F-219
FTS–110–02–F–DV
FTS–111–02–L–DV–SA
FTS–122–01–F–DV
FTS–116–02–L–D
(1.27 mm) .050"
FTS SERIES
MICRO LOW-PROFILE TERMINAL STRIPS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?FTS
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Operating Temp Range:
-55 °C to +125 °C
Plating:
Sn or Au over 50 µ" (1.27 µm) Ni
Current Rating:
3.4 A per pin
(2 pins powered)
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
.004" (0.10 mm) max
Board Mates:
CLP, FLE
Cable Mates:
FFSD
Mates with
socket strips
or IDC cable
Low-profile
(1.27 mm) .050"
OPTIONS
–S OPTION
–SA OPTION
Surface
mount or
through-hole
Shrouded and
alignment pin
options available
Micro pitch
.050" x .050"
(1.27 mm x 1.27 mm)
–P OPTION
–TR OPTION
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
Impedance matched for
high-speed applications
FTS
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
(–D & –DV only)
ALSO AVAILABLE
(MOQ Required)
• Alignment pin
(except –S & –SA
option = 05 thru 46)
(5.84)
.230
02
02 thru 50
= .120"
(3.05 mm)
Post
(Mates with
FFSD)
–01
= Gold flash
on post,
Matte Tin
on tail
–F
= Double
Through-hole
–D
No. of positions x .050 (1.27)
50
(1.27)
.050
01
49
(3.42)
.135
(1.27) .050
= .075"
(1.91 mm)
Post
(Mates with
FLE)
–02
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin
on tail
–L
= Double
Vertical SMT
–DV
–S
= End Shroud with
Alignment Pin
(05 thru 46
positions. Style
-02 & -03 only)
= End Shroud
(05 thru 46
positions. Style
-02 & -03 only)
= Pick &
Place Pad
(04 positions
minimum)
(4.06)
.160
–SA
= Single
Through-hole
–S
(4.57)
.180
50
01
(2.16)
.085
= .065"
(1.65 mm)
Post
(Mates with
CLP)
–03
(3.56)
.140
(1.40)
.055
(1.27)
.050
DIA
= Single
Vertical SMT
–SV
–P
–SA OPTION
(1.59)
.0625
No of positions x .050 (1.27)
+ .325 (8.25) = –SA
No of positions x .050 (1.27)
+ .200 (5.08) = – S
02
46
= .150"
(3.81 mm)
Post
(3.48)
.137
–04
(4.70)
.185
01
45
LEAD
STYLE
– 01
– 02
– 03
– 04
A
(3.05) .120
(1.91) .075
(1.65) .065
(3.81) .150
(1.27)
.050
(3.30)
.130
X
(5.08)
.200
–P OPTION
= Tape & Reel
(-DV only)
(Required callout
for positions
2 thru 4)
–TR
(0.86)
.034
(0.41)
.016
SQ
(2.29)
.090
A
A
(3.56)
.140
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–SV
–D
–DV
–S OPTION
(Shrouded options removed for clarity)
–S
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
