F-219 SUPPLEMENT
YTT–110–01–G–Q
YTT–120–04–L–5
YTT–116–04–T–6
(2.00 mm) .0787"
YTT SERIES
HIGH-DENSITY TERMINAL STRIP
SPECIFICATIONS
For complete specifications
see www.samtec.com?YTT
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
RoHS Compliant:
Yes
Lead–Free Solderable:
Wave only
Mates with:
YTQ, YTS, YTE
Choice of 4, 5 and 6
rows on (2.00 mm)
.0787" pitch
OTHER
SOLUTIONS
(2.00 mm)
.0787"
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(2.00 mm)
.0787"
Through-hole
YTT
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OTHER
OPTIONS
02 thru 50
LEAD
STYLE
–01
–04
06
= 20 µ" (0.51 µm)
Gold on
contact area,
Gold flash on tail
–G
= Four Row
–Q
–5
–6
–“XXX”
= Polarized
Position
Specify
position of
omitted pin
= Five Row
Other Solutions
Right-angle
Four Row
See TMM Series.
A
B
C
(7.67) (3.20) (2.46)
.302
.126 .097
(6.48) (1.91) (2.57)
.255
.075 .101
300
= 30 µ" (0.76 µm)
Gold on
contact area,
Tin on tail
–S
= Six Row
(2.00) .0787
B
A
C
Low Profile
Four Row
See TMM Series.
= 10 µ" (0.25 µm)
Gold on
contact area,
Tin on tail
No. of
rows
x
(2.00)
.0787
–L
2 mm Shunt
See 2SN Series.
(2.00)
.0787
TYP
= Gold flash
on contact area,
Tin on tail
–F
–T
–Q
(2.00) .0787
B
A
C
Elevated
01
295
See YTW Series.
(2.00)
.0787
No. of positions x (2.00) .0787
= Tin
–5
(2.00) .0787
B
A
Shrouded
Four Row
Vertical &
Right-angle
See TMMS Series.
(0.50) .020
SQ
(2.00) .0787
C
–6
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
