F-219
LPHT–08–24–L–RT1–GP
(12.00 mm) .472"
(PWR)
(1.27 mm) .050"
(SIG)
LPHT–04–24–L–RT1–GP
LPHT SERIES
EXTreme LPHPower TERMINAL
™
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?LPHT
Insulator Material:
Black LCP
Terminal Material:
Signal: Brass
Power: Copper Alloy
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating:
Power: 30 A per power blade
(4 blades powered)
Signal: 1 A per signal contact
Operating Temp Range:
-40 °C to +105 °C
Voltage Rating:
250 VAC
Standard Creepage:
(1.21 mm) .048" (power)
Standard Clearance:
(1.36 mm) .054" (power)
RoHS Compliant:
Yes
Mates with:
LPHS
Choice of power
positions
CREEPAGE
AND CLEARANCE
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
Double-stacked power
blades to increase density
Up to a total of
32 signal positions
available
Guide
post holes
Alignment
pin
PROCESSING
Lead-Free Solderable:
Yes
LPHT
POWER
POSITIONS
SIGNAL
POSITIONS
PLATING
TAIL
GP
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(Total, 2 per power bank)
–02, –04,
–06, –08, –10
–16, –20,
–24, –32
(Total)
ALSO AVAILABLE
(MOQ Required)
• Other platings
• 28 Signal positions
• No Guide post
= 10 µ"
(0.25 µm)
Gold on
contact,
Matte Tin
on tail
–L
= Right-angle Through-hole
(Use with (1.60 mm) .062" thick board)
–RT1
–RT2
(12.00)
.472
(7.49)
.295
= Right-angle Through-hole
(Use with (2.36 mm) .093" thick board)
SIGNAL
POSITIONS
POWER POSITIONS
(–02)
A
(–04)
A
(–06)
A
(–08)
A
(–10)
A
(2.50)
.098
(0.64)
.025
(0.45)
.018
(1.27)
.050
–16
–20
–24
–32
(33.97)
1.337
(36.51)
1.437
(39.05)
1.537
(44.13)
1.737
(45.97) (57.97) (69.97) (81.97)
1.810 2.282 2.755 3.227
(48.51) (60.51) (72.51) (84.51)
1.910 2.382 2.855 3.327
(51.05) (63.05) (75.05) (87.05)
2.010 2.482 2.955 3.427
(65.13) (68.13) (80.13) (92.13)
2.210 2.682 3.155 3.627
Notes:
Series is rated
up to 60 A per power bank.
Some lengths, styles and
options are non-standard,
non-returnable.
The Molex EXTreme
LPHPower
™
line is a
second source to the
Samtec LPHT Series
* EXTreme LPHPower
is a trademark of Molex
Incorporated.
™
A
(13.93)
.548
(3.07)
.121 (16.28)
DIA .641
(3.30)
.130
DIA
(3.07) .121 DIA
(3.30) .130 DIA
LPHT–04–24–L–RTX–GP
Due to technical progress, all designs, specifications and components are subject to change without notice.
(3.25)
.128
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
