19-1015; Rev 1; 2/08
MAX13042E Evaluation Kit
General Description
The MAX13042E evaluation kit (EV kit) demonstrates
the MAX13042E 4-channel, bidirectional logic-level
translator, featured in a tiny 12-bump UCSP™ package.
The MAX13042E translates between V
L
and V
CC
logic
levels and guarantees data rates up to 100Mbps.
As configured, the EV kit dedicates two channels for
translation between V
L
to V
CC
and two channels for
translation between V
CC
to V
L
. The EV kit gives the
option of using SMA connectors or test points at the
input signal lines, while providing scope probe jacks for
monitoring the outputs. The V
L
range is 1.62V to 3.2V
and the ±15kV ESD-protected V
CC
range is 2.2V to 3.6V.
Features
♦
Supply Voltage Ranges
1.62V to 3.2V (V
L
)
2.2V to 3.6V (V
CC
)
♦
±15kV ESD Protection on I/O V
CC
Lines
♦
Two Dedicated Channels to Allow Translation
from V
L
to V
CC
♦
Two Dedicated Channels to Allow Translation
from V
CC
to V
L
♦
100Mbps Guaranteed Data Rates
♦
Enable Input
♦
SMA Inputs and 5mm Scope Probe Jack Outputs
♦
12-Bump UCSP (1.54mm x 2.12mm) Package
♦
Fully Assembled and Tested
Evaluates: MAX13042E
Component List
DESIGNATION QTY
DESCRIPTION
0.1µF ±10%, 16V X7R ceramic
capacitors (0402)
Murata GRM155R71C104K
TDK C1005X7R1C104K
1µF ±10%, 6.3V X5R ceramic
capacitors (0402)
Murata GRM155R60J105K
TDK C1005X5R0J105K
SMA PCB vertical mounts
3-pin header
2-pin headers
5mm scope probe jacks
0Ω resistors (0603)
49.9Ω ±1% resistors (0402)
Not installed, test points
4-channel, bidirectional logic-level
translator
(12-bump UCSP, 1.54mm x 2.12mm)
Maxim MAX13042EEBC+
(Top Mark: ADQ)
Shunts
PCB: MAX13042E EV Kit+
PART
Ordering Information
TYPE
EV Kit
MAX13042EEVKIT+
C1, C2
2
+Denotes
lead-free and RoHS-compliant.
C3
1
Component Suppliers
SUPPLIER
Murata Mfg. Co., Ltd.
TDK Corp.
PHONE
WEBSITE
770-436-1300 www.murata.com
847-803-6100 www.component.tdk.com
IVL1, IVL2,
IVCC3, IVCC4
JU1
JU2–JU5
OVCC1,
OVCC2, OVL3,
OVL4
R1–R8
R9–R12
TP1–TP4
4
1
4
4
8
4
0
Note:
Indicate that you are using the MAX13042E when con-
tacting these component suppliers.
U1
1
—
—
5
1
UCSP is a trademark of Maxim Integrated Products, Inc.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
MAX13042E Evaluation Kit
Evaluates: MAX13042E
Quick Start
Recommended Equipment
Before beginning, the following equipment is needed:
• 1.62V to 3.2V DC power supply
•
•
•
•
2.2V to 3.6V DC power supply
Logic function generator
Oscilloscope
Standard 5mm scope probe
The MAX13042E EV kit circuit features I/O traces of
matched length (within 5 mils) to maintain propagation-
time uniformity. The EV kit dedicates two channels for
translation between V
L
to V
CC
and two channels for
translation between V
CC
to V
L
. Input signals can either
be applied using SMA connectors IVL1, IVL2, IVCC3,
and IVCC4 or at test points TP1–TP4. Output signals
are monitored using oscilloscope probe jacks OVCC1,
OVCC2, OVL3, and OVL4. The EV kit also utilizes the
MAX13042E’s enable function through configuration of
jumper JU1.
Procedure
The MAX13042E EV kit is fully assembled and tested.
Follow the steps below to verify board operation.
Caution: Do not turn on the power supply until all
connections are completed.
1) Verify that a shunt is installed on jumper JU1
between pins 1-2 (normal operation).
2) Set the logic function generator to produce a 1MHz,
2V
P-P
, 1V offset square wave. Disable the logic
function generator output.
3) Connect the logic function generator to SMA input
IVL1. Terminate function generator as necessary.
4) Connect the positive terminal of the 2V supply to the
VL PCB pad and the ground terminal to the GND
PCB pad.
5) Connect the positive terminal of the 3V supply to the
VCC PCB pad and the ground terminal to the GND
PCB pad.
6) Place an oscilloscope probe at scope jack output
OVCC1.
7) Enable the power supplies and the logic function
generator output.
8) Verify that OVCC1 shows a 1MHz, 3V
P-P
square
wave with a 1.5V offset.
Enable Input
Jumper JU1 controls the enable input of the
MAX13042E. See Table 1 for JU1 jumper selection.
Table 1. Enable (EN) Pin Setting
(Jumper JU1)
SHUNT
POSITION
1-2*
2-3
ENABLE PIN (EN)
Connected to V
L
EV KIT FUNCTION
Enabled (normal operation)
Connected to GND Disabled (tri-state operation)
*Default
position.
SMA Inputs (IVL1, IVL2, IVCC3, and IVCC4)
To utilize the SMA connectors to apply input signals to
the EV kit, these connections must be appropriately ter-
minated. See Table 2 for SMA input termination set-
tings. Signal traces will remain of matched length in this
configuration.
Table 2. SMA Input Termination
(Jumpers JU2–JU5)
SHUNT POSITION
Installed
Not installed*
INPUT TERMINATION
49.9Ω termination
None**
Detailed Description
The MAX13042E EV kit demonstrates the MAX13042E
4-channel, bidirectional logic-level translator, featured
in a tiny 12-bump UCSP package. The MAX13042E
translates between V
L
(1.62V to 3.2V) and V
CC
(2.2V to
3.6V) logic levels and guarantees data rates up to
100Mbps. The MAX13042E also features ±15kV ESD
protection on all I/O V
CC
lines.
*Default
position.
**Must
configure signal generator for high-impedance output.
Test Point Input Option (TP1–TP4)
To implement use of the test point inputs, remove the
appropriate resistor (R1, R2, R7, or R8) and apply a
signal to the corresponding test point. Signal traces will
remain of matched length in this configuration. GND
pads are conveniently located on the EV kit to ground
the input signal.
Note:
The input signal is not as well
matched as it is with the SMA inputs.
