F-219
LS2–120–01–L–D–RA1
LS2–110–02–L–D
LS2–110–01–L–D
(2.00 mm) .0787"
LS2 SERIES
SELF MATING HERMAPHRODITIC STRIP
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?LS2
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
3.2 A per pin
(6 adjacent pins powered)
Voltage Rating:
475 VAC mated with LS2
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
Mates with:
LS2
Shrouded Terminals
Polarized
Align &
Latch™
APPLICATION
Through-Hole
(-01)
=(9.65 mm)
.380"
Surface Mount
(-02)
=(13.71 mm)
.540"
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.15 mm) .006" max*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
–RA1
–RA2
(2.00 mm)
.0787"
pitch
LS2
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
D
TAIL
OPTION
–01 only
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
05, 10, 15,
20, 25, 30
=Through-
hole
– 01
– 02
= Surface
Mount
= Gold flash on contact,
Matte Tin on tail
–F
–L
– RA1
= Right-
angle
(Shroud
Down)
= (6.30 mm)
.248" DIA
Polyimide
Film Pick &
Place Pad
(–02 only)
–K
ALSO AVAILABLE
(MOQ Required)
• Alignment pin
• Other platings
• Other stack heights
No. of positions x
(2.00) .0787 + (1.57) .062
(5.27)
.208
(2.00)
.0787
= 10 µ" (0.25 µm) Gold
on contact, Matte Tin on tail
– RA2
= Right-
angle
(Shroud
Up)
= Tape
& Reel
Packaging
–TR
(2.29)
.090
(3.07)
.121
–RA1
(8.38)
.330
(6.83)
.269
(2.00)
.0787
(6.35)
.250
(1.78)
.070
(2.00)
.0787
Style –02
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(0.50)
.020
SQ
Style –01
(2.29)
.090
–RA2
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
