F-219
TSSH–115–01–L–D
TSSH–120–01–L–DH
(2.54 mm) .100"
TSSH SERIES
SHROUDED .025" SQ POST HEADERS
Board Mates:
SSW, SSQ, SSM
Important Note:
This Series will only mate
with SSW, SSQ & SSM Series
TSSH
1
NO. PINS
PER ROW
01
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?TSSH
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
05, 10, 15, 20,
25, 30, 34
(–D–RA, –DH)
05, 10, 15, 20,
25, 30, 35, 36
(–D, –DV)
= 10 µ" (0.25 µm) Gold on post,
Matte Tin on tail
–L
= Matte Tin
–T
= Alignment Pin (N/A
with -LC)
–A
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity (–DV):
(0.10 mm) .004" max (05-10)
(0.15 mm) .006" max (15-20)*
(0.20 mm) .008" max (25-36)*
SMT Lead Coplanarity (–DH):
(0.15 mm) .006" max*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
= Double Row Right-angle Pin
Through-hole
02
–D–RA
= Double Row Horizontal Pin
Surface Mount
(1.58)
.062
–DH
(3.17)
.125
(No. of positions + 2) x (2.54) .100
(2.54) .100
(2.54)
.100
01
(2.29)
.090
(No. of positions x
(2.54) .100) + (1.02) .040
(0.64) .025 SQ
(5.84)
.230
= Locking Clip
(–DV only)
(N/A with -A)
(Manual placement
required)
(9.65)
.380
–LC
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(1.52)
.060
APPLICATIONS
SSM TSSH
–D–RA
(2.54)
.100
(2.54)
.100
(3.94)
.155
(1.27)
.050
(7.62)
.300
–DH
(1.42)
.056
x
(0.25)
.010
(3.43)
.135
= Double Row Vertical Pin
Through-hole
HORIZONTAL
No. of positions x
(2.54) .100 + (5.08) .200
(2.54) .100
72
02
–D
= Double Row Vertical Pin
Surface Mount
–DV
= Plastic Pick
& Place Pad
(–DH only) 5 pos. min
–P
ALSO AVAILABLE
(MOQ Required)
• Other platings
(8.89)
.350
(6.10)
.240
(2.54) (6.35)
.100 .250
01
No. of positions x
71
(2.54) .100 + (1.27) .050
(0.64) .025 SQ
(6.10)
.240
(2.54)
.100
(8.89)
.350
(8.89)
.350
(6.86)
.270
x
(8.26)
.325
(8.89)
.350
(2.69)
.106
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
–D
(10.03)
.395
(1.91)
.075
–DV
= Tape & Reel
5 to 25 positions
(–DH & –DV only)
–TR
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
