F-219
SMM–135–02–L–D–K
SMM–108–02–L–S
SMM–115–02–S–D
SMM–110–02–L–S
(2.00 mm) .0787"
SMM SERIES
TIGER EYE SOCKET STRIP
™
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?SMM
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
BeCu
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Current Rating (TMM/SMM):
3.2 A per pin
(2 pins powered)
Voltage Rating:
350 VAC
Operating Temp Range:
-55 °C to +125 °C
Insertion Depth:
(3.05 mm) .120" to
(3.25 mm) .128"
Max Cycles:
100 with 10 µ" (0.25 µm) Au
RoHS Compliant:
Yes
Board Mates:
TMM, TMMH, MTMM, MMT,
LTMM, TW, PTT, ZLTMM
Cable Mates:
TCMD
Available with optional
Pick & Place Pads
High-reliability
Tiger Eye™ contacts
(Four point redundancy)
EXTENDED LIFE
PRODUCT
HIGH MATING
CYCLES
10 YEAR MFG
WITH 30 µ" GOLD
(3.56 mm)
.140"
(2.00 mm)
.0787" pitch
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
SMM
1
NO. PINS
PER ROW
02
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
02 thru 40
= Gold flash
on contact,
Matte Tin on tail
= 10 µ" (0.25 µm)
Gold on contact,
Matte Tin on tail
40
(2.00)
.0787
–F
–L
= Single
Row
–S
= Polarized
Position
–“XX”
–K
FILE NO. E111594
= Double
Row
–D
ALSO AVAILABLE
(MOQ Required)
• Locking clip
(Manual placement required)
• Other platings
No. of positions x (2.00) .0787
= 30 µ" (0.76 µm)
Gold on contact,
Matte Tin on tail
–S
(3.81) .150
x (7.62) .300
(5.71) .225
x (10.01) .394
–S Row
01
(2.00)
.0787
02
–D Row
= (5.50 mm)
.217" DIA
Polyimide
Film
Pick &
Place Pad
(2 positions
minimum,
–02 thru –05
requires –TR)
POLARIZING KEY
Specify PK–01–07 for polarizing
key (Available in wheels of six
each). Also polarizes TCSD Series
IDC Cable.
80
(2.00) (4.00)
.0787 .158
= Plastic Pick
& Place Pad
(–02 thru –05
requires –TR)
–P
79
01
–P
= Tape & Reel
Packaging
(27 positions
maximum)
–TR
(0.38)
.015
(3.56)
.140
(0.51)
.020
(4.32)
.170
(6.30)
.248
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
