PIS 4728
Shielded
A
12.3 max
8.2 max
5.0
(S)
12.3 max
7.6 12.0
(F)
5.4
2.9
Recommended Layout for solder pads
* In order to prevent short circuit,
a solder resist is recommended
7 12.8
Outline
Solder resist
Typical Ls vs Frequency (ƒ)
10000
Inductance (µH)
1000 µ H
Inductance
Part No
L (µH)
PIS4728-1R2N-04
PIS4728-2R4N-04
PIS4728-3R5N-04
PIS4728-4R7N-04
PIS4728-5R6N-04
PIS4728-6R1N-04
PIS4728-7R6N-04
PIS4728-100M-04
PIS4728-120M-04
PIS4728-150M-04
PIS4728-180M-04
PIS4728-220M-04
PIS4728-270M-04
PIS4728-330M-04
PIS4728-390M-04
PIS4728-470M-04
PIS4728-560M-04
PIS4728-680M-04
PIS4728-820M-04
PIS4728-101M-04
PIS4728-121M-04
PIS4728-151M-04
PIS4728-181M-04
PIS4728-221M-04
PIS4728-271M-04
PIS4728-331M-04
PIS4728-391M-04
PIS4728-471M-04
PIS4728-561M-04
PIS4728-681M-04
PIS4728-821M-04
PIS4728-102M-04
PIS4728-152M-04
1.2
2.4
3.5
4.7
5.6
6.1
7.6
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1500
f
L
Tol
(kHz) ± (%)
100
100
100
100
100
100
100
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
30
30
30
30
30
30
30
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
DCR
max
(mΩ)
7.0
11.5
13.5
15.8
15.8
17.6
20.0
21.6
24.3
27.0
39.2
43.2
45.9
64.8
72.9
100
110
140
160
220
250
280
350
390
560
640
700
980
1070
1480
1640
1820
2300
Rated DC
Current
I (A)
9.8
8.0
7.5
6.8
6.7
6.6
5.9
5.4
4.9
4.5
3.9
3.6
3.4
3.0
2.75
2.50
2.35
2.10
1.95
1.70
1.60
1.42
1.30
1.16
1.06
0.95
0.88
0.79
0.73
0.67
0.60
0.55
0.45
1000
100 µ H
SMD Power Inductors
100
6.1 µ H
10
1
0.01
0.1
1
10
Frequency (MHz)
100
Typical Ls vs Current (I)
10000
Inductance (µH)
1000
1000
µH
100
100
µH
10
6.1
µH
1
1
10
100
1000
Current (mA)
10000
Revision date : 02 Nov 2017
Core Material :
Ferrite, magnetically shielded.
SPQ :
Taped / Reel 500 [-04]
Remarks :
- Additional gluing to PCB board is recommended.
-
I
- see description in Inductors Technical Data.
•
All dimensions in mm
