The MS Series of thermoelectric modules (TEMs) are designed to reach cool down
temperatures that are not achievable with single stage TEMs.
This product line is available in numerous heat pumping capacities, geometric shapes
and temperature differentials. Assembled with Bismuth Telluride semiconductor material
and thermally conductive Aluminum Oxide ceramics, the MS Series is designed for higher
current and lower heat-pumping applications.
FeatureS
•
•
•
•
•
•
High temperature differential
Precise temperature control
Reliable solid state operation
Environmentally friendly
DC operation
RoHS compliant
applicationS
•
•
•
•
•
•
•
CCD cameras
Electron microscope
Calibration equipment
Photonics laser systems
Gas analyzers
infrared (IR) Sensors
Guidance Systems
perforMance SpecificaTionS
hot Side Temperature (°c)
Qmax (Watts)
delta Tmax (°c)
imax (amps)
Vmax (Volts)
25
7.5
100
3.9
8.1
Suffix ThickneSS
(prior To Tinning)
00
11
22
0.417”± 0.008”
0.409”± 0.008”
0.417”± 0.008”
flaTneSS &
paralleliSM
0.001” / 0.004”
0.001” / 0.002”
0.001” / 0.004”
hoT
face
Metallized
Lapped
Pre-tinned
cold
face
Metallized
Lapped
Pre-tinned
lead
lengTh
7.87”
7.87”
7.87”
Sealing option
Suffix
rT
ep
SealanT color
RTV
Epoxy
White
Black
TeMp range
-60 to 204 °C
-55 to 150 °C
deScripTion
Non-corrosive, silicone adhesive sealant
Low density syntactic foam epoxy encapsulant
global
solutions:
local
support
Americas: +1 888.246.9050
Europe: +46.31.420530
Asia: +86.755.2714.1166
clv.customerpos@lairdtech.com
www.lairdtech.com
TM
Multistage Series MS3,119,14,15
Innovative
Technology
for a
Connected
World
Thermoelectric Modules
Performance Curves at Th = 25°C
therMo
2.5
3.0
3.5
3.9
1.5
2.5
2.0
electric
9.0
8.0
6.0
5.0
Qc (W)
4.0
3.0
2.0
1.0
0.0
120
100
80
60
40
20
0
1.0
0.5
0.0
120
100
80
60
Delta T (°C)
Delta T (°C)
+INPUT
(RED)
1.18
[30.0]
0.59
[15.0]
22 AWG PVC
-INPUT
(BLACK)
0.59
[15.0]
1.18
[30.0]
COLD FACE
THICKNESS
SEE TABLE
HOT FACE
96% Alumina Ceramics
operating tipS
• Max Operating Temperature: 80°C
• Do not exceed Imax or Vmax when
operating module
• Reference assembly guidelines for
recommended installation
• Solder tinning also available on
metallized ceramics
THR-DS-MS3,119,14,15 0609
