Product Brief
2EDL EiceDRIVER™ Compact
600 V half-bridge Driver ICs
for consumer electronics and home appliances
The new 2EDL EiceDRIVER™ Compact high-voltage gate driver family meets the ever
growing need for higher application efficiency and smaller form factors in consumer
electronics and home appliances. It is optimized for the switching behavior and power
losses of today’s power supplies using IGBT and MOSFETs with dramatically reduced
gate charges such as the latest generation of Infineon’s CoolMOS™. With a monolithically
integrated ultrafast low-ohmic bootstrap diode, the 2EDL Compact sets the benchmark
for driver ICs needed in applications with more than 2 A output currents.
The 2EDL Compact family comprises seven 600 V drivers with output currents of 0.5 A and 2.3 A
in DSO-8 and DSO-14 150 mil packages for applications based on IGBT or MOSFET switches:
›
The 2EDL05I06BF in DSO-8, optimized for IGBTs, comes without interlock or dead
time. It is ideal for switched reluctance motor drives and two-transistor forward
switched-mode power supply topologies.
›
The 2EDL05I06PF in DSO-8 and the 2EDL05I06PJ in DSO-14 are optimized for IGBTs
and include interlock and dead time. They are recommended for applications such
as fans, pumps, major home appliances, power tools, and general purpose inverters.
The DSO-14 version is recommended for industrial applications with higher creepage
distance requirements.
›
The 2EDL05N06PF in DSO-8 and the 2EDL05N06PJ in DSO-14 boast the same features as
the IGBT driver versions and an undervoltage lockout adapted for MOSFETs. They are
recommended for servers and telecommunications equipment, low-voltage drives, e-bikes,
battery chargers, and half-bridge based switched-mode power supply applications.
›
The 2EDL23I06PJ and 2EDL23N06PJ are 2.3 A half-bridge driver ICs in DSO-14 with
interlock, dead time, fault enable, and overcurrent protection. The 2EDL23I06PJ for
IGBTs is ideal for applications such as multi-oven IH cookers, fans, pumps, and drives.
The 2EDL23N06PJ for MOSFETs is best suited for TV, switched-mode power supplies,
servers and telecommunications equipment, e-scooters, forklifts, and battery chargers.
Key features
›
High creepage distance in DSO-14
›
Integrated ultrafast low-ohmic
›
›
›
›
bootstrap diode
Asymmetric undervoltage lockout
for IGBT types
Specific undervoltage lockout levels
for IGBT and MOSFET
Rail-to-rail output
Overcurrent protection in DSO14
Applications
›
Home appliances
›
Consumer electronics
›
Fans, pumps
›
E-bikes, E-scooters, orklift trucks
›
Power tools
www.infineon.com/eicedriver-compact
Product Brief
600V Half-Bridge EiceDRIVER™ Compact
2EDL family
Bootstrap circuit of 2EDL half-bridge driver ICs with high-performance,
ultrafast bootstrap diode (example with IGBTs):
Products:
›
2EDL05I06BF
›
2EDL05I06PF
›
2EDL05I06PJ
›
2EDL05N06PF
›
2EDL05N06PJ
›
2EDL23I06PJ
›
2EDL23N06PJ
v
D BS
V DD
V
Bus
VB
R
Lim
D
BS
C
BS
HO
v
BS
T1
D1
T2
C
V DD
V
DD
2EDL-
family
VS
LO
v
CE
D2
G ND
Detailed product features
Sales Code
Applications
2EDL05I06BF (DSO-8)
Switched reluct. motor
drive, TTF, PFC
2EDL05I06PF (DSO-8)
2EDL05I06PJ (DSO-14)
Fans, pumps, MHA,
GP drives (GPI)
DSO-14: Industrial
Blocking voltage
Output current (peak)
Integr. bootstrap function
UVLO (lowest turn-off)
Features
600 V
0.36 A / -0.7 A
Ultrafast BS diode and BS
resistor
IGBT (10.9 V)
No deadtime
No interlock
PG-DSO-8 150mil
600 V
0.36 A / -0.7 A
Ultrafast BS diode and BS
resistor
IGBT (10.9 V)
Deadtime, interlock
2EDL05N06PF (DSO-8)
2EDL05N06PJ (DSO-14)
TVs, LV drives, PCs, e-bikes,
adapters (SMPS), batteries
DSO-14: server/telecom
600 V
0.36 A / -0.7 A
Ultrafast BS diode and BS
resistor
MOSFET (7.5 V)
Deadtime, interlock
600 V
2.3 A / -2.8 A
Ultrafast BS diode and BS
resistor
IGBT (10.9 V)
Deadtime, interlock
enable, fault,
overcurrent protection
PG-DSO-14 150mil
2EDL23I06PJ (DSO-14)
Multi-oven IH cookers,
fans, pumps, drives
2EDL23N06PJ (DSO-14)
TVs, adapters (SMPS),
server/telecom, PCs,
e-scooters, forklift trucks,
batteries
600 V
2.3 A / -2.8 A
Ultrafast BS diode and BS
resistor
MOSFET (7.5 V)
Deadtime, interlock
enable, fault,
overcurrent protection
PG-DSO-14 150mil
Package
PG-DSO-8 150mil
PG-DSO-14 150mil
PG-DSO-8 150mil
PG-DSO-14 150mil
