level gate drive
sources
Suitable for thermally demanding
environments due to 175 °C rating
1.3 Applications
12 V and 24 V loads
Automotive systems
General purpose power switching
Motors, lamps and solenoids
1.4 Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
drain-source on-state
resistance
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
V
GS
= 10 V; T
mb
= 25 °C;
see
Figure 1;
see
Figure 3
T
mb
= 25 °C; see
Figure 2
V
GS
= 10 V; I
D
= 25 A;
T
j
= 175 °C; see
Figure 11;
see
Figure 12
V
GS
= 10 V; I
D
= 25 A;
T
j
= 25 °C; see
Figure 11;
see
Figure 12
[1]
Min
-
-
-
-
Typ
-
-
-
-
Max Unit
55
75
254
16
V
A
W
mΩ
Static characteristics
-
6.8
8
mΩ
Nexperia
BUK7608-55A
N-channel TrenchMOS standard level FET
Table 1.
Symbol
E
DS(AL)S
Quick reference data
…continued
Parameter
non-repetitive
drain-source
avalanche energy
gate-drain charge
Conditions
I
D
= 75 A; V
sup
≤
55 V;
R
GS
= 50
Ω;
V
GS
= 10 V;
T
j(init)
= 25 °C; unclamped
V
GS
= 0 V; I
D
= 25 A;
V
DS
= 44 V; T
j
= 25 °C;
see
Figure 13
Min
-
Typ
-
Max Unit
670
mJ
Avalanche ruggedness
Dynamic characteristics
Q
GD
-
35
-
nC
[1]
Continuous current is limited by package.
2. Pinning information
Table 2.
Pin
1
2
3
mb
Pinning information
Symbol Description
G
D
S
D
gate
drain
[1]
source
mounting base; connected to
drain
2
1
3
mb
D
Simplified outline
Graphic symbol
G
mbb076
S
SOT404 (D2PAK)
[1]
It is not possible to make a connection to pin 2.
3. Ordering information
Table 3.
Ordering information
Package
Name
BUK7608-55A
D2PAK
Description
Version
plastic single-ended surface-mounted package (D2PAK); 3 leads SOT404
(one lead cropped)
Type number
BUK7608-55A
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2017. All rights reserved
Product data sheet
Rev. 03 — 14 June 2010
2 of 14
Nexperia
BUK7608-55A
N-channel TrenchMOS standard level FET
4. Limiting values
Table 4.
Symbol
V
DS
V
DGR
V
GS
I
D
Limiting values
Parameter
drain-source voltage
drain-gate voltage
gate-source voltage
drain current
T
mb
= 25 °C; V
GS
= 10 V; see
Figure 1;
see
Figure 3
T
mb
= 100 °C; V
GS
= 10 V; see
Figure 1
T
mb
= 25 °C; V
GS
= 10 V; see
Figure 1;
see
Figure 3
I
DM
P
tot
T
stg
T
j
I
S
I
SM
E
DS(AL)S
peak drain current
total power dissipation
storage temperature
junction temperature
source current
peak source current
T
mb
= 25 °C
t
p
≤
10 µs; pulsed; T
mb
= 25 °C
[2]
[1]
[1]
In accordance with the Absolute Maximum Rating System (IEC 60134).
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
R
GS
= 20 kΩ
Min
-
-
-20
-
-
-
-
-
-55
-55
-
-
-
-
Typ
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Max
55
55
20
126
75
75
504
254
175
175
75
126
504
670
Unit
V
V
V
A
A
A
A
W
°C
°C
A
A
A
mJ
[2]
[2]
T
mb
= 25 °C; t
p
≤
10 µs; pulsed;
see
Figure 3
T
mb
= 25 °C; see
Figure 2
Source-drain diode
Avalanche ruggedness
non-repetitive drain-source I
D
= 75 A; V
sup
≤
55 V; R
GS
= 50
Ω;
avalanche energy
V
GS
= 10 V; T
j(init)
= 25 °C; unclamped
[1]
[2]
Current is limited by power dissipation chip rating.
Continuous current is limited by package.
BUK7608-55A
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2017. All rights reserved
Product data sheet
Rev. 03 — 14 June 2010
3 of 14
Nexperia
BUK7608-55A
N-channel TrenchMOS standard level FET
I
D
(A)
120
100
140
03nh50
120
P
der
(%)
80
03na19
80
60
40
20
0
25
50
75
100
125
150
175
200
T
mb
(°C)
0
Capped at 75 A due to package
40
0
50
100
150
T
mb
(°C)
200
Fig 1.
Continuous drain current as a function of
mounting base temperature
10
3
I
D
(A)
R
DSon
= V
DS
/ I
D
Fig 2.
Normalized total power dissipation as a
function of mounting base temperature
03nh48
t
p
= 10
µs
100
µs
Capped at 75 A due to package
DC
1 ms
10 ms
100 ms
10
2
10
1
1
10
V
DS
(V)
10
2
Fig 3.
Safe operating area; continuous and peak drain currents as a function of drain-source voltage
BUK7608-55A
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2017. All rights reserved
Product data sheet
Rev. 03 — 14 June 2010
4 of 14
Nexperia
BUK7608-55A
N-channel TrenchMOS standard level FET
5. Thermal characteristics
Table 5.
Symbol
R
th(j-mb)
R
th(j-a)
Thermal characteristics
Parameter
Conditions
Min
-
-
Typ
-
50
Max
0.59
-
Unit
K/W
K/W
thermal resistance from junction see
Figure 4
to mounting base
thermal resistance from junction mounted on printed-circuit
to ambient
board ; minimum footprint
1
Z
th(j-mb)
(K/W)
10
−1
03nh49
δ
= 0.5
0.2
0.1
0.05
0.02
t
p
T
10
−2
Single Shot
P
δ
=
t
p
t
T
10
−3
10
−6
10
−5
10
−4
10
−3
10
−2
10
−1
t
p
(s)
1
Fig 4.
Transient thermal impedance from junction to mounting base as a function of pulse duration
BUK7608-55A
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2017. All rights reserved
Product data sheet
Rev. 03 — 14 June 2010
5 of 14
