For installation & set up please visit
https:/
/ttn.fyi/activate
GETTING STARTED
WITH THE THINGS
GATEWAY
EN
LoRaWAN
915 MHz
802.11.b/g/n
Wireless LAN
Bluetooth 4.2
Frequency
Range
902 to
928 MHz
2.412 to
2.472 GHz
2.402 to
2.480 GHz
Maximum TX
Range
27 dBm
For full installation, activation & setup please
visit https:/
/ttn.fyi/activate.
1. Mount the antenna onto the SMA connector on the Things
Gateway .
2. (Optionally) Mount the ethernet cable.
3. Plug in the 12V 2A power adapter into the Things
Gateway.
4. Continue with the steps as described in the illustrated
quick start guide for the Things Gateway found on
https:/
/ttn.fyi/activate.
20.7 dBm
3 dBm
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician
for help.
INSTRUCTIONS FOR SAFE USE
The Things Gateway shall only be connected to an external
power supply rated at 12V 2A. Any external power supply
used with the Things Gateway shall comply with relevant
regulations and standards applicable in the country of
intended use.
Use a 915 MHz / 868 MHz tuned, 50 Ohm impedance
antenna for use with the SMA connector.
The Things Gateway should be operated in a well ventilated
environment. Do not expose the Things Gateway to heat
from any source; The Things Gateway is designed for reliable
operation at normal ambient room temperatures (50-86°F).
The Things Gateway should be used in a vertical position, on
a stable, non-conductive surface and should not be
contacted by conductive items.
When the Things Gateway is being used always connect the
right antenna to the SMA connector.
The Things Gateway has multiple modules onboard with the
following frequency and output power;
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance
20cm between the radiator and your body. This transmitter
must not be co-located or operating in conjunction with any
other antenna or transmitter.
The Things Gateway operates on the 915 MHz ISM band
using the LoRaWAN protocol. Use a 915 MHz tuned, 50
Ohm impedance antenna. Bluetooth Low Energy & Wifi
operate on the 2.4 GHz ISM band.
The Things Gateway is powered by a 12V 2A power adapter.
Manufactured by Premier Farnell and other companies that
are members of the Premier Farnell group in PRC
The Things Products
Herengracht 182
1016BR Amsterdam
The Netherlands
FCC ID: 2AJX4-GATEWAY
Contains FCC ID: W7O24WN0
Contains FCC ID: A8TBM71S2
THE THINGS GATEWAY
Model: TTN-001-915-1.0
