AMPMODU Interconnection System
Mod IV Receptacle Assemblies, Single-Row, Surface Mount, .100 [2.54] x
.100 [2.54] Centerline End To End Stackable without Compliant Pin Holddowns
Surface Mount,Single-Row,
Dual Entry, End to End
Stackable
.020
Standoff Typ.
[0.51]
.265
[6.73]
Material and Finish
Housing
— Glass-filled thermoplastic,
black, 94V-0 rated
Contacts
— Phosphor bronze, plated
as follows:
Plating A
— Duplex .000030
[0.00076] gold on contact area,
.000150-.000300 [0.00381-0.00762]
matte tin on solder area all over .000050
[0.00127] nickel
Plating B
— Duplex .000010
[0.000254] gold on contact area,
.000150-.000300 [0.00381-0.00762]
matte tin on solder area all over .000050
[0.00127] nickel
Plating C
— .000150-.000300
[0.00381-0.00762] matte tin on solder
leads, all over .000050 [0.00127] nickel
A
.100
[2.54] Typ.
.107
[2.72]
Typ.
(Localized Gold
Plate Area)
.208
[5.28] Max.
.140
[3.56]
.148
[3.77]
Point of
Contact
B
.100
[2.54]
Surface Mount Receptacle
Assemblies
.040±.003
Dia. Typ.
[1.02±0.08]
(For bottom entry or pass
through applications)
.228
[5.78]
Related Product Data
Mateable Headers
—
Refer to Mating Post Selection Guide —
page 90
Performance Specifications
—
page 186
No. of
Pos.
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
30
40
Dimensions
A
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
1.900
[48.26]
2.000
[50.80]
3.000
[76.20]
4.000
[101.60]
B
.200
[5.08]
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
1.500
[38.10]
1.600
[40.64]
1.700
[43.18]
1.800
[45.72]
1.900
[48.26]
2.900
[73.66]
3.900
[99.06]
.060
Min.
[1.52]
.090
[2.28]
5
Recommended PC Board Pad Pattern
(.008 [0.20] thick stencil)
Packaged in Tubes
Contact Plating/ Part Nos.
Plating A
Plating B
Plating C
5-147738-2
5-147737-2
5-147736-2
5-147738-3
5-147737-3
5-147736-3
5-147738-4
5-147737-4
5-147736-4
5-147738-5
5-147737-5
5-147736-5
5-147738-6
5-147737-6
5-147736-6
5-147738-7
5-147737-7
5-147736-7
5-147738-8
5-147737-8
5-147736-8
5-147738-9
5-147737-9
5-147736-9
6-147738-0
6-147737-0
6-147736-0
6-147738-1
6-147737-1
6-147736-1
6-147738-2
6-147737-2
6-147736-2
6-147738-3
6-147737-3
6-147736-3
6-147738-4
6-147737-4
6-147736-4
6-147738-5
6-147737-5
6-147736-5
6-147738-6
6-147737-6
6-147736-6
6-147738-7
6-147737-7
6-147736-7
6-147738-8
6-147737-8
6-147736-8
6-147738-9
6-147737-9
6-147736-9
7-147738-9
7-147737-9
7-147736-9
8-147738-9
8-147737-9
8-147736-9
Packaged in Tape & Reel
Contact Plating/ Part Nos.
Plating A
Plating B
Plating C
5-147723-2
5-147728-2
5-147729-2
5-147723-3
5-147728-3
5-147729-3
5-147723-4
5-147728-4
5-147729-4
5-147723-5
5-147728-5
5-147729-5
5-147723-6
5-147728-6
5-147729-6
5-147723-7
5-147728-7
5-147729-7
5-147723-8
5-147728-8
5-147729-8
5-147723-9
5-147728-9
5-147729-9
6-147723-0
6-147728-0
6-147729-0
6-147723-1
6-147728-1
6-147729-1
6-147723-2
6-147728-2
6-147729-2
6-147723-3
6-147728-3
6-147729-3
6-147723-4
6-147728-4
6-147729-4
6-147723-5
6-147728-5
6-147729-5
6-147723-6
6-147728-6
6-147729-6
6-147723-7
6-147728-7
6-147729-7
6-147723-8
6-147728-8
6-147729-8
6-147723-9
6-147728-9
6-147729-9
7-147723-9
7-147728-9
7-147729-9
8-147723-9
8-147728-9
8-147729-9
Notes:
1. Tyco Electronics recommends mating gold or duplex plated headers with duplex plated receptacle assemblies.
2. To obtain the minimum mating post length, add .020 [0.51] (not including the post lead in chamfer) to
the maximum point-of-contact dimension, and .062 [1.57] for recommended board thickness if used in bottom entry application.
Note:
All part numbers are RoHS compliant.
188
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
