F-219
SSM–120–S–DV
EXTENDED LIFE
PRODUCT
HIGH MATING
CYCLES
10 YEAR MFG
WITH 30 µ" GOLD
SSM–116–S–SV
(2.54 mm) .100"
SSM–115–L–SH
SSM SERIES
TIGER CLAW SURFACE MOUNT SOCKET
™
Mates with:
TSW, MTSW, TST,
TSS, ZST, ZSS, DW,
EW, ZW, TSM, HMTSW,
HTSW, TSSH, BST,
HTSS, TLW, MTLW
SSM
1
NO. PINS
PER ROW
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?SSM
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (SSM/TSW):
5.2 A per pin
(2 pins powered)
Voltage Rating:
405 VAC / 572 VDC
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
Insertion Depth:
SV/DV is (4.34 mm) .171" to
(7.24 mm) .285" or pass-through
from top; (5.56 mm) .219" plus
board thickness minimum from
bottom; SH/DH is (4.34 mm)
.171" to (6.35 mm) .250"
Normal Force:
125 grams (1.21 N) average
RoHS Compliant:
Yes
02 thru 36
(–SV, – SH, –DH)
02 thru 40
(–DV)
= Gold flash
on contact,
Matte Tin on tail
–F
–L
= Bottom Entry
(–DV & –SV only)
–BE
–LC
–K
= Metal Pick &
Place Pad
(5 positions min.)
–DV only
(5.94) .234
x
(5.72) .225
–M
= Locking Clip
(–DV & –SV only)
Contact Samtec for
–DH & –SH
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
= 30 µ" (0.76 µm)
Gold on contact,
Matte Tin on tail
–S
= (6.50 mm) .256" DIA
Polyimide film
Pick & Place Pad
(2 positions min.)
–DV & –SV only
ALSO AVAILABLE
(MOQ Required)
• Alignment pin
= Polarized Position
(–BE not available)
–“XXX”
–TR
= Plastic Pick
& Place Pad
(–DV & –SV only)
(6 pos. minimum.
Contact Samtec
for availability on
smaller positions)
(4.95)
.195
x
(10.03)
.395
–P
APPLICATIONS
TSM
SSM TSSH
= Tape & Reel Packaging
(29 positions max.)
(1.27)
.050
PROCESSING
Lead–Free Solderable:
Yes
–DH Coplanarity:
Less than 28 positions
(0.15 mm) .006" max*
More than 27 positions
(0.20 mm) .008" max*
–SH, –SV, –DV Coplanarity:
(0.15 mm) .006" max*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
= Single Row Vertical Pin
(2.54) .100 x No. of Positions
(2.54)
.100
01
72
36
(5.08)
.200
71
–SV
HORIZONTAL
= Double Row Vertical Pin
(2.54) .100 x No. of Positions
02
–DV
(4.42)
.174
(2.54)
.100
01
(7.04)
.277
(7.37)
.290
(7.37)
.290
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(2.54) .100
(0.51) .020
(0.13) .005
(2.54) .100
(0.51) .020
(1.27) .050
(1.42) .056
= Single Row Horizontal Pin
(1.78)
.070
(3.18)
.125
(0.25)
.010
(8.13)
.320
(2.54) .100 x No. of Positions
(0.89) .035 SQ TYP
72
(5.72) (2.54)
.225 .100
(1.78)
.070
(8.13)
.320
71
–SH
= Double Row Horizontal Pin
(2.54) .100 x No. of Positions
02
–DH
FILE NO. E111594
01
36
(11.00)
.433
01
(11.18)
.440
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(0.51) .020
(2.54).100
(0.51) .020
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
