RI-0509S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Analog mixed-signal IC> RI-0509S

RI-0509S: Description1-OUTPUT 2 W DC-DC UNREG PWR SUPPLY MODULE; Categorysemiconductor Analog mixed-signal IC; File Size1MB，5 Pages; ManufacturerRECOM Power GmbH; Websitehttps://www.recom-power.com/

Download Datasheet Parametric View All

RI-0509S Overview

1-OUTPUT 2 W DC-DC UNREG PWR SUPPLY MODULE

RI-0509S Parametric

Parameter Name	Attribute value
Rated input voltage	24 V
Number of functions	1
Number of terminals	4
Minimum operating temperature	-40 Cel
Maximum operating temperature	85 Cel
Rated output voltage	15 V
Minimum output voltage	14.25 V
Maximum output voltage	15.75 V
Maximum total output power	2 W
Processing package description	ROHS COMPLIANT, SIP-4
each_compli	Yes
EU RoHS regulations	Yes
state	Contact Mfr
Analog IC other types	DC-DC UNREGULATED POWER SUPPLY MODULE
Minimum input voltage	21.6 V
Maximum input voltage	26.4 V
jesd_30_code	R-XSMA-P4
load_regulation_max	10 %
moisture_sensitivity_level	NOT SPECIFIED
Number of outputs	1
Maximum output current	0.1330 A
Packaging Materials	UNSPECIFIED
ckage_equivalence_code	SIP4,.24
packaging shape	RECTANGULAR
Package Size	MICROELECTRONIC ASSEMBLY
eak_reflow_temperature__cel_	NOT SPECIFIED
qualification_status	COMMERCIAL
seated_height_max	10.45 mm
sub_category	Other Analog ICs
surface mount	NO
Craftsmanship	HYBRID
Temperature level	Industrial
terminal coating	NOT SPECIFIED
Terminal form	PIN/PEG
Terminal spacing	2.54 mm
Terminal location	SINGLE
ime_peak_reflow_temperature_max__s_	NOT SPECIFIED
im_adjustable_output__v_	NO
length	11.5 mm
width	7.55 mm

Preview

Download Datasheet

View All

Features

Unregulated

Converters

Description

• 1kVDC/1 second basic isolation

• Optional continuous short circuit protection

• UL94 V-0 package material

• No heatsink required

• Efficiency up to 85%

DC/DC Converter

The RI series has been specifically designed for applications where board space is at a premium since

these 2 Watt converters have only a slightly larger foot print than the RO series 1 Watt converters. With

efficiencies up to 85%, the full output power is available over the operating temperature range -40°C to

+85°C and the converters can be used in ambient temperatures of up to 100°C with derating. The wide

selection of input voltage and output voltage options plus an I/O-Isolation of 1kVDC as standard makes

these converters suitable for many industrial applications.

2 Watt

SIP4

Sinlge Output

Selection Guide

Part

Number

RI-xx05S

(3)

RI-xx12S

(3)

RI-xx15S

(3)

nom. Input

Voltage

[VDC]

5, 12, 15, 24

Output

Voltage

[VDC]

Output

Current

[mA]

400

167

133

Efficiency

typ.

(1)

[%]

78-83

80-85

max. Capacitive

Load

(2)

[µF]

1200

680

Notes:

Note1: Efficiency is tested at nominal input and full load at +25°C ambient

Note2: Max Cap Load is tested at nominal input and full resistive load and is defined as the

capacitive load that will allow start up in under 1s without damage to the converter

Model Numbering

RI- __ __S/_

Input Voltage

Output Voltage

Protection

(3)

Single

EN60950-1 certified

IEC60950-1 certified

Notes:

Note3: standard part is without Continuous Short Circuit Protection

add suffix „/P“ for Continuous Short Circuit Protection

Ordering Examples:

RI-123.3S/P: 12V Input Voltage, 3.3V Output Voltage, Single Output with continuous short circuit protection

RI-0509S: 5V Input Voltage, 9V Output Voltage, Single Output

www.recom-power.com

REV.: 1/2018

ECO-1
