569AAAA000118BBG datasheet, PDF

Datasheet> All Categories > Passive components> Frequency controller and a timer> oscillator> VCXO oscillator> 569AAAA000118BBG

Preview

569AAAA000118BBG: DescriptionVCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz; CategoryPassive components Frequency controller and a timer oscillator VCXO oscillator; File Size1MB，35 Pages; ManufacturerSilicon Labs; Websitehttps://www.silabs.com

Download Datasheet Parametric Compare View All

569AAAA000118BBG Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	569AAAA000118BBG	-	-	View	Buy Now

569AAAA000118BBG Overview

VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz

569AAAA000118BBG Parametric

Parameter Name	Attribute value
Maker	Silicon Labs
Product Category	VCXO Oscillator
Package/box	3.2 mm x 5 mm
frequency	0.2 MHz to 3000 MHz
frequency stability	20 PPM
load capacitance	5 pF
Working power voltage	2.5 V, 3.3 V
Supply voltage - min.	2.375 V
Supply voltage - max.	3.465 V
Output format	LVPECL
Termination type	SMD/SMT
Minimum operating temperature	- 40 C
Maximum operating temperature	+ 85 C
length	5 mm
high	1.17 mm
width	3.2 mm
series	Si569
Current rating	120 mA
Duty Cycle - Max	55 %
Installation style	SMD/SMT

Preview

Download Datasheet

View All

Ultra Series

™

Crystal Oscillator (VCXO)

Si569 Data Sheet

Ultra Low Jitter I2C Programmable VCXO (100 fs), 0.2 to

3000 MHz

The Si569 Ultra Series

™

voltage-controlled crystal oscillator utilizes Silicon

Laboratories’ advanced 4

generation DSPLL

technology to provide an ul-

tra-low jitter, low phase noise clock at any output frequency. The device is

user-programmed via simple I2C commands to provide any frequency from

0.2 to 3000 MHz with <1 ppb resolution and maintains exceptionally low jitter

for both integer and fractional frequencies across its operating range. On-

chip power supply filtering provides industry-leading power supply noise re-

jection, simplifying the task of generating low jitter clocks in noisy systems

that use switched-mode power supplies. Unlike a traditional XO, where a dif-

ferent crystal is required for each output frequency, the Si569 uses one sim-

ple crystal and a DSPLL IC-based approach to provide the desired output

frequency. The Si569 is factory-configurable for a wide variety of user speci-

fications, including startup frequency, I2C address, output format, and OE

pin location/polarity. Specific configurations are factory-programmed at time

of shipment, eliminating long lead times associated with custom oscillators.

Pin Assignments

SDA

VDD

KEY FEATURES

• I2C programmable to any frequency from 0.2 to

3000 MHz with < 1 ppb resolution

• Ultra low jitter: 100 fs RMS Typ (12 kHz – 20 MHz)

• Configure up to 2 pin-selectable startup frequencies

• I2C interface supports 100 kbps, 400 kbps, and 1

Mbps (Fast Mode Plus)

• Excellent PSRR and supply noise immunity: –80

dBc Typ

• Programmable Kv (ppm/V) simplifies development

• 3.3 V, 2.5 V and 1.8 V V

supply operation from

the same part number

• LVPECL, LVDS, CML, HCSL, CMOS, and Dual

CMOS output options

• 3.2x5, 5x7 mm package footprints

• Samples available with 1-2 week lead times

APPLICATIONS

• 100G/200G/400G OTN, coherent optics, PAM4

• 3G-SDI/12G-SDI/24G-SDI broadcast video

• Servers, switches, storage, search acceleration

• FPGA/ASIC clocking

OE/FS

GND

SCL

(Top View)

CLK–

CLK+

Pin #

VC = Voltage Control Pin

Descriptions

OSC

Fixed

Frequency

Crystal

Frequency

Flexible

DSPLL

DCO

Low

Noise

Driver

Selectable via ordering option

OE = Output enable; FS = Frequency Select

GND = Ground

CLK+ = Clock output

CLK- = Complementary clock output. Not used for CMOS.

