7 0 Wat t O pen F ra me Switch in g Power S uppl y with P FC
70 Watts Output Power
Universal 85-265VAC Input
1, 2, 3, and 4 Outputs
REL70
series
Active Power Factor Correction
2.5VDC to 48VDC Outputs
4.5” x 2.5” x 1.22”
Model Number
SINGLE OUTPUT
REL70-1001
REL70-1002
REL70-1003
REL70-1004
REL70-1005
REL70-1006
REL70-1007
REL70-1008
DUAL OUTPUT
REL70-2001
REL70-2002
REL70-2003
REL70-2004
REL70-2005
TRIPLE OUTPUT
REL70-3001
REL70-3002
QUAD OUTPUT
REL70-4001
REL70-4002
REL70-4003
REL70-4004
REL70-4005
REL70-4006
REL70-4007
Output #1
Output #2
Output #3
Output #4
Medical Versions Available
Contact Factory
2.5V/14A
3.3V/14A
5V/14A
12V/5.8A
15V/4.7A
24V/2.9A
28V/2.5A
48V/1.5A
3.3V/6A
5V/6A
5V/6A
12V/3A
15V/3A
5V/6A
5V/6A
3.3V/6A
5V/6A
5V/6A
5V/6A
5V/6A
5V/6A
5V/6A
5V/5A
12V/4A
24V/2A
-12V/3A
-15V/2A
12V/2A
15V/2A
5V/5A
3.3V/5A
3.3V/5A
-5V/5A
-5V/5A
24V/2A
24V/2A
12V/2A
12V/2A
15V/2A
12V/2A
15V/2A
12V/2A
15V/2A
Order On-Line!
astrodyne.com
-12V/2A
-15V/2A
-12V/2A
-12V/2A
-15V/2A
-12V/2A
-15V/2A
-12V/2A
-15V/2A
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
WWW.ASTRODYNE.COM
7 0 Wat t O pen F ra me Switch in g Power S uppl y with P FC
INPUT SPECIFICATIONS
Input Voltage, Full Range:
Active PFC
Input Frequency
Inrush Current
Leakage Current
85-264 VAC
>0.95@115VAC
47-63Hz.
30A @ 115VAC, typ
4
40A @ 230VAC, typ
4
<300uA @ 240VAC
REL70
0 to +60 °C
4
10-95%, Description
4
-40 to +85 °C
4
100KHrs
MIL-Std 217F
To MIL-Std 810E
series
ENVIRONMENTAL SPECIFICATIONS
Oper. Temperature
Relative Humidity
Storage Temperature
MTBF
Shock & Vibration
OUTPUT SPECIFICATIONS
Output Power
Minimum Load Requirement
Max Current (A, Peak)
Initial Accuracy
Voltage Adjust
Load Regulation
Cross Regulation
Line Regulation
Temperature Coefficient
Ripple/Noise
Overvoltage Protection
Remote Sense (Singles Only)
Hold Up/Start Up Times
Short Circuit Protection
Current Limit
50W, Conv/70W Forced Air
10%
See Model Selection Chart
7
+/-1%, typ
± 8%, typ
± 1%, typ
+/-5%
± 0.5%, typ
± 0.02%/°C
100mV Pk-Pk, typ
110-150%, Type
2
&
3
250mV compensation
16mS/4Sec, typ
Continuous
4
110-160% typ, Auto Recovery
PHYSICAL SPECIFICATIONS
Dimensions
Material Flammability
Construction
Weight
4.5”x2.5”x1.22”
to UL94V-0
Open Frame
0.6lb
SPECIFICATION NOTES
1) All specifications typical @ 25°C, Nominal Line & Load, unless otherwise
noted.
2) O/P noise measured directly at pins/terminals with 0.1uFbypass, pk-pk @
20MHz bandwidth.
3) Ripple and Noise dependant upon output voltage as specified per particular
model.
4) These are stress ratings. Exposure of the devices to any of these conditions
may adversely affect long term reliability. Proper operation under conditions
other than the standard operating conditions is neither warranteed or implied.
5) Isolation for up to 1 minute duration.
