MR10Q010
1 Mb High Speed Quad SPI MRAM
FEATURES
•
•
•
•
•
High bandwidth – Read and Write at 52MB/sec
Quad I/O with the use of dual purpose pins to maintain a low pin count
Operates in both standard, single SPI mode and high speed quad SPI mode
RoHS
Fast quad Read and Write with quad address input and quad I/O
Intended for next generation RAID controllers, server system logs, storage device
buffers, and embedded system data and program memory
• Data is non-volatile with retention greater than 20 years
• Automatic data protection on power loss
• Unlimited write endurance
• Low-current sleep mode
• Dual 3.3v V
DD
/ 1.8v V
DDQ
power supply
• Tamper Detect function will detect possible data modification from outside mag-
netic fields.
• Quad Peripheral Interface (QPI) mode is supported to enhance system performance
for Execute in Place (XIP) operation.
• MSL Level 3.
16-SOIC
24-BGA
DESCRIPTION
The MR10Q010 is the ideal memory solution for applications that must store and retrieve data and programs quickly
using a small number of pins, low power, and choice of a 24-ball BGA or a 16-pin SOIC package. The four I/O’s in Quad
SPI mode allow very fast reads and writes, making it an attractive alternative to conventional parallel data bus inter-
faces in next generation RAID controllers, server system logs, storage device buffers, and embedded system data and
program memory.
Using Everspin’s patented MRAM technology, both reads and writes can occur randomly in memory with no delay
between writes.
Standard Serial Peripheral Interface (SPI), Quad SPI and Quad Peripheral Interface (QPI) modes are supported at a clock
rate up to 104MHz. XIP operation is supported for Read commands in all three modes.
The MR10Q010 Quad SPI MRAM is organized as 131,072 words of 8 bits.
Operational Overview
Mode
SPI Mode
Command Set
Read 40MHz. Write, Fast Read
104MHz
Quad I/O mode Read/Write data,
or both address and data
Enables command instruction
entry in quad I/O mode. (2 clocks)
Utility Commands
Write Enable/Disable, Sleep Mode, Read/Write
Status Register, Tamper Detect, Read Device ID,
Enable QPI Mode
None.
Disable QPI Mode.
XIP Command Operation
Fast Read
Fast Read Quad Output, Fast Read
Quad Address and Data
Fast Read, Fast Read Quad Output,
Fast Read Quad Address and Data
Quad SPI Mode
QPI Mode
Copyright © 2018 Everspin Technologies, Inc.
1
MR10Q010 Revision 5.6, 6/2018
MR10Q010
TABLE OF CONTENTS
Operational Overview ....................................................................................................................1
OVERVIEW ............................................................................................................................................7
Table 1 – Operational Parameters Summary ...................................................................................................... 7
Operation in 3.3v Data Bus Systems - Evaluation Board Available .............................................7
Figure 1 – MR10Q010 Block Diagram .................................................................................................................... 8
Figure 2 – System Configuration............................................................................................................................. 9
Figure 3 – 16-SOIC Package Pin Assignments ..................................................................................................10
Table 2 – 16-SOIC Pin Functions ............................................................................................................................10
Figure 4 – 24-BGA Package Ball Assignments ..................................................................................................12
Table 3 – 24-BGA Ball Functions ............................................................................................................................12
STATUS REGISTER ............................................................................................................................. 14
Table 4 – Status Register Bit Definitions .............................................................................................................14
Memory Protection Modes .......................................................................................................... 15
Table 5 – Memory Protection Modes ..................................................................................................................15
Block Protection Modes ............................................................................................................... 15
Table 6 – Block Memory Write Protection..........................................................................................................15
SPI COMMUNICATIONS PROTOCOL ................................................................................................ 16
SPI MODE COMMANDS .................................................................................................................... 16
Table 7 – SPI Mode Commands Overview .........................................................................................................17
SPI Mode Commands Overview .................................................................................................. 17
Read Status Register (RDSR) ........................................................................................................ 18
Figure 5 – Read Status Register (RDSR) Command Operation ..................................................................18
Write Enable (WREN) .................................................................................................................... 19
Figure 6 – Write Enable (WREN) Command Operation ................................................................................19
Write Disable (WRDI) .................................................................................................................... 20
Figure 7 – Write Disable (WRDI) Command Operation ................................................................................20
Copyright © 2018 Everspin Technologies, Inc.
