SILICON RECTIFIER

VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 3.0 Amperes

MECHANICAL DATA

Case: Molded plastic

Epoxy: UL 94V-0 rate flame retardant

Lead: MIL-STD-202E, Method 208 guaranteed

Polarity: Color band denotes cathode end

Mounting position: Any

Weight: 1.18 grams

FEATURES

Low cost

Low leakage

Low forward voltage drop

High current capability

DO-27

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

C ambient temperature unless otherwise specified.Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

PARAMETER

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current .375*(9.5mm)

lead length at TL = 105℃

Peak Forward Surge Current 8.3 ms single half sine-wave

Superimposed on rated load (JEDEC Method)

Maximum Instantaneous Forward Voltage at 3.0A DC

Maximum DC Reverse Current at Rated DC @T

= 25℃

Blocking Voltage

Maximum

Full

Load

Reverse

Current

= 100℃

Average,

Full

SYMBOL

RRM

RMS

FSM

1N5400 1N5401 1N5402 1N5404 1N5406 1N5407 1N5408 UNITS

100

200

140

200

400

280

400

3.0

200

1.1

5.0

600

420

600

800

560

800

1000

700

1000

Volts

Amps

Volts

uAmps

℃/W

℃

500

Cycle .375*(9.5mm) lead length at TL = 75℃

Typical Junction Capacitance ( Note )

Typical Thermal Resistance

Operating and Storage Temperature Range

NOTES : Measured at 1 MH

and applied reverse voltage of 4.0 volts

RΘJA

STG

-65 to +175

Wing Shing Computer Components Co., (H.K.)Ltd.

Homepage:

http://www.wingshing.com

Tel:(852)2341 9276 Fax:(852)2797 8153

E-mail: wsccltd@hkstar.com
