Surge arrester
2-electrode arrester
B88069X4681B152
V13-C500X
Features
Standard size
Maximum current rating
Fast response time
Stable performance over life
Low capacitance
High insulation resistance
RoHS-compatible
Applications
AC power line N-PE application
Class II – surge protection
Electrical specifications
DC spark-over voltage
1) 2)
Front of wave spark-over voltage
- at 1.2/50 µs, 6 kV, for 99% of measured values
Breakdown time
- typical values
Insulation resistance at 100 V
DC
Class II according to IEC 61643-11
Max. continuous operating voltage at 50/60 Hz
Nominal discharge current 8/20 µs
Maximum discharge current 8/20 µs
Follow current at 50/60 Hz
AC discharge current (TOV
3)
at 1200 V)
1 operation
50 Hz, 0.2 s
Weight
Operation and storage temperature
U
c
I
n
I
max
I
f
450 … 850
V
< 1500
< 100
< 20
>1
230
20
40
100
300
~8
-40 ... +90
40/090/21
500 MMY O
500
MM
Y
O
- Nominal voltage
- Month of production
- Year of production
- Non radioactive
V
ns
ns
GΩ
V
kA
kA
A
A
g
°C
Climatic category (IEC 60068-1)
Marking, black positive
Certification
1)
2)
3)
UL 497B (E163070)
At delivery AQL 0.65 level II, DIN ISO 2859
In darkness without storage
TOV – Temporary over voltage
