45115-0203 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Wire/cable> Cable package> Private sidings> 45115-0203

Preview

45115-0203: DescriptionSpecial line MicroLock Plus Blue 2CKT 300MM; CategoryWire/cable Cable package Private sidings; File Size160KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric Compare View All

45115-0203 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	45115-0203	-	-	View	Buy Now

45115-0203 Overview

Special line MicroLock Plus Blue 2CKT 300MM

45115-0203 Parametric

Parameter Name	Attribute value
Maker	Molex
Product Category	dedicated line
product	Sensor / Actuator Cables
Connector port A	Socket
Connector Port A Pin Count	2 Position
Connector port B	Socket
Connector Port B Pin Count	2 Position
length	300 mm
Type	Female / Female
Number of conductors	2 Conductor
color	Blue
Shell material	Polyvinyl Chloride (PVC)
series	45115
Factory packaging quantity	250

Preview

Download Datasheet

View All

9

8

7

6

5

4

3

2

1

E

ITEM

A,C

B

D

MOLEX NO

5055650204

5054311000

884260070

DESCRIPTION

1.25WTB SINGLE REC HSG 2CKT BLUE

1.25 ROBUST W/B CRIMP TERM.

PAPER PRINTED PAPER WHITE (S100X150YAJ)

QTY

2

4

1

UOM

PC

CKT NO

WIRE #

COLOR

DESCRIPTION

E

From To

A1

A2

C2

1X26AWG DISC PVC BK 0.98MM UL1061

884530501

BLACK

HOOKUP

C1

L1

2

L2

1

D

1

B

TABLE

C

A

SEE DETAIL A

C

B

2

PART NUMBER

L1

50

±

5

100

±

8

150

±

10

300

±

10

450

±

15

600

±

15

L2

18REF

44REF

69REF

144REF

219REF

294REF

TITLE

C

451150200

451150201

451150202

451150203

451150205

451150206

B

Microlock Plus Cable Blue 2-ckt 50MM

Microlock Plus Cable Blue 2-ckt 100MM

Microlock Plus Cable Blue 2-ckt 150MM

Microlock Plus Cable Blue 2-ckt 300MM

Microlock Plus Cable Blue 2-ckt 450MM

Microlock Plus Cable Blue 2-ckt 600MM

B

2017/10/23

NOTES

1. This product must meet 2011/65/EC ROHS compliance.

2. Cable assembly to be tested 100% for continuity and polarity.

3. Label text must be 2mm max. In height with Arial font.

4. Connector view shown is from mating side.

QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION

DIMENSION UNITS

SCALE

SYMBOLS

GENERAL

=

0

TOLERANCES

(UNLESS SPECIFIED)

ANGULAR TOL ±

°

mm

DRWN BY

DATE

NTS

EC NO:

167026

DRWN:

RDESAI01

CHK'D:

APPR:

MNARAYAN01

A

P/N:45115XXXX

MOLEX

Batch WK/YR

MOLEX PN

=

4 PLACES

3 PLACES

2 PLACES

1 PLACE

0 PLACES

±

RDESAI01

CHK'D BY

DATE

2017/07/11

MICROLOCK PLUS CABLE BLUE 2-CKT

0

A

APPR BY

DATE

±

PRODUCT CUSTOMER DRAWING

2017/07/14

SERIES

MATERIAL NUMBER

CUSTOMER

DETAIL A

C

=

MNARAYAN01

DRAWING SIZE

THIRD ANGLE PROJECTION

RELEASE STATUS

FORMAT: master-tb-prod-A3

REVISION: G

DATE: 2015/12/14

P1

RELEASE DATE

23.10.2017

11:13:25

=

B

REV

DRAFT WHERE APPLICABLE

MUST REMAIN

WITHIN DIMENSIONS

45115

DOCUMENT NUMBER

SEE TABLE

GENERAL MARKET

DOC TYPE

DOC PART

SHEET NUMBER

A3

3

451150200

PSD

000

1 OF 1

9

8

7

6

5

4

2

1

45115-0203 Related Products

	45115-0203	45115-0202	45115-0200	45115-0205	45115-0201	45115-0206
Description	Special line MicroLock Plus Blue 2CKT 300MM	Special line MicroLock Plus Blue 2CKT 150MM	Special line MicroLock Plus Blue 2CKT 50MM	Special line MicroLock Plus Blue 2CKT 450MM	Special line MicroLock Plus Blue 2CKT 100MM	Special line MicroLock Plus Blue 2CKT 600MM
Maker	Molex	Molex	Molex	Molex	Molex	Molex
Product Category	dedicated line	dedicated line	dedicated line	dedicated line	dedicated line	dedicated line
product	Sensor / Actuator Cables	Sensor / Actuator Cables	Sensor / Actuator Cables	Sensor / Actuator Cables	Sensor / Actuator Cables	Sensor / Actuator Cables
Connector port A	Socket	Socket	Socket	Socket	Socket	Socket
Connector Port A Pin Count	2 Position	2 Position	2 Position	2 Position	2 Position	2 Position
Connector port B	Socket	Socket	Socket	Socket	Socket	Socket
Connector Port B Pin Count	2 Position	2 Position	2 Position	2 Position	2 Position	2 Position
length	300 mm	150 mm	50 mm	450 mm	100 mm	600 mm
Type	Female / Female	Female / Female	Female / Female	Female / Female	Female / Female	Female / Female
Number of conductors	2 Conductor	2 Conductor	2 Conductor	2 Conductor	2 Conductor	2 Conductor
color	Blue	Blue	Blue	Blue	Blue	Blue
Shell material	Polyvinyl Chloride (PVC)	Polyvinyl Chloride (PVC)	Polyvinyl Chloride (PVC)	Polyvinyl Chloride (PVC)	Polyvinyl Chloride (PVC)	Polyvinyl Chloride (PVC)
series	45115	45115	45115	45115	45115	45115
Factory packaging quantity	250	500	500	250	500	250