2
MR10Q010 Revision 5.6, 6/2018
MR10Q010
Table of Contents (Cont’d)
Write Status Register (WRSR) ...................................................................................................... 21
Figure 8 – Write Status Register (WRSR) Command Operation ................................................................21
Read Data Bytes (READ) ............................................................................................................... 22
Figure 9 – Read Data Bytes (READ) Command Operation ...........................................................................22
Fast Read Data Bytes (FREAD) ..................................................................................................... 23
Figure 10 – Fast Read Data Bytes (FREAD) Command Operation .............................................................23
Write Data Bytes (WRITE) ............................................................................................................. 24
Figure 11 – Write Data Bytes (WRITE) Command Operation ......................................................................24
Enter Sleep Mode (SLEEP) ............................................................................................................ 25
Figure 12 – Enter Sleep Mode (SLEEP) Command Operation .....................................................................25
Exit Sleep Mode (WAKE)............................................................................................................... 26
Figure 13 – Exit Sleep Mode (WAKE) Command Operation ........................................................................26
Tamper Detect (TDET) .................................................................................................................. 27
Figure 14 – Tamper Detect (TDET) Command Operation ............................................................................27
Tamper Detect Exit (TDETX) ........................................................................................................ 28
Figure 15 – Tamper Detect Exit (TDETX) Command Operation .................................................................28
Read ID (RDID) .............................................................................................................................. 29
Figure 16 – Read ID (RDID) Command Operation...........................................................................................29
Table 8 – Device ID for MR10Q010 .......................................................................................... 30
QUAD SPI MODE COMMANDS ......................................................................................................... 31
Quad SPI Mode Commands Overview ........................................................................................ 31
Table 9 – Quad SPI Mode Commands Overview .............................................................................................31
Fast Read Quad Output (FRQO) .................................................................................................. 32
Figure 17 – Fast Read Quad Output (FRQO) Command Operation ..........................................................33
Fast Read Quad Address and Data (FRQAD) .............................................................................. 34
Figure 18 – Fast Read Quad Address and Data (FRQAD) Command Operation ..................................35
Copyright © 2018 Everspin Technologies, Inc.
3
MR10Q010 Revision 5.6, 6/2018
MR10Q010
Table of Contents (Cont’d)
Fast Write Quad Data (FWQD)...................................................................................................... 36
Figure 19 – Fast Write Quad Data (FWQD) Command Operation .............................................................36
Fast Write Quad Address and Data (FWQAD) ............................................................................. 37
Figure 20 – Fast Write Quad Address and Data (FWQAD) Command Operation ................................37
QPI MODE .......................................................................................................................................... 38
Table 10 – SPI Mode Command Structures in QPI Mode .............................................................................38
Table 11 – Quad SPI Mode Command Structures in QPI Mode .................................................................39
Enable QPI (EQPI) Command ....................................................................................................... 40
Figure 21 – Enable QPI Mode (EQPI) Command Operation .......................................................................40
Disable QPI (DQPI) Command ..................................................................................................... 41
Figure 22 – Disable QPI Mode (DQPI) Command Timing ............................................................................41
EXECUTE IN PLACE (XIP) MODE....................................................................................................... 42
Table 12 – Mode Byte Definitions to Set/Reset XIP Mode ...........................................................................42
Table 13 – XIP Mode with FREAD Command....................................................................................................43
Figure 23 – FREAD Command- Set XIP Mode - Initial Access .....................................................................44
Figure 24 – FREAD Command - XIP Mode Set - Next Access .....................................................................45
Figure 25 – FREAD Command - XIP Mode Exit .................................................................................................46
Table 14 – XIP Operation with FRQO Command .............................................................................................47
Figure 26 – FRQO Command - Set XIP Mode - Initial Access ....................................................................48
Figure 27 – FRQO Command - XIP Mode Set - Next Access .......................................................................49
Figure 28 – FRQO Command - XIP Mode Exit...................................................................................................50
Table 15 – XIP Operation with FRQAD Command ..........................................................................................51
Figure 29 – FRQAD Command - Set XIP Mode - Initial Access ..................................................................52
Figure 30 – FRQAD Command - XIP Mode Set - Next Access ....................................................................53
Figure 31 – FRQAD Command - XIP Mode Exit ................................................................................................54
ELECTRICAL SPECIFICATIONS ......................................................................................................... 55
Copyright © 2018 Everspin Technologies, Inc.
4
MR10Q010 Revision 5.6, 6/2018
MR10Q010
Table of Contents (Cont’d)
Table 16 – Absolute Maximum Ratings ...........................................................................................................55
Table 17 – Operating Conditions ..........................................................................................................................56
Table 18 – DC Characteristics .................................................................................................................................56
Table 19 – Power Supply Characteristics............................................................................................................57
Table 20 – Capacitance .............................................................................................................................................57
TIMING SPECIFICATIONS ................................................................................................................. 58
AC Measurement Conditions ....................................................................................................... 58
Table 21 – AC Measurement Conditions ............................................................................................................58
Figure 32 – Output Load for Impedance Parameter Measurements .......................................................58
Figure 33 – Output Load for all Other Parameter Measurements.............................................................58
Power Up Timing .......................................................................................................................... 59
Table 22 – Power-Up Delay Minimum Voltages and Timing .......................................................................59
Figure 34 – Power-Up Timing ................................................................................................................................60
AC Timing Parameters .................................................................................................................. 61
Table 23 – AC Timing Parameters .........................................................................................................................61
Figure 35 – Synchronous Data Timing (READ) .................................................................................................63
Figure 36 – Synchronous Data Timing Fast Read (FREAD) ...........................................................................63
Figure 37 – Synchronous Data Timing (WRITE) ...............................................................................................64
Figure 38 – Synchronous Data Timing Fast Write Quad Data and Fast Write Quad Address and
Data (FWQD and FWQAD) ..............................................................................................................................64
Figure 39 –
HOLD
Timing .......................................................................................................................................65
PART NUMBERS AND ORDERING .................................................................................................... 66
Table 24 – Part Numbering System ......................................................................................................................66
Table 25 – Ordering Part Numbers .......................................................................................................................66
PACKAGE CHARACTERISTICS .......................................................................................................... 67
Copyright © 2018 Everspin Technologies, Inc.
5
MR10Q010 Revision 5.6, 6/2018
