R1WV6416R Series
64Mb Advanced LPSRAM (4M word x 16bit / 8M word x 8bit)
REJ03C0368-0100
Rev.1.00
2009.05.07
Description
The R1WV6416R Series is a family of low voltage 64-Mbit static RAMs organized as 4,194,304-word by
16-bit, fabricated by Renesas’s high-performance 0.15um CMOS and TFT technologies.
The R1WV6416R Series is suitable for memory applications where a simple interfacing, battery operating
and battery backup are the important design objectives.
The R1WV6416R Series is provided in 48-pin thin small outline package [TSOP (I): 12mm x 20mm with
pin pitch of 0.5mm], 52-pin micro thin small outline package [
µ
TSOP (II): 10.79mm x 10.49mm with pin pitch
of 0.4mm] and 48-ball fine pitch ball grid array [f-BGA] package. It gives the best solution for compaction of
mounting area as well as flexibility of wiring pattern of printed circuit boards.
Features
•
•
•
•
•
•
•
•
Single 2.7~3.6V power supply
Small stand-by current: 8 µA (3.0V, typical)
No clocks, No refresh
All inputs and outputs are TTL compatible.
Easy memory expansion by CS1#, CS2, LB# and UB#
Common Data I/O
Three-state outputs: OR-tie Capability
OE# prevents data contention on the I/O bus
Ordering Information
Type No.
R1WV6416RSA-5S%
R1WV6416RSA-7S%
R1WV6416RSD-5S%
R1WV6416RSD-7S%
R1WV6416RBG-5S%
R1WV6416RBG-7S%
Access time
55 ns
70 ns
55 ns
70 ns
55 ns
70 ns
Package
12mm x 20mm 48-pin plastic TSOP (I)
(normal-bend type) (48P3R)
350 mil 52-pin plastic
μ-TSOP
(II)
(normal-bend type) (52PTG)
f-BGA 0.75mm pitch 48-ball
%
R
I
% - Temperature version; see table below
Temperature Range
0 ~ +70 °C
-40 ~ +85 °C
REJ03C0368-0100, Rev.1.00, 2009.05.07
Page 1 of 16
R1WV6416R Series
Pin Description
Pin name
Vcc
Vss
A0 to A21
A-1 to A21
DQ0 to DQ15
CS1#
CS2
WE#
OE#
LB#
UB#
BYTE#
NC
Power supply
Ground
Address input (word mode)
Address input (byte mode)
Data input/output
Chip select 1
Chip select 2
Write enable
Output enable
Lower byte enable
Upper byte enable
Byte control mode enable
Non connection
Function
Note: BYTE# pin is supported for 48-pin TSOP (I) and 52-pin µTSOP (II) packages.
REJ03C0368-0100, Rev.1.00, 2009.05.07
Page 3 of 16
R1WV6416R Series
Operation Table
CS1#
H
X
X
L
L
L
L
L
L
L
L
L
L
L
L
CS2
X
L
X
H
H
H
H
H
H
H
H
H
H
H
H
BYTE#
X
X
H
H
H
H
H
H
H
H
H
H
L
L
L
LB#
X
X
H
L
L
L
H
H
H
L
L
L
L
L
L
UB#
X
X
H
H
H
H
L
L
L
L
L
L
L
L
L
WE#
X
X
X
L
H
H
L
H
H
L
H
H
L
H
H
OE#
X
X
X
X
L
H
X
L
H
X
L
H
X
L
H
DQ0~7
High-Z
High-Z
High-Z
Din
Dout
High-Z
High-Z
High-Z
High-Z
Din
Dout
High-Z
Din
Dout
High-Z
DQ8~14
High-Z
High-Z
High-Z
High-Z
High-Z
High-Z
Din
Dout
High-Z
Din
Dout
High-Z
High-Z
High-Z
High-Z
DQ15
High-Z
High-Z
High-Z
High-Z
High-Z
High-Z
Din
Dout
High-Z
Din
Dout
High-Z
A-1
A-1
A-1
Operation
Stand-by
Stand-by
Stand-by
Write in lower byte
Read in lower byte
Output disable
Write in upper byte
Read in upper byte
Output disable
Word write
Word read
Output disable
Byte write
Byte read
Output disable
Note1. H: V
IH
L:V
IL
X: V
IH
or V
IL
2. BYTE# pin is supported for 48-pin TSOP (I) and 52-pin µTSOP (II) packages.
3. When apply BYTE# =“L”, please assign LB#=UB#=“L”.
Absolute Maximum Ratings
Parameter
Power supply voltage relative to Vss
Terminal voltage on any pin relative to Vss
Power dissipation
Operation temperature
Storage temperature range
Storage temperature range under bias
Symbol
Vcc
V
T
P
T
Topr
*3
Tstg
Tbias
*3
R ver.
I ver.
R ver.
I ver.
Value
-0.5 to +4.6
-0.5
*1
to Vcc+0.3
*2
0.7
0 to +70
-40 to +85
-65 to 150
0 to +70
-40 to +85
unit
V
V
W
°C
°C
°C
°C
°C
Note 1. –2.0V in case of AC (Pulse width
≤30ns)
2. Maximum voltage is +4.6V.
3. Ambient temperature range depends on R/I-version. Please see table on page 1.
REJ03C0368-0100, Rev.1.00, 2009.05.07
Page 5 of 16
