F-219
AW–60–03–G–D–180–075
AW–10–03–G–D–130–175
AW–40–03–G–D–217–075
(0.80 mm) .0315"
AW SERIES
SMT MICRO BOARD STACKER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?AW
Insulator Material:
Top: Black LCP
Bottom: Natural LCP
Terminal Material:
Phosphor Bronze
Plating:
Au over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
Mates with:
CLE
Choice of post heights
and board space
Ideal for
high-density
skyscrapers
OPTIONS
–EP OPTION
–P OPTION
PROCESSING
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max (05-40)
(0.15 mm) .006" max (41-90)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
–ES OPTION
Surface
Mount
Optional
End Shrouds
for blind
mating
(0.80 mm) .0315"
micro pitch
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
AW
NO. PINS
PER ROW
03
PLATING
OPTION
D
STACKER
HEIGHT
POST
HEIGHT
OPTION
–“XXX”
05 thru 90
= 10 µ" (0.25 µm) Gold
–G
No. of positions
x (0.80) .0315
02
= Stacker
Height
(in inches)
(3.09 mm)
.122" to
(5.84 mm)
.230"
= Post Height
(in inches)
(1.91 mm)
.075"
minimum
Example:
–075
= (1.91 mm)
.075"
–“XXX”
= End Shroud
11 pins/row min.
(–075 Post
Height only)
–ES
(0.80) .0315
(3.18)
.125
(5.08)
.200
X
(3.18)
.125
Example:
–175
= (4.45 mm)
.175"
(3.05)
.120
01
= End Shroud
with Guide Post
(–075 Post
Height only)
11 pins/row min.
–EP
(1.20)
.047
(1.91)
.075
DIA
–P OPTION
(0.30) .012 SQ
(3.81)
.150
(4.17)
.164
(3.56)
.140
POST
HEIGHT (3.56)
.140
= Alignment Pin
(4 positions min.)
(Available for
board stacks
between
(4.06 mm) .160"
to (5.84 mm) .230")
(Metal or plastic
at Samtec
discretion.)
–A
Notes:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
Some lengths, styles and
options are non-standard,
non-returnable.
STACKER
HEIGHT
(3.09)
.122
to
(5.84)
.230
(7.75)
.305
MAX
OVERALL
LENGTH
(1.40)
.055
(4.57)
.180
(1.91)
.075
MIN
= Pick & Place Pad
(8 positions min.)
–P
(1.70)
.067
–EP OPTION
= Tape & Reel
(84 positions max.)
–ES OPTION
–TR
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