VDD = Power supply

SDA = I2C Serial Data

SCL = I2C Serial Clock

ADC

Control

Digital

Phase

Detector

Phase Error

Cancellation

Phase Error

Fractional

Divider

Digital

Loop

Filter

Flexible

Formats,

1.8V – 3.3V

Operation

NVM

Power Supply Regulation

OE, Frequency Select

(I2C and Pin Control)

Built-in Power Supply

Noise Rejection

silabs.com

| Building a more connected world.

Rev. 1.1

569AAAA000118BBG Related Products

	569AAAA000118BBG	569AAAA000368ABG	569AAAA000122BBG	569AACA002014ABG	569AAAA002024ABG	569BABB001677ABG	569BAAA000118BBG	569AAAA002020ABG
Description	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz	VCXO OscillatorDifferential/single-ended Any (I2C) VCXO; 0.2-3000 MHz
Maker	Silicon Labs	Silicon Labs	Silicon Labs	Silicon Labs	Silicon Labs	Silicon Labs	Silicon Labs	Silicon Labs
Product Category	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator	VCXO Oscillator
Package/box	3.2 mm x 5 mm	5 mm x 7 mm	3.2 mm x 5 mm	5 mm x 7 mm	5 mm x 7 mm	5 mm x 7 mm	3.2 mm x 5 mm	5 mm x 7 mm
frequency	0.2 MHz to 3000 MHz	0.2 MHz to 3000 MHz	0.2 MHz to 3000 MHz	0.2 MHz to 3000 MHz	0.2 MHz to 3000 MHz	0.2 MHz to 1500 MHz	0.2 MHz to 3000 MHz	0.2 MHz to 3000 MHz
frequency stability	20 PPM	20 PPM	20 PPM	20 PPM	20 PPM	20 PPM	20 PPM	20 PPM
load capacitance	5 pF	5 pF	5 pF	5 pF	5 pF	5 pF	5 pF	5 pF
Working power voltage	2.5 V, 3.3 V	2.5 V, 3.3 V	2.5 V, 3.3 V	2.5 V, 3.3 V	2.5 V, 3.3 V	1.8 V, 2.5 V, 3.3 V	1.8 V, 2.5 V, 3.3 V	2.5 V, 3.3 V
Supply voltage - min.	2.375 V	2.375 V	2.375 V	2.375 V	2.375 V	1.71 V	1.71 V	2.375 V
Supply voltage - max.	3.465 V	3.465 V	3.465 V	3.465 V	3.465 V	3.465 V	3.465 V	3.465 V
Output format	LVPECL	LVPECL	LVPECL	LVPECL	LVPECL	LVDS	LVDS	LVPECL
Termination type	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT
length	5 mm	7 mm	5 mm	7 mm	7 mm	7 mm	5 mm	7 mm
high	1.17 mm	1.18 mm	1.17 mm	1.18 mm	1.18 mm	1.18 mm	1.17 mm	1.18 mm
width	3.2 mm	5 mm	3.2 mm	5 mm	5 mm	5 mm	3.2 mm	5 mm
series	Si569	Si569	Si569	Si569	Si569	Si569	Si569	Si569
Current rating	120 mA	120 mA	120 mA	120 mA	120 mA	100 mA	100 mA	120 mA
Duty Cycle - Max	55 %	55 %	55 %	55 %	55 %	55 %	55 %	55 %
Installation style	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT
Minimum operating temperature	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	-
Maximum operating temperature	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	-
Shipping restrictions	-	Mouser does not currently sell this product.	Mouser does not currently sell this product.	Mouser does not currently sell this product.	-	Mouser does not currently sell this product.	-	Mouser does not currently sell this product.
Factory packaging quantity	-	50	50	50	50	50	-	50
