This document was generated on 08/01/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0787180002
Active
Serial Attached SCSI (SAS) Connectors
1.27mm Signal Pitch, 0.80mm Signal Pitch, 1.27mm Power Pitch SAS 12G Receptacle,
Right Angle, Surface Mount, with Blade, 2.85mm Height, 3.50mm Peg Length, 1.60mm
PCB Thickness, 29 Circuits, with Cap, Embossed Tape and Reel, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-78718-001 (PDF)
Product Specification TS-78718-001-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Comments
Component Type
Electrical Model
Overview
Product Name
Type
UPC
Physical
Circuits (Loaded)
Circuits Detail
Color - Resin
Durability (mating cycles max)
Flammability
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Surface Mount Compatible (SMC)
Application Specification AS-78718-001-001 (PDF)
Packaging Specification PK-78718-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
LR19980
E29179
I/O Connectors
78718
Board-to-Board
With Cap
Receptacle
Yes
Serial Attached SCSI (SAS) Connectors
SAS 12G
N/A
887191897523
29
Signal 14, Power 15
Black
500
94V-0
Female
Yes
None
Copper Alloy
Gold
Tin
Liquid Crystal Polymer
1.910/g
2
Right Angle
Yes
Yes
1.60mm
Embossed Tape on Reel
No
0.80mm, 1.27mm
0.80mm, 1.27mm
0.762µm
2.540µm
Yes
Yes
Yes
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
78718 Series
Mates With
SFF-8482 and SFF-8680 Plugs|SAS / SATA
Plugs
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Application Specification
Electrical Model Document
Packaging Specification
Product Specification
S-Parameter Model
Sales Drawing
0°C to +55°C
Surface Mount
No
1.5A
30V
010
REFLOW
001
260
AS-78718-001-001
EE-78718-001, EE-78718-002
PK-78718-001
PS-78718-001, TS-78718-001-001
SP-78718-001, SP-78718-002
SD-78718-001-001