6) No termination necessary with control pin to maintain constant “ON” operation
(if applicable to this model)
7) Max load (peak) specified for 10mS max, 20% duty cycle, minimum load on
all outputs
GENERAL SPECIFICATIONS
Input-Output Isolation
Output-Ground Isolation
Input-Ground Isolation
Efficiency (@ Full Load)
Safety
EMC
3000VAC
5
500VAC
1500VAC
78%, typ
(or See Chart/Curve)
UL60950/EN60950 Approved
EN55022/B, EN61000-3-2,3/A
EN61000--4-2,3,4,5,6,8,11/Cr A
All specifications are typical at nominal input, full load, and 25DegC unless
otherwise noted
A
Blue Number
means see respective Specification
Astrodyne products are not authorized or warranteed for use
as critical components in life support systems, equipment used
in hazardous environments, nuclear controls systems, or other
mission-critical applications.
WWW.ASTRODYNE.COM
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
7 0 Wat t O pen F ra me Switch in g Power S uppl y with P FC
MECHANICAL DIMENSIONS
OPEN FRAME
3
P3
2
6
1
1
5
REL70
2 – Good
3 – Good
series
RECOMMENDED AIR FLOW DIRECTION
1 – Optimum
P3
1
2
3
4
5
6
(+)
(+)
(-)
(-)
(-)
(+)
OUTPUT 1
SENSE
OUTPUT 1
SENSE
P.F. RTN
P.F. SIG
P2
1
2
3
4
5
6
7
8
4 - Fair
2
P2
L
P1
N
T1
4
V1 ADJUST
AC
INPUT
GND
(-)
(-)
(-)
(-)
(+)
(+)
(+)
(+)
O
O
O
O
O
O
O
O
THERMAL PERFORMANCE
70
60
50
½O½CE½
½O½CE½ AI½ COOLING
CONVECTION COOLING
SINGLE OUTPUT MODEL
1
.128 DIA
MTG HOLE
(4 PLACES)
40
30
4.50 (114.3)
.15 (3.8) TYP
4.20 (106.7)
20
10
P2
1
2
3
4
5
6
7
8
(-)
(+)
(-)
(+)
(-)
(+)
(-)
(+)
OUTPUT 4
OUTPUT 4
OUTPUT 3
OUTPUT 3
OUTPUT 2
OUTPUT 2
OUTPUT 1
OUTPUT 1
CONVECTION COOLING
WITH CHASIS ½COVE½
COVE½
0
0
10
20
30
40
50
60
70
1
2.20 (55.9)
P2
L
P1
N
T1
2.50 (63.5)
AC
INPUT
GND
V1 ADJUST
P3
1
CONNECTOR SPECIFICATIONS
P1 AC Input
.156 friction lock header mates with Molex 09-50-3031 crimp terminal
housing with Molex 2478 crimp terminal
P2 DC Output (Single)
P3
1
2
(-)
(+)
P.F. RTN
P.F. SIG
MULTIPLE OUTPUT MODEL
3.20 (81.3)65 (16.5)
.
1.22 (30.9)
MAX
.80 (20.3)
1.00 (25.4)
.156 friction lock header mates with Molex 09-50-3181 crimp terminal
housing with Molex 2478 crimp terminal
P2 DC Output (Multiple)
.156 friction lock header mates with Molex 09-50-3181 crimp terminal
housing with Molex 2478 crimp terminal
G
Ground
.187 quick disconnect terminal
P3 P.F Sense (Single)
.100 breakaway header mates with Molex 22-55-2061 crimp terminal
housing with Molex 71851crimp terminal
P3 Power Fail (Multiple)
CHASSIS & COVER
4.20 (106.7)
.68 (17.2)
4-40
MTG HOLE
(2 PLACES)
1.48 (37.6)
4.79 (121.6)
3
4.20 (106.7)
.100 breakaway header mates with Molex 50-57-9002 crimp terminal
housing with Molex 71851 crimp terminal
2.20 (55.9)
2
2.62 (66.5)
4
4-40
MTG HOLE
(4 PLACES-BASE)
1
ALL DIMENSIONS IN INCHES (MM)
WWW.ASTRODYNE.COM
300 Myles Standish Blvd., Taunton, MA 02780
Ph: 1-800-823-8082
Fax: 508-823-8181
